Models: STLDVNS/PS, CLLDVNS/PS,
CRLDVNS/PS, PFLDVNS/PS
Installation and operating
Instructions
waRNING
IF The INFoRMaTIoN IN TheSe INSTRuCTIoNS IS
NoT FoLLoweD exaCTLy, a FIRe oR exPLoSIoN
May ReSuLT CauSING PRoPeRTy DaMaGe,
PeRSoNaL INjuRy oR LoSS oF LIFe.
–
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
–
whaT To Do IF you SMeLL GaS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use
any phone in your building.
• Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the
fire department.
–
Installation and service must be performed
by a qualified installer, service agency or the
gas supplier.
waRNING: Improper installation, adjustment,
alteration, services or maintenance can cause
injury or property damage. Refer to this manual.
For assistance or additional information consult
a qualified installer, service agency or the
gas supplier.
This appliance may be installed in an aftermarket*,
permanently located, manufactured home (uSa
only) or mobile home, where not prohibited by
local codes.
This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is
not convertible for use with other gases, unless a
certified kit is used.
* aftermarket: Completion of sale, not for purpose of resale, from
the manufacturer.
Designer Series Direct Vent
Gas Fireplace
Due To hIGh TeMPeRaTuReS, The aPPLIaNCe
ShouLD Be LoCaTeD ouT oF TRaFFIC aND
away FRoM FuRNITuRe aND DRaPeRIeS.
ChILDReN aND aDuLTS ShouLD Be aLeRTeD
To The haZaRDS oF hIGh SuRFaCe
TeMPeRaTuRe aND ShouLD STay away To
aVoID BuRNS oR CLoThING IGNITIoN.
youNG ChILDReN ShouLD Be SuPeRVISeD
wheN They aRe IN The SaMe RooM aS The
aPPLIaNCe.
CLoThING oR oTheR FLaMMaBLe MaTeRIaL
ShouLD NoT Be PLaCeD oN oR NeaR The
aPPLIaNCe.
KeeP The RooM aRea CLeaR aND FRee
FRoM CoMBuSTIBLe MaTeRIaLS, GaSoLINe,
aND oTheR FLaMMaBLe VaPoRS aND
LIquIDS.
INSTaLLeR: Leave this manual with the appliance.
CoNSuMeR: Retain this manual for future refer-
ence.
2381
designer cover
waRNING
20302381 10/10 Rev. 2
Advertisement
Table of Contents
Related Manuals for MHSC STLDVNS
Summary of Contents for MHSC STLDVNS
- Page 1 Designer Series Direct Vent Gas Fireplace Models: STLDVNS/PS, CLLDVNS/PS, CRLDVNS/PS, PFLDVNS/PS Installation and operating Instructions waRNING IF The INFoRMaTIoN IN TheSe INSTRuCTIoNS IS NoT FoLLoweD exaCTLy, a FIRe oR exPLoSIoN May ReSuLT CauSING PRoPeRTy DaMaGe, PeRSoNaL INjuRy oR LoSS oF LIFe.
-
Page 2: Table Of Contents
CoNTeNTS Designer Series Direct Vent Gas Fireplace Thank you and congratulations on your purchase of an MhSC Fireplace. PLeaSe ReaD The INSTaLLaTIoN aND oPeRaTIoN INSTRuCTIoNS BeFoRe uSING The aPPLIaNCe! IMPoRTaNT: Read all instructions and warnings carefully before starting installation. Failure to follow these instructions may result in a possible fire hazard and will void the warranty. -
Page 3: Important Safety Information
IMPoRTaNT SaFeTy INFoRMaTIoN Designer Series Direct Vent Gas Fireplace INSTaLLeR owNeR Please leave these instructions with the appliance. Please retain these instructions for future reference. • Read this owner’s manual carefully and completely before trying to assemble, operate, or service this fireplace. •... -
Page 4: Code Approval
IMPoRTaNT SaFeTy INFoRMaTIoN & CoDe aPPRoVaL Designer Series Direct Vent Gas Fireplace 12. Do not use this fireplace to cook food or burn paper or IMPoRTaNT: other objects. PLeaSe ReaD The FoLLowING 13. Never place anything on top of fireplace. CaReFuLLy 14. -
Page 5: Product Specifications
PFLDVNS Nat. 37,000 25,000 In Canada, please consult provincial and/or local authori- PFLDVPS 35,000 27,000 1.8 mm ties having jurisdiction for installations at elevations STLDVNS Nat. 37,000 25,000 above 4,500 feet (1,370 m). STLDVPS 35,000 27,000 1.8 mm GaS PReSSuReS CLLDVNS Nat. -
Page 6: Fireplace Dimensions
FIRePLaCe DIMeNSIoNS Designer Series Direct Vent Gas Fireplace 12" (305 mm) 47 ” (1216 mm) 41 ” 25 ” ” (903 mm) (1064 mm) (654 mm) 28 ” (718 mm) 37 ” (962 mm) 1/4" (6 mm) ” (840 mm) 23" (584 mm) ” ” (979 mm) 7 ” (81 mm) (200 mm) ” (1259 mm) FP2851 Figure 2 - STLDV (See-thru) Fireplace Dimensions FP2851 LDV see thru dims... - Page 7 FIRePLaCe DIMeNSIoNS Designer Series Direct Vent Gas Fireplace 12" (305 mm) 7 ” 47 ” (200 mm) (1216 mm) 21” 41 ” ” (903 mm) (533 mm) (1064 mm) 25 ” 28 ” (654 mm) 28 ” (718 mm) (718 mm) 37 ” 1/4" (962 mm) 1/4" (6 mm) (6 mm) 18 ” ” (840 mm) 23" (584 mm) 5 ”...
