KVM Extension over UTP (Cat5) for Dual Video PCs
Dual-Video Ports, keyboard, mouse, audio, and serial port
Sender Station, features Local ports for KVM optional hookup
U
s
e
r
U
s
e
r
Model U97-H2
Extend PC's
to 500 feet using only 2 Cat5 Cables
H
R
all
esearch
Phone:
Fax:
'
s
M
a
n
u
a
'
s
M
a
n
u
a
April 15, 2006
T
echnologies, Inc
1163 Warner Ave.
Tustin, CA 92780
l
l
UMA1095 Rev. n/c
(714) 641-6607
(714) 641-6698
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Hall Research Technologies U97-H2
Summary of Contents for Hall Research Technologies U97-H2
- Page 1 (714) 641-6607 Fax: (714) 641-6698 ’ ’ Model U97-H2 KVM Extension over UTP (Cat5) for Dual Video PCs Extend PC’s Dual-Video Ports, keyboard, mouse, audio, and serial port to 500 feet using only 2 Cat5 Cables Sender Station, features Local ports for KVM optional hookup April 15, 2006 UMA1095 Rev.
- Page 2 PRODUCT DESCRIPTION FEATURES SETUP OPERATION HOW TO CONTROL THE VIDEO COMPENSATION SPECIFICATIONS (FCC) S __________ EDERAL OMMUNICATIONS OMMISSION TATEMENT - 1 -...
-
Page 3: Product Description
The digital compensation control is controlled via hot keys on the remote keyboard. The Sender unit of the U97-H2 has an external control switch that will allow only local control, or only remote control, or either station control. The Sender unit also has 2 LEDs to indicate which station, local or remote, currently has control. - Page 4 Setup Figure 2 U97-H2 Sender Connector and Indicator Functions Figure 3 Cable for connection to PC Power down the PC Use the special “KVVM” (4-in-1) cable to connect the Sender unit to the PC. The end with the 4 connections connects to the PC The other end connects to the Sender via the DB25-15 connector labeled “INPUT”...
- Page 5 Connect the RS-232 (serial) output from the PC to the RS-232 input on the Sender via the “RS-232” label on the Sender unit with a male-to-female DB9 cable Connect any combination of keyboard, mice, video A, video B, audio, or RS-232 to the Sender and Receiver to control the PC Connect a keyboard and/or mouse and/or video and/or audio and/or RS-232 to the Sender unit via the connections labeled “Local”...
- Page 6 Operation The U97-H2 will allow only the local or remote to communicate with the PC at any given time. After either stations stops sending keyboard or mouse data, there is a 2 second delay before the other station can start sending data to the PC. If the Local LED on the Sender is lit then only the local station may communicate with the PC.
-
Page 7: Specifications
Specifications Dimensions Sender Unit Width X Height X Depth 14 X 1-3/4 X 4-1/8 Single Rack Unit (1RU) construction with included rack mounting brackets Receiver Unit Width X Height X Depth 10 X 1-3/8 X 3-9/16 (not including 2 mounting flanges 3/8 each added to the 10) Video Max Resolution... - Page 8 © Copyright 2006. Hall Research Technologies, Inc. All rights reserved. Products Designed and Made in the USA esearch echnologies, 1163 Warner Ave. Tustin, CA 92780 Phone: (714) 641-6607 Fax:(714) 641-6698 - 7 -...
