Napoleon Tureen GD82NT-T Installation And Operation Instructions Manual

Napoleon fireplaces installation and operation instructions gas fireplace gd82nt-t , gd82pt-t
Hide thumbs Also See for Tureen GD82NT-T:
Table of Contents

Advertisement

Quick Links

Download this manual
INSTALLER: THESE INSTRUCTIONS MUST BE CONVEYED TO AND REMAIN WITH THE HOMEOWNER.
CERTIFIED UNDER CANADIAN AND AMERICAN NATIONAL STANDARDS: CSA 2.33, ANSI Z21.88 FOR VENTED GAS FIREPLACE HEATERS.
GD82NT-T
NATURAL GAS
GD82PT-T
PROPANE
CERTIFIED FOR CANADA AND UNITED STATES USING ANSI/CSA METHODS.
SAFETY INFORMATION
WARNING: If the information in these
instructions are not followed exactly, a fire
or explosion may result causing property
damage, personal injury or loss of life.
- Do not store or use gasoline or other
flammable vapors and liquids in the vicinity
of this or any other appliance.
- WHAT TO DO IF YOU SMELL GAS:
Do not try to light any appliance.
Do not touch any electrical switch; do
not use any phone in your building.
Immediately call your gas supplier from
a neighbour's phone. Follow the gas
supplier's instructions.
If you cannot reach your gas supplier,
call the fire department.
-
Installation
and
performed by a qualified installer, service
agency or the supplier.
Wolf Steel Ltd., 24 Napoleon Rd., Barrie, ON L4M 4Y8 Canada • (705)721-1212 • fax(705)722-6031
$10.00
OPERATION INSTRUCTIONS
service
must
be
www.napoleonfireplaces.com • ask@napoleon.on.ca
INSTALLATION AND
1
W415-0583 / B / 05.23.07
W415-0583 / B / 05.23.07

Advertisement

Table of Contents
loading

Related Manuals for Napoleon Tureen GD82NT-T

Summary of Contents for Napoleon Tureen GD82NT-T

  • Page 1 INSTALLER: THESE INSTRUCTIONS MUST BE CONVEYED TO AND REMAIN WITH THE HOMEOWNER. CERTIFIED UNDER CANADIAN AND AMERICAN NATIONAL STANDARDS: CSA 2.33, ANSI Z21.88 FOR VENTED GAS FIREPLACE HEATERS. GD82NT-T NATURAL GAS GD82PT-T PROPANE CERTIFIED FOR CANADA AND UNITED STATES USING ANSI/CSA METHODS.

  • Page 2: Table Of Contents

    TABLE of CONTENTS PG 2-5 INTRODUCTION Warranty Dimensions General Instructions General Information Care of Glass & Plated Parts VENTING Vent lengths Venting Specifi cations Air Terminal Locations 10-15 INSTALLATION/FRAMING Wall & Ceiling Protection Using Flexible Vent Components Fireplace Vent Connection Using Rigid Vent Components Gas Installation Restricting Vertical Vents...
  • Page 3 NAPOLEON® products are manufactured under the strict Standard of the world recognized ISO 9001 : 2000 Quality Assurance Certifi cate. NAPOLEON® products are designed with superior components and materials, assembled by trained craftsmen who take great pride in their work. The burner and valve assembly are leak and test-fi red at a quality test station. The complete fi...

  • Page 4: General Instructions

    46" " 5" 24" 28" GENERAL INSTRUCTIONS THIS GAS FIREPLACE SHOULD BE INSTALLED AND SER- VICED BY A QUALIFIED INSTALLER to conform with local codes. Installation practices vary from region to region and it is important to know the specifi cs that apply to your area, for example: in Massachusetts State: •...

  • Page 5: Venting

    This fi replace may be installed in an aftermarket permanently located, manufactured (mobile) home, where not prohibited by local codes. This fi replace is only for use with the type of gas indicated on the rating plate. This fi replace is not convertible for use with other gases, unless a certifi...
  • Page 6 DEFINITIONS for the following symbols used in the venting calculations and examples are: > - greater than > - equal to or greater than < - less than < - equal to or less than - total of both horizontal vent lengths (H ) in feet - combined horizontal vent lengths in feet - offset factor: .03(total degrees of offset - 90°*) in...
  • Page 7 TOP EXIT / HORIZONTAL TERMINATION when (H ) > (V Simple venting confi guration (only one 90° elbow) FIGURE 6 See graph to determine the required verti- cal rise V for the required horizontal run REQUIRED VERTICAL RISE IN INCHES HORIZONTAL VENT RUN PLUS OFFSET IN FEET The shaded area within the lines represents acceptable values for H...
  • Page 8 TOP EXIT VERTICAL TERMINATION when (H ) < (V See graph to determine the required vertical rise for the required horizontal run H FIGURE 9 TOP VERTICAL TERMINATION when (H ) > (V Simple venting confi gurations FIGURE 10 See graph to determine the required vertical rise V required horizontal run H MAXIMUM VERTICAL...
  • Page 9 FIGURE 12 W415-0583 / B / 05.23.07...

  • Page 10: Wall & Ceiling Protection

    WALL AND CEILING PROTECTION For optimum performance it is recommended that all horizontal runs have a minimum ¼ inch rise per foot using For safe and proper operation of the fi replace, follow the venting instructions exactly. HORIZONTAL TERMINATION: A clearance to combustibles of 2" must be maintained during the fi rst 24” of venting when penetrating combustible walls.

  • Page 11: Using Flexible Vent Components

    USING FLEXIBLE VENT COMPONENTS Use only approved aluminum fl exible liner kits marked: “Wolf Steel Approved Venting” as identifi ed by the stamp only on the 7” outer liner. For safe and proper operation of the fi replace, follow the venting instructions exactly.