-
Page 8: Fireplace Framing Dimensions
Designer Series Direct Vent Gas Fireplace FIRePLaCe FRaMING 23" (1/2" Drywall) or Adjustable to 22 ” (5/8” Drywall) Remove box and Insulation for Top Vent Configurations Noncombustible Material Fold Outer Tabs and Nail to Framing ” Members (1224 mm) NoTe: Glass cen- terline is off center from rought framing dimensions. -
Page 9: Crldv/Clldv Framing
Designer Series Direct Vent Gas Fireplace FIRePLaCe FRaMING 46 ” (1172 mm) (1/2” Drywall) 27 ” (699 mm) (1/2” Drywall) 46” (1168 mm) (5/8” Drywall) Remove box and 27 ” (696 mm) Insulation for Top (5/8” Drywall) Vent Configurations Noncombustible Material " (1224 mm) If using 5/8" drywall, remove framing tabs and re-install on 2nd set of holes positioned slightly inwards... -
Page 10: Pfdv Framing
FIRePLaCe FRaMING Designer Series Direct Vent Gas Fireplace 23” (584 mm) (1/2” Drywall) or Adjustable to 46 ” (1172 mm) 22 ” (578 mm) (1/2” Drywall) (5/8” Drywall) 46” (1168 mm) Noncombustible (5/8” Drywall) Material Remove box and Insulation for Top Vent Configurations ” (1224 mm) If using 5/8" drywall, remove framing tabs and re-install on 2nd set of holes positioned slightly inwards Fold Outer Tabs... -
Page 11: Installation Information
PRe-INSTaLLaTIoN INFoRMaTIoN Designer Series Direct Vent Gas Fireplace BeFoRe you STaRT FIReBox FRaMING Read this homeowner manual thoroughly and follow all Firebox framing can be built before or after the appliance instructions carefully. Inspect all contents for shipping is set in place. Construct firebox framing following Figure damage and immediately inform your dealer if any damage 5, 6 or 7 for your specific installation requirements. -
Page 12: Fireplace Location
PRe-INSTaLLaTIoN INFoRMaTIoN Designer Series Direct Vent Gas Fireplace FIRePLaCe LoCaTIoN Plan for the installation of your appliance. This includes determining where the unit is to be installed, the vent configuration to be used, framing and finishing details, and whether any optional accessories (i.e. -
Page 13: Clearances
CLeaRaNCeS Designer Series Direct Vent Gas Fireplace CLeaRaNCeS To CoMBuSTIBLeS Follow these instructions carefully to ensure safe installation. Failure to follow instructions exactly can create a fire hazard. The appliance cannot be installed on a carpet, tile or other combustible material other than wood flooring. -
Page 14: Venting Installation
Installation of any damaged venting component. • Unauthorized modification of the venting system. • Installation of any component part not manufactured or approved by MHSC • Installation other than permitted by these instructions. Failure to follow these instructions will void the warranty. - Page 15 VeNTING INSTaLLaTIoN Designer Series Direct Vent Gas Fireplace Screws after conversion to top vent configuration, Flue Pipe the 5" (127 mm) flue pipe should be Cover concentric with the 8" (203 mm) outer collar within 1/4". Flue Cover Screws Flue Pipe FP2833 Adapter Figure 12 -...
