Napoleon Park Avenue GD82NT-PA Installation And Operating Instructions Manual

Vented natural and propane gas fireplace heaters
Hide thumbs Also See for Park Avenue GD82NT-PA:
Table of Contents

Advertisement

Quick Links

Download this manual
CERTIFIED UNDER CANADIAN AND AMERICAN NATIONAL STANDARDS: CSA 2.33, ANSI Z21.88 FOR VENTED GAS FIREPLACE HEATERS.
GD82NT-PA
NATURAL GAS
GD82PT-PA
PROPANE
CERTIFIED FOR CANADA AND UNITED STATES USING ANSI/CSA METHODS.

SAFETY INFORMATION

WARNING
!
If the information in these instructions are
not followed exactly, a fire or explosion
may result causing property damage,
personal injury or loss of life.
- Do not store or use gasoline or other
flammable vapors and liquids in the vicinity
of this or any other appliance.
- WHAT TO DO IF YOU SMELL GAS:
Do not try to light any appliance.
Do not touch any electrical switch; do
not use any phone in your building.
Immediately call your gas supplier from
a neighbour's phone. Follow the gas
supplier's instructions.
If you cannot reach your gas supplier,
call the fire department.
-
Installation
and
performed by a qualified installer, service
agency or the supplier.
Phone (705)721-1212 • Fax (705)722-6031 • www.napoleonfireplaces.com • ask@napoleon.on.ca
$10.00
INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE.
CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE.
INSTALLATION AND
OPERATING INSTRUCTIONS
service
must
Wolf Steel Ltd., 24 Napoleon Rd., Barrie, ON, L4M 4Y8 Canada /
103 Miller Drive, Crittenden, Kentucky, USA, 41030
be
Serial No.
APPLY SERIAL NUMBER LABEL FROM CARTON
MODEL NO.
1.2
1
W415-0748 / 12.12.08
W415-0748 / 12.12.08

Advertisement

Table of Contents
loading

Related Manuals for Napoleon Park Avenue GD82NT-PA

Summary of Contents for Napoleon Park Avenue GD82NT-PA

  • Page 1: Safety Information

    CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE. INSTALLATION AND OPERATING INSTRUCTIONS CERTIFIED UNDER CANADIAN AND AMERICAN NATIONAL STANDARDS: CSA 2.33, ANSI Z21.88 FOR VENTED GAS FIREPLACE HEATERS. GD82NT-PA NATURAL GAS GD82PT-PA PROPANE CERTIFIED FOR CANADA AND UNITED STATES USING ANSI/CSA METHODS.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION WARRANTY DIMENSIONS INSTALLATION OVERVIEW GENERAL INSTRUCTIONS GENERAL INFORMATION CARE OF GLASS VENTING VENTING LENGTHS AND COMPONENTS SPECIAL VENT INSTALLATIONS 2.2.1 PERISCOPE TERMINATION MINIMUM AIR TERMINAL LOCATION CLEARANCES DEFINITIONS ELBOW VENT LENGTH VALUES HORIZONTAL TERMINATION VERTICAL TERMINATION INSTALLATION WALL AND CEILING PROTECTION 3.1.1...

  • Page 3: Introduction

    1.0 INTRODUCTION WARNING • Do not operate heater before reading and understanding operating instructions. Failure to operate heater according to operating instructions could cause fire or injury. • Risk of fire or asphyxiation do not operate heater with fixed glass removed. •...

  • Page 4: Warranty

    WARRANTY NAPOLEON® products are manufactured under the strict Standard of the world recognized ISO 9001 : 2000 Quality Assurance Certificate. NAPOLEON® products are designed with superior components and materials assembled by trained crafts- men who take great pride in their work. The burner and valve assembly are leak and test-fired at a quality test station.

  • Page 5: Dimensions

    DIMENSIONS FIGURE 1.2a-c 58" 46" " " 4" DIA. 7" DIA. " 21" 5" " 2" " " 14" 24" GAS INLET 28" 28" INSTALLATION OVERVIEW FIGURE 1.3 W415-0748 / 12.12.08...

