Summary of Contents for CHIEF PSS2000
- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S PLASMA SWIVEL STAND Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description PSS2000...
- Page 2 A WARNING alerts you to the possibility of installer’s responsibility to make sure the combined weight of serious injury or death if you do not follow the instructions. all components located on the PSS2000 does not exceed 150 lbs (68.04 kg). DIMENSIONS 45°...
- Page 3 Installation Instructions PSS2000 LEGEND Tighten Fastener Pencil Mark Apretar elemento de fijación Marcar con lápiz Befestigungsteil festziehen Stiftmarkierung Apertar fixador Marcar com lápis Serrare il fissaggio Segno a matita Bevestiging vastdraaien Potloodmerkteken Serrez les fixations Marquage au crayon Loosen Fastener Drill Hole Aflojar elemento de fijación...
- Page 4 PSS2000 Installation Instructions TOOLS REQUIRED FOR INSTALLATION 1/2" (12.7mm) PARTS A (1) B (5) D (1) C (1) 5/32" 3/16"...
- Page 5 Remove slide from base by removing four button head cap NOTE: screws and four flat washers. (See Figure 3) PSS2000 ships assembled for displays 30" in height or less, and lowered to its minimum height. Remove faceplate from slide by removing two flat washers and two lock nuts.
- Page 6 In addition, the pin and nut may be removed from the upper holes Locate a flat dry surface on which to mount the PSS2000 assembly. and moved to the lower holes for use as a more permanent locking device.
- Page 7 Tighten the four height adjustment screws. (See Figure 2) Adjusting Stand Tension Check swivel tension while display is attached to the stand. If tension adjustment is necessary, slightly tighten or loosen adjustment screws on bottom of PSS2000. (See Figure 6) Swivel Tension Adjustment Screws Figure 8...
- Page 8 Europe A Fellenoord 130 5611 ZB EINDHOVEN, The Netherlands P +31 (0)40 2668620 F +31 (0)40 2668615 Chief Manufacturing, a division of Asia Pacific A Room 24F, Block D, Lily YinDu International Building Milestone AV Technologies LuoGang, BuJi Town, Shenzhen, CHINA.