-
Page 16: Vent Pipe Clearances
VeNTING INSTaLLaTIoN Designer Series Direct Vent Gas Fireplace horizontal sections of this vent system require a minimum of 3" clearances to combustibles at the top of the flue and 1" clearance at the sides and bottom until the flue penetrates the outside wall. -
Page 17: Installation Planning
Designer Series Direct Vent Gas Fireplace VeNTING INSTaLLaTIoN INSTaLLaTIoN PLaNNING Never run the vent pipe down. This may There are two basic types of direct-vent installation: cause excessive temperatures which could • Horizontal Termination cause a fire. • Vertical Termination It is important to select the proper length of vent pipe for the type of termination you choose. -
Page 18: Termination Location
3. MHSC assumes no responsibility for the improper only permitted if veranda, porch, deck or balcony is fully open on a performance of the appliance when the venting system minimum 2 sides beneath the floor: does not meet these requirements. -
Page 19: Vent Graph
VeNTING INSTaLLaTIoN Designer Series Direct Vent Gas Fireplace TeRMINaTIoN CLeaRaNCeS FoR BuILDINGS wITh CoMBuSTIBLe aND NoNCoMBuSTIBLe exTeRIoRS G=6" (152mm) F=6" (152mm) Combustible – 6" (152 mm) Noncombustible – 2" (51mm) Inside Corner Outside Corner C = Maximum depth of 48" (1219mm) for alcove location D = Minimum width for back wall of alcove location... -
Page 20: Rear Wall Vent Installation
Combustible Interior walls: Cut a 12 " x 10 " hole behind the appliance. Only an MHSC brand termination is through the interior wall. allowed for this application. Combustible exterior walls: Cut a 10 "... - Page 21 MHSC termination) Apply Mastic Termination to all Four Sides all rear vent through-the-wall applications must use MhSC-designed 5 x 8 square ter- mination. No other manufacturer's termina- tion is permitted in this application. Bolt FP1956 Wood Screw For more information, follow instructions Figure 23 - provided with terminations.
-
Page 22: Horizontal W/Vertical Rise Applications
VeNTING INSTaLLaTIoN Designer Series Direct Vent Gas Fireplace when installing the appliance as a rear 3 x 90° vent unit, the 90° or 45° transition elbow Elbows attached directly to the rear of the unit is NoT INCLuDeD in the following criteria and calculations and, unless specifically mentioned, should be ignored when calculating venting layouts. - Page 23 VeNTING INSTaLLaTIoN Designer Series Direct Vent Gas Fireplace hoRIZoNTaL wITh VeRTICaL RISe (ThRouGh-The-waLL) aPPLICaTIoNS 1. Locate and cut the vent opening in the wall. For combustible walls first frame in opening. Combustible Interior walls: Cut a 12Z\x"H x 10Z\x" W hole through the interior wall.
-
Page 24: Below Grade Installation
VeNTING INSTaLLaTIoN Designer Series Direct Vent Gas Fireplace 1. Locate and cut the vent opening in the wall. For com- 1. Establish vent hole through the wall. bustible walls first frame in opening. 2. Remove soil to a depth of approximately 16" below base Combustible Interior walls: Cut a 11Z\x"H x 9Z\x"... -
Page 25: Vertical Through-The-Roof Applications
VeNTING INSTaLLaTIoN Designer Series Direct Vent Gas Fireplace VeRTICaL ThRouGh-The-RooF aPPLICa- TIoNS a restrictor disc must be installed on vertical terminations that are higher than 12' (366 cm). Maximum 40' Maximum Height 8' Minimum Height Install restrictor disc as shown in Figure 34 for vertically vented applications. -
Page 26: Installation For Vertical Termination
VeNTING INSTaLLaTIoN Designer Series Direct Vent Gas Fireplace Roof Flashing Wall Strap 45° Elbows FP1669 Example: Elbow 1 = 90° Elbow 2 = 45° Elbow 3 = 45° Ceiling Firstop Elbow 4 = 90° Total Angular Variation = 270° Figure 37 - Offset with Wall Strap and 45°... - Page 27 VeNTING INSTaLLaTIoN Designer Series Direct Vent Gas Fireplace Nails NoTe: If the vent pipe passes through any occupied areas above the first floor, including storage spaces and closets, you must enclose pipe. You may frame and sheetrock the enclosure with standard construction material. Make sure to meet the minimum allowable clearances to combustibles.