  • Page 6: General Instructions

    GENERAL INSTRUCTIONS WARNING Always light the pilot whether for the first time or if the gas supply has ran out, with the glass door opened or removed. Provide adequate accessibility clearance for servicing and operating the fireplace. Provide adequate ventilation. Never obstruct the front opening of the fireplace.

  • Page 7: General Information

    GENERAL INFORMATION FOR YOUR SATISFACTION, THIS FIREPLACE HAS BEEN TEST-FIRED TO ASSURE ITS OPERATION AND QUALITY! Maximum input is 26,000 BTU/hr for natural gas and propane. When the fi replace is installed at elevations above 4,500ft, and in the absence of specifi c recommendations from the local authority having juris- diction, the certifi...

  • Page 8: Venting

    2.0 VENTING WARNING Risk of fire, maintain specified air space clearances to vent pipe and appliance. THIS FIREPLACE USES A 4" EXHAUST / 7" AIR INTAKE VENT PIPE SYSTEM. Refer to the section applicable to your installation. For safe and proper operation of the fireplace follow the venting instruction exactly. Deviation from the minimum vertical vent length can create difficulty in burner start-up and/or carboning.
  • Page 9 WARNING The fi rst 2 feet of outer 7 “ diameter vent pipe from the appliance must be wrapped in the 1” thick insulation sleeve (supplied). Make sure the insulation is pulled down tight to the fi replace when installed. There after, a 2” clearance all around the vent pipe from combustible materials on all horizontal vent sections is required.

  • Page 10: Special Vent Installations

    SPECIAL VENT INSTALLATIONS 2.2.1 PERISCOPE TERMINATION WARNING The fi rst 2 feet of outer 7 “ diameter vent pipe from the appliance must be wrapped in the 1” thick insulation sleeve (supplied). Make sure the insulation is pulled down tight to the fi replace when installed.

  • Page 11: Minimum Air Terminal Location Clearances

    MINIMUM AIR TERMINAL LOCATION CLEARANCES FIGURE 2.3 NOTE: Clearances are in accordance with local installation codes and the requirements of the gas supplier. 12.1 W415-0748 / 12.12.08...

  • Page 12: Definitions

    DEFINITIONS For the following symbols used in the venting calculations and examples are: > - greater than > - equal to or greater than < - less than < - equal to or less than - total of both horizontal vent lengths (Hr) and offsets (Ho) in feet - combined horizontal vent lengths in feet - offset factor: .03 (total degrees of offset - 90°*) in feet - combined vertical vent lengths in feet...

  • Page 13: Horizontal Termination

    HORIZONTAL TERMINATION ) < (V Simple venting configuration (only one 90° elbow) See graph to determine the required vertical rise V for the required horizontal run H REQUIRED VERTICAL FIGURE 2.6a RISE IN FEET V 12.5 17.5 HORIZONTAL VENT RUN PLUS OFFSET IN FEET H The shaded area within the lines represents acceptable values for H and V...
  • Page 14 ) > (V Simple venting configuration (only one 90° elbow) See graph to determine the required vertical rise V for the required horizontal run H 147” FIGURE 2.6c REQUIRED VERTICAL RISE IN INCHES V 57” 19 1/2” 2’ 12.5’ 19.5’ HORIZONTAL VENT RUN PLUS OFFSET IN FEET H The shaded area within the lines represents acceptable values for H...

  • Page 15: Vertical Termination

    VERTICAL TERMINATION ) < (V Simple venting configurations. See graph to determine the required vertical rise V for the required horizontal run H REQUIRED FIGURE 2.7a VERTICAL RISE IN FEET V HORIZONTAL VENT RUN PLUS OFFSET IN FEET H The shaded area within the lines represents acceptable values for H and V For vent configurations requiring more than zero 90°...
  • Page 16 ) > (V Simple venting configurations. See graph to determine the required vertical rise V for the required horizontal run H REQUIRED VERTICAL RISE IN FEET V HORIZONTAL VENT RUN PLUS OFFSET IN FEET H The shaded area within the lines represents acceptable FIGURE 2.7c values for H and V...

