IR Speed Dome

User Manual

V1.0.0
UD.6L0201D1030A01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IR Speed Dome and is the answer not in the manual?

Questions and answers

Related Manuals for HIKVISION IR Speed Dome

Summary of Contents for HIKVISION IR Speed Dome

  • Page 1: User Manual

    IR Speed Dome User Manual V1.0.0 UD.6L0201D1030A01...
  • Page 2 UL MAKES NO REPRESENTATIONS, WARRANTIES OR CERTIFICATIONS WHATSOEVER REGARDING THE PERFORMANCE OR RELIABILITY OF ANY SECURITY OR SIGNALING RELATED FUNCTIONS OF THIS PRODUCT. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 3: Regulatory Information

    (Cd), lead (Pb), or mercury (Hg). For proper recycling, return the battery to your supplier or to a designated collection point. For more information see: www.recyclethis.info. 0100001030406 © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 4: Safety Instruction

     If the product does not work properly, please contact your dealer or the nearest service center. Never attempt to disassemble the product yourself. (We shall not assume any responsibility for problems caused by unauthorized repair or maintenance.) © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 5  Please use a soft and dry cloth when clean inside and outside surfaces of the product cover. Do not use alkaline detergents.  Improper use or replacement of the battery may result in hazard of explosion. Please use the manufacturer recommended battery type. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 6: Table Of Contents

    Appendix 1 Lightning & Surge Protection ........................37 Appendix 2 RS485 Bus Connection ..........................38 Appendix 3 24VAC Wire Gauge & Transmission Distance ....................41 Appendix 4 Table of Wire Gauge Standards ........................42 © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 7: Chapter 1 Overview

    The dome provides 5 scan modes: auto scan, tilt scan, frame scan, random scan and panorama scan.  Preset Freezing This feature freezes the scene on the monitor when the dome is moving to a preset. This allows for © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 8 When there are both very bright and very dark areas simultaneously in the field of view, WDR balances the brightness level of the whole image and provide clear images with details. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 9 The programmable actions include: pan scan, random scan, patrol 1-8, pattern 1-4, preset 1-8, frame scan, panorama scan, tilt scan, day, night, and none.  Park Action This feature allows the dome to start a predefined action automatically after a period of inactivity. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 10: Chapter 2 Getting Started

     You have to configure the address and the baudrate for the speed dome the same as those in the control devices.  The speed dome is self-adaptive to the PELCO-D, PELCO-P, PRIVATE-Code, VICON, and KALATEL-312 protocols. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 11: Basic Operations

    IR cut filter out Start tilt scanning Pattern 1 Start panorama scanning Pattern 2 Patrol 5 Pattern 3 Patrol 6 Pattern 4 Patrol 7 Enable fast patrol Patrol 8 Enable limit stops © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 12: On-Screen Displays

    Address Show: Display the address of the speed dome. Error Rate Show: Display the error rate of the speed dome. Fan and Heat show: Display the heat information of the speed dome. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 13: Chapter 3 Menu Operation

    3. View the live video of the speed dome. 4. For PELCO-P/D and other private PTZ protocols, call preset 95 from the preset list in the PTZ control panel of the DVR. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 14: Configuring System Information

    The information shown on this submenu is similar to the system information shown after the power-up action. Please refer to Section 2.1 for more details. Enter the system information display menu: MAIN MENUS > SYS INFO © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 15: Configuring System Parameters

    Notes:  Before you set the soft address of the speed dome, you need to confirm that it is within the control range of the control device (e.g. the DVR). © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 16 (1) Move the cursor to ZERO ANGLE using the direction buttons and click IRIS+ to enter. (2) Click the left/right/up/down direction buttons to adjust the monitor angle of the speed dome. (3) Click IRIS+ button to confirm the settings and exit. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 17: Ir Parameter Configuration

    LED control, fan control, switch delay, heat control, and IR correction, etc. Enter the LED parameter submenu: MAIN MENU > DOME SETTINGS > SYS INFO SETTINGS > IR PARAMETER © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 18 ON (normally on), OFF (normally off) or TEM (change according to the temperature).  HEAT CONTROL is also to control the temperature of the speed dome in severe cold © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 19: Configuring Image Parameters

     Protocol and RS-485 settings  Select the protocol. Choose the protocol on PROTO SET submenu. You can configure it as AUTO MATCH, PELCO-P, PELCO-D, HIKVISION, KALATEL or VICON. When you choose AUTO MATCH, it is protocol self-adaptive.  Set the protocol status.

