Wisper 905 ECO Installation Manual

Wisper 905 Eco Installation Manual
1. Prepare a clear space to install your bike.
2. Unpack your bike and components from
the Wisper shipping box and lean the
semi‐assembled bike upside‐down against
a wall (or chair) so it won't tip.
3. Your Wisper shipping box will contain:
main bike frame assembly, seat and
seatpost, two small cardboard boxes. The
smallest box contains: pedals, 2 X keys,
bike tool kit. The other box contains your
battery charger.
4. Use a pair of nippers or scissors and carefully snip the plastic ties holding the front wheel to
the frame. Place the wheel nearby.
5. Carefully lift and turn the bike right way up and again lean it against its support. Snip the
three plastic ties holding the handlebars to the frame and lower the handlebars to the
ground. Carefully remove all protective foam and padding from the bike (scissors are useful
here, but be extremely careful not to scratch the frame, or damage any cables).
6. Use the keys supplied and unlock the battery lock. Make sure
the battery power output cable is unplugged from the
battery, then open out the battery handle and pull the
battery up to slide it free from the bike.
Important: Fully charge the battery before using the
bike. Refer to the User Guide for instructions.
Important: Your first three charge cycles need to be
deep cycles, as detailed in the User Guide.
7. Hint: It is a good idea to begin charging the battery now, so
it is ready sooner. To charge the new battery, unpack the
charger from the larger of the cardboard boxes. Remove
the rubber charge socket protective cap from the battery
(next to the power terminal socket) and, with the I/O
switch on the charger off (O), plug the charger lead into
the charge socket on the battery.