-
Page 28: Flex Vent Installation
FLex VeNT INSTaLLaTIoN Designer Series Direct Vent Gas Fireplace 1. Insert the long side of the 5" inner ring into exhaust 1. Flexible UL1777 listed venting may be used in any pipe, gently tap to seat into place, and secure with venting application where rigid direct vent components screws. - Page 29 2. Connect the 8" flexible vent to the termination assemblies. ring as in Figure 45. 1. When using Simpson pipe, an MHSC flex-to-pipe 3. Review Figure 45 for proper overlap and clamp adapter and/or rigid pipe section(s) is required to placement.
- Page 30 UL1777 Flex Vent Figure 48 - FP1975 Typical Pipe Connection Firestop 4 x 7 pipe connection UL1777 Flex MHSC Horizontal PIpe Vent Termination Screws 7TDVP58 5" x 8" to (3 Places equidistant just 4" x 7" Reducer above gear clamp) UL1777 Flex Vent 1C\v"...
-
Page 31: Fireplace Installation
FIRePLaCe INSTaLLaTIoN Designer Series Direct Vent Gas Fireplace CheCK GaS TyPe Use proper gas type for the fireplace you are installing. If you have conflicting gas type, do not install fireplace. See dealer where you purchased the fireplace for proper fireplace according to your gas type. -
Page 32: Install Gas Piping
Designer Series Direct Vent Gas Fireplace FIRePLaCe INSTaLLaTIoN GaS SuPPLy LINe INSTaLLaTIoN a manual shutoff valve must be installed only persons licensed to work with gas upstream of the appliance. union tee piping may make the necessary gas and plugged 1/8" NPT pressure tapping connections to this appliance. -
Page 33: Check Gas Pressure
CheCK GaS PReSSuRe and eLeCTRICaL INSTaLLaTIoN Designer Series Direct Vent Gas Fireplace Pressure Inlet 1. Check gas type. The gas supply must be the same as stated on the appliance’s rating decal. If the gas supply is different from the fireplace, SToP! Do not install the appliance. -
Page 34: Junction Box Wiring
eLeCTRICaL INSTaLLaTIoN Designer Series Direct Vent Gas Fireplace juNCTIoN Box wIRING 1. This should be done before framing the fireplace. Wire the receptacle into an electrical circuit. Wire with mini- mum 60° C wire in accordance with prevailing codes. 2. Remove the external junction box cover by removing the screw from the side of the outside firebox wall. -
Page 35: Signature Command Wiring Diagram
eLeCTRICaL INSTaLLaTIoN Designer Series Direct Vent Gas Fireplace Optional To Junction Box AC Module in Fireplace Pilot Optional White Light Black Optional White Blower Black White Optional Black Aux. Green Connector Pin To Control Board Input 300 Watt Max. Each Optional A/C Module Replaces 6V Adapter When Used RF Receiver ON/OFF Button Control Board 6V AC Black / Thermopile Adapter Red / Thermopile Sensor Conversion NG/LP Ignitor / Sparker Plug-in Connector... - Page 36 oPTIoNaL FaN BLoweR SySTeM Designer Series Direct Vent Gas Fireplace electrical Grounding Instructions: This electrical connections should only be appliance is equipped with a three-prong performed by a qualified licensed electrician. (grounding) plug for your protection against Main power supply must be turned off before shock hazard and should be plugged directly connecting the fan to the main electrical into a properly grounded three-prong...
-
Page 37: Optional Fan/Blower Systems
oPTIoNaL FaN BLoweR SySTeMS Designer Series Direct Vent Gas Fireplace BLoTBLDV auToMaTIC DuaL TheRMoSTaT BLoweR 120VAC Receptacle Junction BLACK GREEN WHITE BLACK WHITE BLACK BLACK Speed Control Figure 56 - BLOTBLDV Blower Wiring Diagram FP2685 Before installing the blower, wire the receptacle into an electrical circuit. -
Page 38: Glass Frame Removal
GLaSS ReMoVaL Designer Series Direct Vent Gas Fireplace GLaSS FRaMe ReMoVaL 1. Remove access panel by lifting up and out. each clamp has a quick spring force. when 2. Release two clamps (500 model has three clamps) on reinstalling clamps, keep fingers clear. bottom of fireplace. -
Page 39: Final Installation
FINaL INSTaLLaTIoN Designer Series Direct Vent Gas Fireplace RoCK wooL PLaCeMeNT Place rock wool evenly in dime-sized pieces over the burner ports. Do not place embers over the burner slots. To better enable the gas to permeate the rock wool, apply the rock wool in light, dime size fluffy pieces. -
Page 40: Log Placement
LoG PLaCeMeNT Designer Series Direct Vent Gas Fireplace LoG PLaCeMeNT Log #1 1. Hold log #1 with the rounded end opposite the pilot. NoTe: Log #1 is designed to not be symmetrical. Place log #1 aligning the two (2) pins provided making sure to fit the notches in the bottom of the log over the sides of the grate so that it... - Page 41 Designer Series Direct Vent Gas Fireplace LoG PLaCeMeNT Log #3 False-Bottom Hearth 3. Position log #3 on the key pro- vided on the rounded end of log #1. The other end sits on the "false-bottom hearth" (the sheet metal surrounding the burner and supporting the grate), just outside of the grate.