  • Page 20: Configure The Focus/Zoom Settings

    You can set FOCUS LIMT to 1CM, 30CM, 1M, 3M and AUTO to make sure that the speed dome focuses on the target. Note: The focus limit value varies according to the models of speed dome. Task 2: Configure the zoom settings.  Setting the zoom limit © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 21 (1) BLC/WDR. You can set the value as ON or OFF to enable or disable the functions. (2) BLC LEVEL. You can manually adjust the backlight compensation level. Note: BLC level configuration varies according to the different camera models. Some models © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 22: Set The Shutter

    The value of X indicates that the shutter speed is 1/X second. If you set the SHUTTER value bigger (shutter speed is faster), the amount of entering light per second is fewer, and © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 23: Chroma Suppress

    The wide limit function is supported by certain camera model series.  Chroma Suppress Set the Chroma suppress to ON can suppress the color noise so as to get the clear and high-quality image in the low luminance environment. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 24: Configuring Privacy Mask

    (3) Click IRIS+ again to confirm and exit the editing mode. Note: The configurable privacy mask number varies according to the camera models. 3. Configure the position and size of the privacy mask. Steps: © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 25: Configuring Ptz Control Parameters

    You can configure panning, tilting and zooming movements, and configure PTZ control functions including presets, patrols, patterns, etc. for the speed dome. 3.4.1 Configuring PTZ Parameters Enter PTZ configuration menu: MAIN MENU > DOME SETTINGS > MOTION PARAMETER © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 26 You can set IMAGE FREEZE as ON or OFF to enable or disable this function. Note: The function varies according to the different camera models.  PTZ speed © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 27: Configuring Presets

    A preset is a user-defined monitoring position/point. You can simply call the preset number to change the monitor scene to the defined position. Steps: 1. Move the cursor to enter preset configuration submenu: MAIN MENU > DOME SETTINGS > PRESETS © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 28: Configuring Patrols

    A patrol is a scanning track specified by a group of user-defined presets. You can call a patrol to scan the scenes automatically among the user-defined presets in sequence. Steps: 1. Move the cursor to enter patrol configuration submenu: MAIN MENU > DOME SETTINGS > PATROLS © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 29 (4) Follow the above steps to define the other presets for the selected patrol. You can configure up to 32 presets in sequence for a patrol. Press IRIS+ to save the new settings or press IRIS- © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 30: Configuring Patterns

    (2) Click the up/down direction buttons to select the number of the pattern which is to be configured. (3) Click IRIS+ again to confirm the settings. Note: Up to 4 patterns can be configured. 3. Edit the pattern. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 31: Configuring Time Tasks

    3.4.5 Configuring Time Tasks Purpose: A time task is a preconfigured action that can be performed automatically at a specific date and time. Steps: 1. Move the cursor to enter the TIME TASK submenu: © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 32 (3) Click the up and down direction buttons to set the start time and end time to run the time task. (4) Click IRIS+ to confirm the settings and exit. Note: The weekday can be set to be from Monday to Sunday or Whole Week; the H refers to © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 33: Configuring Zone

    (2) Click the up and down buttons to select the zone number to be configured. (3) Click IRIS+ again to confirm the settings and exit edit mode of this column. Note: Up to 8 zones can be configured. 3. Configure the zone area. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 34: Clearing Ptz Control Settings

    Click IRIS+ again to confirm the settings and exit. On DIAGNOSTICS submenu, you can see the self-diagnostics information of the speed dome. For more details, please refer to the table below. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 35: Others

    95 to enter the menu. Steps: 1. Move the cursor to enter the password modification submenu: MAIN MENU > DOME SETTINGS > PASSWORD > EDIT PASSWORD 2. Click IRIS+ to enter edit mode. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 36: Restoring Default Dome Settings

    Table 1-4 Parameters Default Value Dome address Baud rate 2400bps 120Ω matching resistance Soft address Focus Zoom limit Max Optical Zoom Zoom speed High Slow shutter IR cut filter D/N level © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 37: Restoring Default Camera Settings

    Note: Camera settings include the image parameters, lens settings and display settings. 3.5.4 Rebooting the Dome Enter MAIN MENU > REBOOT DOME and click IRIS+ to reboot the speed dome remotely. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 38: Appendix

    4Ω. The sectional area of the grounding cable should be no less than 25mm2. For grounding instructions, please refer to the Installation Manual of Speed Dome. Lightning & Surge Protection Figure A- 1 © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 39: Appendix 2 Rs485 Bus Connection

    RS485 industry standard so that it will lead to some problems such as signal reflection, anti-jamming ability decline when the devices are © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 40 3. The RS485 wire is 3. Reconnect the RS485 wire remotely. disconnected. tightly. 4. RS485 wire is broken. 4. Change a RS485 wire. The speed 1. The connection is loose. 1. Reconnect the RS485 wire © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 41 3. The speed dome is too far away 3. Add a terminal resistor. smoothly. from the remote control device. 4. Too many speed domes are 4. Add a RS485 distributor. connected. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 42: Appendix 3 24Vac Wire Gauge & Transmission Distance

    34（10） 55（16） 139（42） 20（6） 32（9） 51（15） 129（39） 18（5） 30（9） 47（14） 120（36） 17（5） 28（8） 44（13） 113（34） 16（4） 26（7） 42（12） 106（32） 15（4） 25（7） 39（11） 100（30） 14（4） 23（7） 37（11） 95（28） 14（4） 22（6） 35（10） 90（27） © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 43: Appendix 4 Table Of Wire Gauge Standards

    Bare Wire British Wire Wire Gauge Area of Bare Gauge(mm) Gauge SWG Wire(mm2) 0.750 0.4417 0.800 0.5027 0.900 0.6362 1.000 0.7854 1.250 1.2266 1.500 1.7663 2.000 3.1420 2.500 4.9080 3.000 7.0683 © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