  • Page 12: Fireplace Vent Connection

    FIREPLACE VENT CONNECTION 1. Install the 4” diameter aluminium fl exible liner to the fi replace. Secure with 3 screws and fl at washers. Seal the joint and screw holes using the high temperature sealant (W573-0007 not provided). 2. Install the 7” diameter aluminium fl exible liner to the fi...

  • Page 13: Gas Installation

    6. Remove nails from the shingles, above and to the sides of the chimney. Place the fl ashing over the air terminal and slide it underneath the sides and upper edge of the shingles. Ensure that the air terminal is properly centred within the fl ash- ing, giving a 3/4”...

  • Page 14: Framing

    FRAMING It is best to frame your fi replace after it is positioned and the vent system is installed. Use 2x4’s and frame to local build- ing codes. Note: In order to avoid the possibility of exposed insulation or vapour barrier coming in contact with the fi replace body, it is recommended that the walls of the fi...

  • Page 15: Electrical Connection

    Combustible mantle clearance can vary according to the mantle depth. Use the graph to help evaluate the clearance needed. FIGURE 32 MANTLE WIDTH ELECTRICAL CONNECTION Do NOT use the fi replace if any part has been under water. Call a qualified service technician IMMEDIATELY to have the fi...

  • Page 16: Finishing / Servicing

    FINISHING / SERVICING OPTIONAL FRONT REMOVAL 1a. Rectangular Front Removal Pull on the top of the optional front away from the fi replace until the male portion of the latch disengages. Tilt forward slightly and lift from the 2 shoulder screws near the bottom. 1b.
  • Page 17 4. After rocks have been placed on the bowl, add the remaining rock by inserting the pin into the hole shown in Fig 40. FIGURE 39 TOP SIDE OF ROCK CLUSTER CURVED DECORATIVE PANEL REMOVAL FIGURE 40 EDGES BOTTOM EDGES Insert a gloved hand behind the top right hand corner of the panel and pull forward gently.

  • Page 18: Battery Replacement

    BATTERY REPLACEMENT 1. Remove the optional front. (Instructions on Pg. 17) 2. Tilt the control panel forward allowing access to the electode box which is screwed to the base of the fi rebox. (Fig. 43) BURNER BOWL W415-0583 / B / 05.23.07 FIGURE 43 BURNER CONTROL PANEL...

  • Page 19: Night Light

    NIGHT LIGHT Yo u r comes equipped with our Night Light light has been pre-wired and is controlled from the remote control. If in the event the lamp or lens needs to be replaced, follow the instructions below. Unplug the wire harness / transformer from the junction box inside the fi...

  • Page 20: Hand Held Remote Operation

    HAND HELD REMOTE OPERATIONS 1. ON / OFF To turn the fi replace on press the ON / OFF button, the fi replace will always light at maximum fl ame setting. Press the ON / OFF button again to turn the fi replace off. 2.
  • Page 21 CHILD SAFETY LOCK-OUT This function is to deactivate con- trol button. The function is active when the lock icon is lit. To activate this function press the ON / OFF button and within one second the UP key To reactivate the remote control buttons follow the same sequence, press ON / OFF key and within one second press the UP button.
  • Page 22 FIGURE 57 W415-0583 / B / 05.23.07...

  • Page 23: Operating Instructions

    When lit for the fi rst time, the fi replace will emit a slight odour for a few hours. This is a normal temporary condition caused by the curing of paints and lubricants used in the manufactur- ing process and will not occur again. Simply open a window to suffi...

  • Page 24: Adjustments

    TURN OFF THE GAS AND ELECTRICAL POWER BEFORE SERVICING THE FIREPLACE. CAUTION: Label all wires prior to disconnection when servic- ing controls. Wiring errors can cause improper and danger- ous operation. Verify proper operation after servicing. This fi replace and its venting system should be inspected before use and at least annually by a qualifi...

  • Page 25: Conversion Kit

    CONVERSION KIT This conversion kit shall be installed by a qualifi ed service agency in accordance with the manufacturer’s instructions and all applicable codes and requirements of the authority having jurisdiction. If the information in these instruction is not followed exactly, a fi re, explosion or production of carbon monoxide may result causing property damage, per- sonal injury or loss of life.

  • Page 26: Replacements

    Contact your dealer for questions concerning prices and avail- ability of replacement parts. Normally all parts can be ordered through your Napoleon® dealer or distributor. When ordering replacement parts always give the following information: FOR WARRANTY REPLACEMENT PARTS THE ORIGINAL INVOICE WILL BE REQUIRED TO HONOUR THE CLAIM REPLACEMENT PARTS PART NO.
  • Page 27 0:00 FEATURE SELECT ON/OFF W415-0583 / B / 05.23.07...

  • Page 28: Trouble Shooting Guide

    TROUBLE SHOOTING GUIDE EFORE ATTEMPTING TO TROUBLESHOOT PURGE YOUR UNIT AND INITIALLY LIGHT THE PILOT AND THE MAIN BURNER WITH THE GLASS DOOR OPEN SYMPTOM PROBLEM Main burner fl ame Blockage in vent. is a blue, lazy, transparent fl ame. Incorrect installation.
  • Page 29 SYMPTOM PROBLEM Themostat or switch is defec- Pilot burning; no gas tive. to main burner; gas Wall switch wiring is defective. knob is on ‘HI’; wall switch / thermostat is on. Main burner orifi ce is plugged. Faulty valve. Pilot goes out while Gas piping is undersized.
  • Page 30 W415-0583 / B / 05.23.07...
  • Page 31 NOTES W415-0583 / B / 05.23.07...