- Page 42 Designer Series Direct Vent Gas Fireplace LoG PLaCeMeNT 5. Place log #5 on the key provided on log #4. Rest the other end of the log on the "false-bottom hearth" just outside of the grate. It should be almost touching the end of log #1.
-
Page 43: Operating Instructions
oPeRaTING INSTRuCTIoNS Designer Series Direct Vent Gas Fireplace FoR youR SaFeTy ReaD BeFoRe LIGhTING If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of lie. a. This appliance is equipped with an ignition device which automatically lights the pilot. Refer to the instructions. -
Page 44: Operating Instructions
oPeRaTING INSTRuCTIoNS Designer Series Direct Vent Gas Fireplace oPeRaTING INSTRuCTIoNS 1. SToP! Read the safety information above. 2. This appliance is equipped with an ignition device which automatically lights the burner. Do not try to light the burner by hand. 3. -
Page 45: Signature Command System Operation
Designer Series Direct Vent Gas Fireplace SIGNaTuRe CoMMaND SySTeM oPeRaTIoN INSTRuCTIoNS FeaTuReS To Thermopile RF Receiver Command Center ON/OFF To Sensor • Easy Access Function Operation and System Configura- To Sparker tion • Operation Confirmation/Fault Diagnostic Indications (LED/ NG/LP Conversion Buzzer) •... -
Page 46: System Configuration/Setup
Designer Series Direct Vent Gas Fireplace SIGNaTuRe CoMMaND SySTeM oPeRaTIoN INSTRuCTIoNS SySTeM CoNFIGuRaTIoN/SeTuP All System configuration/setup is done on the Command Center. NoTe: When using On/Off wall switch, the switch must be in the ON position to perform all configuration set ups at the command center. - Page 47 SIGNaTuRe CoMMaND SySTeM oPeRaTIoN INSTRuCTIoNS Designer Series Direct Vent Gas Fireplace FuNCTIoNS/oPeRaTIoN Turning on the fireplace 1. Turn on the master switch and wait for a beep. 2. Press the ON button on the Command Center or turn on wall switch. Pilot will light and burner will come on High setting or last memory setting (See Turning Off Fireplace below).
-
Page 48: Cleaning And Maintenance
CLeaNING aND MaINTeNaNCe Designer Series Direct Vent Gas Fireplace Sensor Turn off gas before servicing fireplace. It is recommended that a qualified service technician perform these check-ups at the Thermopile beginning of each heating season BuRNeR, PILoT aND CoNTRoL CoMPaRT- MeNT Keep the control compartment, logs, and burner areas surrounding the logs clean by vacuuming or brushing at... -
Page 49: Venting System
Designer Series Direct Vent Gas Fireplace CLeaNING aND MaINTeNaNCe VeNT SySTeM The fireplace and venting system should be inspected before initial use and at least annually by a qualified field service person. Inspect the external vent cap on a regular basis to make sure that no debris is interfering with the airflow. -
Page 50: Troubleshooting
TRouBLeShooTING Designer Series Direct Vent Gas Fireplace SIGNaTuRe CoMMaND SySTeM ACTION OPERATION FAULT DIAGNOSIS Using Battery polarity wrong? Re-install batteries battery? Make sure Command Install batteries and/or Battery voltage low? Change batteries Center and plug in the AC board No beep in about the control 8 seconds board are... -
Page 51: Replacement Parts
RePLaCeMeNT PaRTS Designer Series Direct Vent Gas Fireplace FIReBox CoMPoNeNTS CR/CL Item Description qty. qty. qty. Designer LDV Glass Frame Assembly 20302401 Access Panel 20302126 Glass Frame Assembly, Short 20302151 Access Panel, Short 20302127 2381 Grate 20301124 firebox parts Junction Box Assembly (not shown) 26D2128 20302381... -
Page 52: Signature Command System
RePLaCeMeNT PaRTS Designer Series Direct Vent Gas Fireplace SIGNaTuRe CoMMaND SySTeM 2381 LDV SCS burner parts 20302381... - Page 53 RePLaCeMeNT PaRTS Designer Series Direct Vent Gas Fireplace SIGNaTuRe CoMMaND SySTeM Item Description qty. Designer Natural Designer LP Burner Assy 20302188 20302188 Venturi Gasket 45D0032 Venturi Assy 69D1119 Injector 70D0064 20H3153 Tube, Union to Venturi 20302009 20302009 Fitting Brass - Union 5/16 Compression 37D0713 37D0713 Tube, Elbow to Union...