  • Page 17: Installation

    3.0 INSTALLATION WARNING Follow the venting instructions exactly. All inner exhaust and outer intake vent pipe joints may be sealed using either red RTV high temp silicone sealant W573-0002 (not supplied) or black high temp mill pac W573-0007 (not supplied) with the exception of the fireplace exhaust flue collar which must be sealed using mill pac.

  • Page 18: Horizontal Installation

    3.1.1 HORIZONTAL INSTALLATION WARNING The firestop assembly must be installed with the vent shield to the top. Do not fill the cavity between the pipe and the framing with any type of material. Terminals must not be recessed into a wall or siding more than the depth of the return flange of the mounting plate.

  • Page 19: Using Flexible Venting Components

    USING FLEXIBLE VENTING COMPONENTS WARNING Do not allow the inner flex pipe to bunch up on horizontal or vertical runs and elbows. Keep it pulled tight. Spacers are attached to the inner flex pipe at predetermined intervals to maintain an even air gap to the outer flex pipe.

  • Page 20: Vertical Air Terminal Installation

    3.2.2 VERTICAL AIR TERMINAL INSTALLATION WARNING Maintain a minimum 2” space between the air inlet base and the storm collar. A. Fasten the roof support to the roof using the screws provided. The roof support is optional. In this case the venting is to be adequately supported using either an alternate method suitable to the authority having jurisdiction or the optional roof support.

  • Page 21: Using Rigid Vent Components

    USING RIGID VENT COMPONENTS The vent system must be supported approximately every 3 feet for both vertical and horizontal runs. Use Wolf Steel vent spacers W615-0033 every 3 feet and on either side of each elbow to maintain the minimum 1 1/4” clearance between the outer rigid vent pipes and inner rigid vent pipes.

  • Page 22: Vertical Venting Installation

    3.3.3 VERTICAL AIR TERMINAL INSTALLATION WARNING Maintain a minimum 2” space between the air inlet base and the storm collar. A. Move the fireplace into position. INNER PIPE B. Fasten the roof support to the roof using the screws provided. The roof support is optional. In this case the venting is to be adequately supported using either an alternate method FIGURE 3.3.3a suitable to the authority having jurisdiction or the optional roof support.

  • Page 23: Mobile Home Installation

    MOBILE HOME INSTALLATION This appliance is certified to be installed as an OEM (Original Equipment Manufacturer) installation in a manufactured home or mobile home and must be installed in accordance with the manufacturer’s instructions and the Manufactured Home Construction and Safety Standard, Title 24 CFR, Part 3280, in the United States or the Mobile Home Standard, CAN/CSA Z240 MH Series, in Canada.

  • Page 24: Minimum Clearance To Combustibles

    ELECTRICAL CONNECTION WARNING Do not use this heater if any part has been under water. Call a qualified service technician IMMEDI- ATELY to have the fireplace inspected for damage to the electrical circuit. Risk of electrical shock or explosion. Do not wire 110V to the valve or to the appliance wall switch. Incorrect wiring will damage controls.
  • Page 25 5.0 FRAMING WARNING In order to avoid the possibility of exposed insulation or vapour barrier coming in contact with the fireplace body, it is recommended that the walls of the fireplace enclosure be “finished” (ie: drywall / sheetrock), as you would finish any other outside wall of a home. This will ensure that clearance to combustibles is maintained within the cavity.

  • Page 26: Framing

    MINIMUM CLEARANCE TO COMBUSTIBLES WARNING Minimum clearance to combustibles must be maintained or a serious fire hazard could result. When constructing the enclosure allow for finishing material thickness to maintain clearances. Framing or finishing material closer than the minimums listed must be constructed entirely of non-combustible materials.
  • Page 27 WARNING Do not build into this area - it must be left clear to provide adequate clearance for the vent in this 14” wide area centered along the front of the fireplace. No combustibles are allowed. Fireplace should be in its final location before framing.

