38CKX 50 Hz
Air Conditioner
38CKX Sizes 024 thru 060
Model 38CKX 50 Hertz Energy-
Efficient Air Conditioner incorporates
innovative technology to provide
reliable summer cooling performance.
Built into these units are the features
most desired by consumers today,
including SEER ratings of up to 10.0
when used with components
designated by manufacturer.
AVAILABLE OPTIONS
Electrical Range — Units are offered
in 230v single phase for 024 and 036
sizes. Three-phase units are available
in 036, 048, and 060 sizes in 400v.
Wide Range of Sizes — The 38CKX
is available in nominal sizes 024, 036,
048, and 060 to meet the needs of
residential and light commercial
applications.
Weather Armor II Cabinet — The
steel is protected with a galvanize
coating, and treated with a layer of zinc
phosphate. A modified polyester
powder coating is then applied and
baked on, providing each unit with a
hard, smooth finish that will last for
many years.
All screws on cabinet exterior are
coated for a long-lasting, rust-resistant,
quality appearance.
Totally Enclosed Fan Motor —
Provides greater reliability under
adverse conditions and dependable
performance for many years. The
permanent-split-capacitor-type motor
was designed for optimum efficiency.
The motor was then qualified under
extreme conditions to help ensure a
long, reliable life.
Form 38CKX-C3PD
Advertisement
Table of Contents
Related Manuals for Carrier 38CKX
Summary of Contents for Carrier 38CKX
- Page 1 230v single phase for 024 and 036 sizes. Three-phase units are available in 036, 048, and 060 sizes in 400v. Wide Range of Sizes — The 38CKX is available in nominal sizes 024, 036, 048, and 060 to meet the needs of residential and light commercial applications.
-
Page 2: Model Number Nomenclature
The 38CKX has sweat field Standard Features — All units are patio areas and foliage. Heat pump style connections. Valves are externally... - Page 3 Accessories PART NO. DESCRIPTION KSAHS1001AAA Start Assist — Capacitor/Relay — Size 024-71 KSAHS1301AAA Start Assist — Capacitor/Relay — Sizes 036-71 KAACS0101PTC Start Assist — PTC — Size 024-71 KAACS0201PTC Start Assist — PTC — Size 036-71 KAALS0101LLS* Liquid Solenoid Valve — All Sizes KSACY0101AAA Cycle Protector —...
- Page 4 Accessory description and usage (Listed alphabetically) Coastal Filter A mesh screen inserted under the top cover and inside the base pan to protect the condenser coil from salt damage without restricting airflow. SUGGESTED USE: In geographic areas where salt damage could occur. Compressor Start Assist —...
-
Page 5: Electrical Data
Electrical data FIELD WIRE SIZE MAX FUSE† Wire Length OPER VOLTS* COMPRESSOR UNIT CKT BKR Size SIZE V/PH AMPS 60°C/75°C** 60°C/75°C‡ 024-71 68.0 11.6 0.65 15.2 14/14 16.2/15.2 230-1 036-71 94.0 17.7 0.65 22.8 12/12 16.8/15.8 036-91 42.0 0.40 14/14 61.6/58.5 048-91 400-3... - Page 6 Dimensions...
-
Page 7: Combination Ratings
Combination ratings COOLING CAP @ 95°F (35°C) COOLING CAP@115°F (46°C) OUTDOOR NOMINAL AIRFLOW Rated Capacity Rated Capacity UNIT Power Rated Power SIZE/SERIES INDOOR UNIT BTUH BTUH FB4ASX024* 23,000 2.75 9.00 19,900 3.03 024-71 FB4ASX030 23,600 2.74 9.10 19,948 3.02 FB4ASX036* 1200 35,000 10.3... - Page 8 Detailed cooling capacities* (S.I.) CONDENSER ENTERING AIR TEMPERATURES °C EVAP. Capacity† Capacity† Capacity† Capacity† Capacity† Capacity† Capacity† Sys. Sys. Sys. Sys. Sys. Sys. Sys. (KW) (KW) (KW) (KW) (KW) (KW) (KW) Power Power Power Power Power Power Power Total Sens‡ KW** Total Sens‡...
- Page 9 Detailed cooling capacities* (S.I.) continued CONDENSER ENTERING AIR TEMPERATURES °C EVAP. Capacity† Capacity† Capacity† Capacity† Capacity† Capacity† Capacity† Comp. Comp. Comp. Comp. Comp. Comp. Comp. (KW) (KW) (KW) (KW) (KW) (KW) (KW) Power Power Power Power Power Power Power Total Sens‡ KW** Total Sens‡...
- Page 10 Condenser only ratings (S.I.) CONDENSER ENTERING AIR TEMPERATURES °C °C 38CKX024-71 6.03 5.69 5.34 5.00 4.66 4.33 4.00 3.67 3.36 –2 1.77 1.85 1.92 1.98 2.03 2.07 2.10 2.12 2.13 35.1 38.9 42.7 46.5 50.3 54.0 57.7 61.4 65.1 6.52 6.16 5.80 5.44...
- Page 11 Condenser only ratings (S.I.) continued CONDENSER ENTERING AIR TEMPERATURES °C °C 38CKX060-91 15.4 14.9 14.4 13.8 13.3 12.8 12.2 11.7 11.1 –2 3.48 3.78 4.12 4.49 4.88 5.29 5.72 6.17 6.63 34.6 38.7 42.9 47.0 51.2 55.3 59.3 63.2 67.0 16.4 15.9 15.3...
-
Page 12: Guide Specifications
Indianapolis, IN 46231 12-99 Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations Book Page 12 Catalog No. 003-800 Printed in U.S.A. PC 101 Form 38CKX-C3PD 3a 1a 2a Replaces: 38CKX-C2PD...
