- Page 1 Owner’s Manual Operation and Maintenance Instructions Wisper 906Alpino January 2010 1 edition Revised August 2010 We strongly recommend that you read this entire manual before using your Wisper bike Wisper Limited - 1 -...
-
Page 2: Table Of Contents
User Guide Introduction Page 3 Part 1 Caring for your Wisper bike and pre use checks Before you set off for the first time Page 4 Before each use Page 5 Battery care Page 5 Recharging your battery Page 6... -
Page 3: Introduction
By making the decision to use an electric bike you are helping to safeguard our environment by saving our planet’s precious resources and reducing carbon pollution. Before you use your Wisper bike it is important that you read this manual carefully. If there is anything you do not understand completely please contact us. -
Page 4: Before You Set Off For The First Time
Part 1 Caring for your Wisper bike and checks Although your Wisper bike has been thoroughly tested prior to delivery, it is very important that you check the bike thoroughly before its first use. Equally important are frequent and regular spot checks they will protect you and your Wisper bike. -
Page 5: Before Each Use
To avoid dangerous unplanned acceleration, always make sure that the electrical system is turned off .For your safety, please turn off the power key on the battery when stopped or walking the bike 1.10 Remember to validate your warranty by visiting www.wisperbikes.com/mywarranty and filling in your details. -
Page 6: Recharging Your Battery
When leaving your bicycle during hot weather always leave in a shaded well ventilated area For best results always recharge the battery at room temperature Before unloading the battery make sure it is turned off at the key, then raise the saddle and unload the battery using its handle If your battery is damaged or appears to be overheating for any reason immediately return it to your retailer for advice and a safety check... - Page 7 (C)Handlebar clamp bolt. (18 to 20)N.M (D)Seat pillar clamp nut/bolt. (5-8) N.M (E)Seat clamp nuts. 24N.M (F) Gear shifter nuts. 4N.M (G) Rear carrier nuts. 8N.M (H) Mudguard bracket nuts.8N.M Other nut torque depends on the nut size. M4：2.5-4.0N.M M5：4.0-6.0N.M M6： 6.0-7.5N.M Your bike has a low maintenance SHIMANO 8 speed alfine gear box The brake leavers should lock the wheels when compressed half way between...
-
Page 8: Technical Specifications And Performance
Socket wrench, 14, 15, and 19 mm socket T25 Torx wrench No. 1 Phillips head screwdriver Bicycle tube patch kit, tire pump Technical specifications & performance Type Wisper 906Alpino Performance (with 75kg 165lb rider) Assisted range 8A up to 50km... -
Page 9: Part 2 Controls And Equipment
Problem Possible reasons Trouble shooting Top speed too 1. Low battery voltage 1. Recharge battery fully slow 2. Handle bar control problem 2. Call service 3. Damage to motor driveline 3. Call service Power on but 1. Battery not connected position 1. -
Page 10: Battery On Off And Battery Lock
Battery on off and battery lock Your Wisper bike has 1 set key. The key for turns the battery on/off and locks the battery in the bike. Please keep a careful note of the key numbers as we cannot replace them without these numbers should they become mislaid. - Page 11 single trip distance. If you press it together with C button, you can set the bike’s tyre size. E: This shows the instant power consumption extent. A longer bar means the motor’s output is higher. Battery capacity. Three bars indicate 80% capacity left, two bars indicate 70% left, one 55% capacity left, half bar 5% capacity left.
-
Page 12: The Lights
12.1 When you first ride your 906Alpino you will notice that after one turn of the pedals the motor will start working assisting you ride the bike by adding power to the front wheel. This is the standard or pedelec mode, to continue using the pedelec mode you must keep turning the pedals, if you stop the motor will stop and the bike will slow to a halt. -
Page 13: Brakes
Front: Disc Rear: disc 14.2 The brakes on your Wisper bike are fitted with cut outs which are required by law. This means that when you pull on either the back or front brake lever the motor immediately stops working. - Page 14 14.3.1.2. Adjust the cable tension to the desired modulation by tightening/loosing the tension modulation adjuster bolt on the caliper with 5mm Allen wrench 14.3.1.3. Adjust the cable adjuster bolt on the caliper so that there is 0.3mm clearance between the outside pad and the rotor.
- Page 15 Rear brakes: 14.3.3. Adjust the pads and caliper 14.3.3.1. Use a 3mm Allen wrench to adjust the stationary caliper adjusting bolt at the back (hub side) of the caliper. Adjust the bolt so that there is 0.3mm clearance between the stationary (hub side) pad and the rotor.
- Page 16 Warning: If you are unsure about any part of the installation process you should seek advice from Wisper service center or qualified mechanic. Stem handle bar clamp 15.1...
-
Page 17: The Front Connection Box
Quick release saddle height adjustment 17.1 Your Wisper bike has been fitted with a quick release saddle post collar to facilitate the movement of the saddle to remove the battery or to change the riding position. Always ensure the collar is fully engaged on the seat tube. -
Page 18: Warranty
Warranty Repair or replacement of components IMPORTANT To validate this Warranty the retail customer must register the bike at www.wisperbikes/mywarranty within 14 days of purchase. Only use this product in accordance with this user manual. We offer a limited warranty of on the following items. - Page 19 Service through Your retailer Wisper Ltd 10 Oakenbrow Sway Hants SO41 6DY Tele:01590 681553 Mobile:07977 185830 douglas.lawson@wisperbikes.com www.wisperbikes.com Copyright January 2010 Wisper Ltd - 19 -...