  • Page 28: Minimum Clearance To Combustible Enclosures

    MINIMUM CLEARANCE TO COMBUSTIBLE ENCLOSURES WARNING Risk of fire! The front of the fireplace must be finished with any non-combustible materials such as brick, marble, granite, etc., as long as the finishing material does not go below the specified dimension as illustrated.
  • Page 29 COMBUSTIBLE MATERIAL WARNING Finishing must be done using a non- combustible material placed flush with the front face of the unit and extending from the top of the unit such as cement board, ceramic tile, marble, etc. DO NOT USE WOOD OR DRYWALL. Any firerated drywall is not acceptable.

  • Page 30: Minimum Mantel Clearances

    MINIMUM MANTEL CLEARANCES WARNING Risk of fire, maintain all specified air space clearances to combustibles. Failure to comply with these instructions may cause a fire or cause the appliance to overheat. Ensure all clearances (i.e. back, side, top, vent, hearth, mantel, front, etc.) are clearly maintained. When using paint or lacquer to finish the mantel, the paint or lacquer must be heat resistant to prevent discolouration.

  • Page 31: Finishing

    6.0 FINISHING DOOR REMOVAL / INSTALLATION WARNING Glass may be hot, DO NOT touch glass until cooled. The door latches are part of a safety system and must be properly engaged. Do not operate the fireplace with latches disengaged. Facing and/or finishing materials must not interfere with air flow through air openings, louvres openings, operation of louvres or doors or access for service.

  • Page 32: Glass / Door Replacement

    GLASS / DOOR REPLACEMENT WARNING Do not use substitute materials. Glass may be hot, DO NOT touch glass until cooled. ● Place the door frame face down careful not to scratch the paint. 6.2.1 GASKET ● Center the gasketed glass inside the door frame with the thick 6.2.2 GLASS side of the gaket facing up.

  • Page 33: Decorative Brick Panel Installation

    DECORATIVE BRICK PANEL INSTALLATION Decorative panels may discolor after time. FIGURE 6.4.2 6.4.1 Carefully remove the glass door and all logs see STEP “FINISHING” section. 6.4.2 Remove the two screws holding the front portion of the rear air defl ector. Remove the pilot shield by removing the two screws as illustrated.

  • Page 34: Log Placement

    LOG PLACEMENT WARNING Logs must be placed in the exact location in heater. Do not change from the proper log positions, since heater may not function properly and delayed ignition may occur. The logs are fragile and should be handled with care. The individual logs can be easily identified by the numbers cast on the underside of each log.

  • Page 35: Afk / Wi Face Kit Installation

    AFK / WI FACE KIT INSTALLATION 6.7.1 Attach screw and spacer as illustrated to the bottom and top of both sides of the front housing. 6.7.2 Attach the two hooks as illustrated using the screws supplied. (The hooks must be installed on the inside of the bracket).

  • Page 36: Servicing / Replacements

    7.0 SERVICING / REPLACEMENTS WARNING Risk of fire and electrical shock. Turn off the gas and electrical power before servicing this fireplace. BLOWER REPLACEMENT WARNING Be careful not to tear the burner train gasket. A replacement gasket can be ordered from your local authorized dealer.

  • Page 37: Spark Module Battery Replacement

    SPARK MODULE BATTERY REPLACEMENT 7.3.1 Remove optional front, see “AFK / WI FACE KIT INSTALLATION” section. 7.3.2 Tilt the control panel forward and remove allowing access to the electrode box which is screwed to the base of the fi rebox. 7.3.3 Pull back on the battery compartment door latch and remove.

  • Page 38: Operation

    8.0 OPERATION WARNING If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. Always light the pilot whether for the first time or if the gas supply has ran out with the glass door opened or removed. GENERAL TRANSMITTER LAYOUT TRANSMISSION THERMOSTAT...

  • Page 39: Temperature Display

    TEMPERATURE DISPLAY ● With the system in the “OFF” position, press the 8.4.1 °F °C Thermostat Key and the Mode Key at the same time to change from degrees F to C. ● Look at the LCD screen on the Transmitter to 8.4.2 verify that a C or F is visible to the right of the Room Temperature display.

