FM600 Series – Small Size. Big Power.
FM600 Series – Small Size. Big Power.
• Space saving, lightweight office design
• High print speed, easy loading, and large media rolls
• Variable media widths (1" - 4")
• Larger capacity label/tag printing that's extremely affordable
• Meets customer demands with speed and flexibility
PRINTER SPECIFICATIONS INCLUDE:
Models FM602, FM612, FM603
Speed FM602 and FM612: Variable 2 to 6 ips
FM603: Variable 2 to 4 ips: Up to 5 ips with PAL
Print Resolution FM602 and FM612: 203 dpi
FM603: 300 dpi
Fonts PPLA & PPLB & PPLZ
International character sets standard
5 alpha-numeric fonts from 0.049" (H) to 0.23" (H)
All fonts are expandable up to 24x24
4 directions 0° to 270° rotation
Soft fonts are downloadable
PAL
Sans Serif, OCR B
Smooth scaling fonts
Barcodes PPLA & PPLB & PPLZ
Code 39, Extended Code 39, Code 93, Code 128
UCC, Code 128 (Subset A, B, C), Codabar, Interleaved 2 of 5,
EAN-8 2&5 add on, EAN-13, EAN-128, UPC, UPC-A, E 2&5
add on, POSTNET, German POST, Matrix25, Maxicode,
PDF- 417, Datamatrix
PAL
Code 39, Code 93, Code 128 (Subset A, B, C),
Codabar, Interleaved 2 of 5, EAN-8, EAN-13,
UPC-A & E, POSTNET, Maxicode, PDF-417,
MSI Plessy, Datamatrix, RSS
Graphics PPLA & PPLB & PPLZ
PCX bit map, GDI graphics
PAL
PCX, BMP
Print Width Max 4.0 inches
Print Method Direct Thermal or Thermal Transfer
Media Size Max width: 4.3 inches (110 mm)
Min Width: 0.6 inches (15mm)
Thickness: 0.0025 inches to 0.01 inches
(0.0635mm to 0.254mm)
Max Roll size OD: 6 inches (152mm)
Core size: 1" or 3" ID
Media Type Roll-Feed, Die-cut Continuous, Fan-fold, tags, ticket,
plain paper, fabric, wristband
Corporate Headquarters
4765 Calle Quetzal, Camarillo, CA 93012
(805) 388-5799 PH
(805) 484-5282 FX
Media Sensor Type
Ribbon
Memory/Buffer
Software
Emulation
Interface
Physical/Electrical
Environmental
Options
Warranty
All products are trademarks of their respective owners. Specifications are subject to change without notice.
Some models and features may not be currently available. Some options and features are not available on all models.
Charlotte Operation
4216 Stuart Andrew Blvd., Charlotte, NC 28217
(704) 523-8500 PH
(704) 525-6104 FX
http://www.amtdatasouth.com
Reflective Sensor (Adjustable)
Wax, Wax/Resin, Resin
Ribbon Width: 1" to 4" (Core Adapter available for
narrow widths)
Max OD: 2.67" (68mm)
Length: 360M wax, 300M Resin
Core size: 1" core ID with notches
2MB DRAM
1MB Flash ROM
Windows Driver (98/NT/2000/XP)
Label Creation Software included (not available with PAL)
PAL – FeatureMan, FlashWiz, ComLog Utilities
Multiple Industry Emulations
FM 602 and FM 603: A & B Industry Emulations, PAL
FM 612: Z Industry Emulation
FM602, FM603: RS-232 serial, Centronics Parallel
FM612: RS-232 serial, Centronics Parallel, USB
12.4" x 9.1" x 8.6"
(314mm x 231mm x 218mm) (W x H x D)
9.3 lbs (4.2kg)
110 to 240 VAC +/-10% m (Internal Universal Power Supply)
CE, UL, CUL, FCC, CCC
44°F to 100°F (4°C to 38°C)
10 to 90% non condensing
Cutter
Peel and Dispense,
Real Time Clock
RS-232 Cable
Standalone keyboard with LCD and Format storage
USB interface (External cable)
LAN print server (External)
One year Parts and Labor, Return to Depot
Six months Printhead
