ITEM #355-7029

CEILING FAN

MODEL #35072
ATTACH YOUR RECEIPT HERE
Serial Number
Purchase Date
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 1-800-554-6504, 8 a.m. - 4:30 p.m, EST, Monday - Friday.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 35072 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Turn of the century 35072

Summary of Contents for Turn of the century 35072

  • Page 1: Ceiling Fan

    ITEM #355-7029 CEILING FAN MODEL #35072 ATTACH YOUR RECEIPT HERE Serial Number Purchase Date Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 1-800-554-6504, 8 a.m. - 4:30 p.m, EST, Monday - Friday.

  • Page 2: Package Contents

    PACKAGE CONTENTS PART DESCRIPTION QUANTITY Hanging Bracket Washer Mounting Screw Down Rod Hair Pin Clevis Pin Canopy Canopy Hole Cover Blade Iron Ring Motor Assembly Blade Silicone Washer Blade Screw Fan Pull Motor Coupling Cover Light Assembly Light Kit Plate Metal Washer Manual Nut Set Screw...

  • Page 3: Safety Information

    SAFETY INFORMATION Please read and understand this entire manual before attempting to assemble, operate or install the product. If you have any questions regarding the product, please call customer service at 1-800-554-6504, 8 a.m. - 4:30 p.m., EST. WARNING: • Important: When using an existing outlet box, be sure the box is securely attached to the building structure and can support the full weight of the fan.
  • Page 4 ASSEMBLY INSTRUCTIONS 2. Remove the hairpin (E) and clevis pin (F) from the downrod support of the motor assembly (J) and loosen the two set screws (T). Slide the downrod (D) through the canopy (G), canopy hole cover (H) and motor coupling cover (O). Feed the black and white and blue wires from fan through the downrod (D).
  • Page 5 ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS 3. Carefully lift the fan and seat the downrod (D)/hanger ball assembly on the hanger bracket (A) that was just attached to the outlet box. Be sure the groove in the ball is lined up with the tab on the hanger bracket (A).
  • Page 6 ASSEMBLY INSTRUCTIONS E E E U E E E A E E E U U 5. Loosen the two shoulder screws (U) without fully removing the hanger bracket (A). Assemble canopy by rotating keyhole slot in canopy over shoulder screws (U) in hanger bracket (A). Tighten shoulder screws (U).
  • Page 7 ASSEMBLY INSTRUCTIONS 7. Attached fan blades (K) to the blade iron ring (I) with blade screws (M). 8. Installing the light kit plate (Q): Remove one of the three screws on the motor mounting plate and loosen the other two. Feed the 4-pin connector through the center hole of the light kit plate (Q).
  • Page 8 ASSEMBLY INSTRUCTIONS 10. Insert 3, 40-watt max type B bulbs (W) into the the sockets on the light assembly (P). CAUTION: Three 40-watt. candelabra-base bulbs (W) are provided with fan. If you replace the bulbs with over 190 watts, the fixture will automatically turn off.
  • Page 9 ASSEMBLY INSTRUCTIONS 12. Attach fan pulls (N) onto the chain hanging from the fan motor. Reverse Switch 13. Use the fan reversing switch located on the motor assembly (J) to optimize your fan for seasonal performance. Toggle the switch back and forth to find the disired direction. Note: Wait for fan to stop before reversing the switch.

  • Page 10: Care And Maintenance

    CARE AND MAINTENANCE At least twice each year tighten all screws and lower canopy to check mounting bracket screws and downrod assembly. Clean fan housing with only a soft brush or lint free cloth to avoid scratching the finish. Clean blades with a lint free cloth. Shut off main power supply before beginning any maintenance.

  • Page 11: Warranty

    WARRANTY TURN ON THE CENTURY® 355-7029 WARRANTY Kichler warrants this fan to be free from defects in workmanship and material present at time of shipment from the factory for Lifetime limited from the date of purchase. This warranty applies only to the original purchaser.