  • Page 40: Fan Speed

    FAN SPEED If the appliance is equipped with a hot air circulating fan, °F °F the speed of the fan can be controlled by the remote system. The fan speed can be adjusted through six (6) speeds. ● 8.8.1 Use the Mode key to guide you to the fan control icon.

  • Page 41: In The Event Of A Power Failure

    8.12 IN THE EVENT OF A POWER FAILURE If the receiver is equipped with batteries they will enable flame height control, ON/OFF or thermostat function to control the fireplace during a power failure. Refer to “FIREPLACE OPERATION” section when communica- tions between receiver and transmitter have been lost.

  • Page 42: Operating Instructions

    9.0 OPERATING INSTRUCTIONS When lit for the first time, the fireplace will emit an odor for a few hours. This is a normal temporary condition caused by the "burn-in" of paints and lubricants used in the manufacturing process and will not occur again. After extended periods of non-operation such as following a vacation or a warm weather season, the fireplace may emit a slight odor for a few hours.

  • Page 43: Adjustments

    10.0 ADJUSTMENTS 10.1 PILOT BURNER ADJUSTMENT Adjust the pilot screw to provide properly sized flame. Turn in a clockwise PILOT direction to reduce the gas flow. BURNER THERMOPILE THERMOCOUPLE Inlet pressure can be checked by turning screw (A) counter-clockwise until loosened and then placing pressure gauge tubing over the test point.

  • Page 44: Maintenance

    11.0 MAINTENANCE MAINTENANCE MAINTENANCE WARNING MAINTENANCE Turn off the gas and electrical power before servicing the appliance. CAUTION: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. Verify proper operation after servicing. This fireplace and its venting system should be inspected before use and at least annually by a qualified service person.

  • Page 45: Replacement Parts

    12.0 REPLACEMENT PARTS WARNING Failure to position the parts in accordance with this manual or failure to use only parts specifically approved with this appliance may result in property damage or personal injury. ** This is a fast acting thermocouple. It is an integral safety component. Replace only with a fast acting thermocouple supplied by Wolf Steel Ltd.
  • Page 46 COMPONENTS REF NO. GD82 DESCRIPTION W475-0402 PANEL, RIGHT FIBRE W475-0403 PANEL, LEFT FIBRE W225-0240 DOOR W300-0082 GLASS W500-0205 RESTRICTOR W010-1799 FIRESTOP SPACER W660-0069 FAN CONTROL MODULE FLEXIBLE VENT KITS REF NO. GD82 DESCRIPTION GD220 (5 FT) W010-0397 4” FLEXIBLE VENT PIPE - (5 FT) C/W SPACERS W410-0017 7”...
  • Page 47 11** W415-0748 / 12.12.08...

  • Page 48: Trouble Shooting Guide

    13.0 TROUBLE SHOOTING GUIDE WARNING Always light the pilot whether for the first time or if the gas supply has ran out, with the glass door open or removed. SYMPTOM PROBLEM TEST SOLUTION - Remove blockage. In really cold conditions, ice buildup Main burner Blockage in vent.
  • Page 49 SYMPTOM PROBLEM TEST SOLUTION Main burner goes out; Pilot flame is not large enough or - Turn up the pilot flame. pilot stays on. not engulfing the thermopile. - Replace pilot assembly. Thermopile shorting. - Clean thermopile connection tot he valve. Reconnect. - Replace thermopile / valve.
  • Page 50 SYMPTOM PROBLEM TEST SOLUTION Pilot goes out while Gas piping is undersized. - Turn on all gas appliances and see if pilot flame flutters, standing: Main burner diminishes or extinguishes, especially when main burner is in “OFF” position. ignites. Monitor appliance supply working pressure. - Check if supply piping size is to code.

  • Page 51: Service History

    14.0 SERVICE HISTORY 43.1 W415-0748 / 12.12.08...

  • Page 52: Notes

    15.0 NOTES 44.1 W415-0748 / 12.12.08...
