I N S T A L L A T I O N I N S T R U C T I O N S
HEAVY DUTY FIXED WALL MOUNT
Model: PSH-2000
Specifications:
•
Accomodates Akira and Orion 84" displays
without interface bracket; accomodates other
large flat panel displays with optional interface
bracket.
NOTE: Interface bracket, if required, will result in
additional installation depth. Contact Chief for
details.
•
Designed for installation on dual wood studs (16"
or 24" on center).
•
Weight capacity of 250 lbs (113 kg).
BEFORE YOU BEGIN
CAUTION: To prevent damage to your display and this unit, which could affect or void the factory warranty,
thoroughly study all instructions and illustrations before installation. Pay particular attention to the Warnings and
Cautions in this document.
•
If you have any questions about this installation, contact Chief Manufacturing at 1-800-582-6480 or 952-894-
6280.
CHIEF MANUFACTURING INC.
1-800-582-6480 952-894-6280 FAX 952-894-6918
8401 EAGLE CREEK PARKWAY, STE 700
SAVAGE, MINNESOTA 55378 USA
8805-000067 Rev F
©2006 Chief Manufacturing
www.chiefmfg.com
01/06

Advertisement

loading
Need help?

Need help?

Do you have a question about the PSH-2000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for CHIEF PSH-2000

Summary of Contents for CHIEF PSH-2000

  • Page 1 Pay particular attention to the Warnings and Cautions in this document. • If you have any questions about this installation, contact Chief Manufacturing at 1-800-582-6480 or 952-894- 6280. CHIEF MANUFACTURING INC. 1-800-582-6480 952-894-6280 FAX 952-894-6918...
  • Page 2 Model: PSH-2000 IMPORTANT WARNINGS AND CAUTIONS! WARNING: A WARNING alerts you to the possibility of serious injury or death if you do not follow the instructions. CAUTION: A CAUTION alerts you to the possibility of damage or destruction of equipment if you do not follow the corresponding instructions.

  • Page 3: Tools Required For Installation

    KEY, Hex, 3/16" KEY, Hex, 1/8" BOLTS, Hex Head Lag, 5/16" x 2-1/2" (Required, not supplied) WASHER, Flat, Machine, 5/16" (Required, not supplied) (20) (30) Figure 1: Parts Model: PSH-2000 Table 1: Parts (40) (50) (60) (70) (80) (90) (100)

  • Page 4: Assembly And Installation

    1. Install the optional interface bracket to display according to the instructions provided with the interface bracket. NOTE: Mounting buttons are pre-installed on optional interface bracket. PSH-2000 items (80) through (120), and key (140)(See Figure 1), will not be used with optional interface bracket. (120)
  • Page 5 (10) with screws (130) (See Figure 7). Ensure lip of support (30) covers edge of plate (10). 2. Repeat for other 3 corners. 3. Once all screws (130) are installed, tighten securely. (40) (60) (4 Places) (30) Figure 7: Side Support Assembly Model: PSH-2000 (130) (10)
  • Page 6 Model: PSH-2000 INSTALL MOUNT TO WALL 1. Determine approximate mounting location, keeping in mind the display size. WARNING: The mount must be installed on two or three wood studs (or other equivalent vertical or horizontal supporting framework). Do not mount to single wood studs.
  • Page 7 3. Tighten all 16 screws (130) securely. (130) (16 Places) Figure 12: Installation on Inside Mounting Holes Mounting Buttons (6 buttons shown; 4 buttons similar) Figure 13: Installation on Middle Mounting Holes Model: PSH-2000 (130) (16 Places) (130) (16 Places)

  • Page 8: Install Display

    Model: PSH-2000 INSTALL DISPLAY WARNING: Display is very heavy! Ensure display can be safely lifted and maneuvered as required to install on mount. Failure to take adequate precautions can result in serious personal injury or damage to equipment! 1. Ensure latches (40) are in fully open (raised) positions (See Figure 6).