-
Page 54: Logs
Designer Series Direct Vent Gas Fireplace RePLaCeMeNT PaRTS LoGS Item Description qty. Designer LDV Log #1 20302432 2381 Log #2 20302433 Designer LDV logs Log #3 20302434 Log #4 20302435 Log #5 20302436 20302381... -
Page 55: Brick
RePLaCeMeNT PaRTS Designer Series Direct Vent Gas Fireplace BRICK herringbone Brick Traditional Brick Ref. Description Cottage Red olde english Vintage Brown End Wall, Traditional 20302517 Long Wall, Traditional 20302518 End Wall, Herringbone 20302519 20302521 2381 Long Wall, Herringbone 20302520 20302522 LDV brick parts 20302381... - Page 56 RePLaCeMeNT PaRTS Designer Series Direct Vent Gas Fireplace VeNT CoMPoNeNTS 0004 MLDV vent parts 20302381...
-
Page 57: Venting Components
Designer Series Direct Vent Gas Fireplace VeNT CoMPoNeNTS FoR 4" x 6B\," Current Simpson Simpson Duravent Duravent qty./ or MhSC or MhSC Selkirk Item Box Description Part no. Part no. Part no. Thru-roof Flexible Pipe Termination Kit with flex adapter TRFK 24"... - Page 58 VeNTING CoMPoNeNTS Designer Series Direct Vent Gas Fireplace VeNT CoMPoNeNTS FoR 5" x 8" Current Simpson Simpson Duravent Duravent qty./ or MhSC or MhSC Selkirk Item Box Description Part no. Part no. Part no. Horizontal High Wind Termination Cap 58DVA-HC...
-
Page 59: Vent Components
VeNTING CoMPoNeNTS Designer Series Direct Vent Gas Fireplace hoRIZoNTaL VeNTING - 4" x 7" Description Model Number Horizontal Vent Termination Kits Rear Vent Hot Touch Termination Kit w/ 10" to 16" 7TBRHTK Adjustable Termination Pipe, Firestop, and Hot Touch Termination w/ Siding Shield Up and Out Side Wall Termination Kit w/ 10"... - Page 60 VeNTING CoMPoNeNTS Designer Series Direct Vent Gas Fireplace VeRTICaL VeNTING - 4" x 7" Description Model Number Vertical Vent Termination Kits Vertical Vent Termination w/ Storm Collar 7TDVSKV (flashing NOT included) Vertical Vent Termination w/ Storm Collar - 8 pack 7TDVSKV/8 (flashing NOT included) Vertical Vent Termination w/ 1/12 - 6/12 Flashing, Storm...
- Page 61 Designer Series Direct Vent Gas Fireplace 20302381...
-
Page 62: Massachusetts Residents Only
Designer Series Direct Vent Gas Fireplace Requirements for the Commonwealth of of eight (8) feet above grade directly in line with the exhaust Massachusetts vent terminal for the horizontally vented gas fueled heating This product must be installed by a licensed plumber or appliance or equipment. -
Page 63: Warranty
After installation, if any of the components manufactured by MHSC in the appliance are found to be defective in materials or workmanship, MHSC will, at its option, replace or repair the defective components at no charge to the original owner. MHSC will also pay for reasonable labor costs incurred in replacing or repairing such components for a period of two years from date of installation. -
Page 64: Efficiencies
D.o.e. Fireplace efficiency (%) (aFue%) Natural Gas 69.7 67.0 LP/Propane 79.4 68.3 Recherchez dans la brochure les caractéristique de rendement énergétique de foyer au gaz Énerguide Selon CSA P.4.1-09 Based on CSA P.4.1-09 MhSC 149 Cleveland Drive • Paris, Kentucky 40361 www.mhsc.com 20302381...
