Carrier 38CKS Product Data

60 hz air conditioner sizes 018 thru 060
Hide thumbs Also See for 38CKS:
Table of Contents

Advertisement

Quick Links

See also: Owner's Manual
Copyright 1999 Carrier Corporation
Product
Data
60 Hz Air Conditioner
Sizes 018 thru 060
The 38CKS Air Conditioner is
designed for superior performance
durability in harsh environments. The
product achieves up to 11 SEER ratings
when used with manufacturer specified
components. The product is available in
seven standard nominal sizes ranging
from 018 to 060 for residential and light
commercial applications. All models are
listed with UL, cUL, CEC, ARI, CSA,
and PFS.

FEATURES/BENEFITS

ArmorPlate Condenser Coil —The
outdoor coil lasts three times longer
than other standard condenser coils by
utilizing a special ArmorPlate
protective coating on the coil.
Heavy Duty Inlet Grille —The coil is
protected with an enhanced coil guard.
With maximum horizontal opening of
10.5 mm and construction of coated
wire, the guard helps to protect from
inclement weather (hail), vandalism,
and incidental damage.
Cabinet Protection —Provides
superior durability through added paint
coverage on all sheet metal
components. Steel is protected with a
galvanized coating and treated with a
layer of zinc phosphate. A modified
polyester powder coating is then
applied and baked on, providing each
unit with a hard, smooth finish that will
last for many years. Additional
attention to detail, such as the motor
cap, protects the fan motor from
exposure to the elements. Coil
isolators protect the unit from internal
scratches during installation and
shipping. All screws on cabinet
exterior are coated for a long-lasting
rust-resistance.
38CKS
Form 38CKS-1PD

Advertisement

Table of Contents
loading

Related Manuals for Carrier 38CKS

Summary of Contents for Carrier 38CKS

  • Page 1 38CKS Product 60 Hz Air Conditioner Data Sizes 018 thru 060 The 38CKS Air Conditioner is designed for superior performance durability in harsh environments. The product achieves up to 11 SEER ratings when used with manufacturer specified components. The product is available in...

  • Page 2: Model Number Nomenclature

    REGISTERED QUALITY SYSTEM CERTIFICATION APPLIES ONLY WHEN THE COMPLETE SYSTEM IS LISTED WITH ARI. Model number nomenclature 38CKS Electric Air Conditioner Packaging Series Nominal Capacity 018 — 18,000 Btuh 042 — 42,000 Btuh 024 —...

  • Page 3: Physical Data

    Physical data UNIT SIZE 018-30 024-30 030-30 036-30 042-30 048-30 060-30 OPERATING WT (Lb) COMPRESSOR Bristol Recip Bristol Recip Bristol Recip Bristol Recip Copeland Recip Millennium Millennium Manufacturer & Type Scroll Scroll REFRIGERANT Control ® AccuRater (Bypass Type) Charge (Lb) @ 15 Ft 3.30 3.65 4.25...
  • Page 4 Accessories PART NO. DESCRIPTION KAATD0101TDR Time-Delay Relay — All Sizes P251-0083 (RCD) Low-Ambient Controller — Sizes 030–060 KSALA0201R22 Low Ambient Kit — All Sizes 32LT660004 (RCD)* MotorMaster® Control — Sizes 024–060 230v MotorMaster® Control — Sizes 018 Ball Bearing Fan Motor — Sizes 018 HC34GE232 Ball Bearing Fan Motor —...
  • Page 5 THERMOSTAT PKG. DESCRIPTION TSTATCCPRH01-B Thermidistat Control, Programmable/Non-Programmable Thermostat with Humidity Control TSTATCCNAC01-B Thermostat, Auto Changeover, Non-Programmable, °F/°C, 1-Stage Heat, 1-Stage Cool TSTATCCPAC01-B Thermostat, Auto Changeover, 7-Day Programmable, °F/°C, 1-Stage Heat, 1-Stage Cool TSTATCCBAC01 Builder’s Thermostat, Manual Changeover, Non-Programmable, °F/°C, 1-Stage Heat, 1-Stage Cool TSTATXXSEN01-B Outdoor Air Temperature Sensor TSTATXXNBP01...
  • Page 6 Accessory description and usage (continued) Evaporator Freeze Thermostat An SPST temperature actuated switch which stops unit operation when evaporator reaches freeze-up conditions. SUGGESTED USE: All units where Winter Start Control has been added. Filter Drier A device for removing contaminants from refrigerant circulating in an air conditioner: 1-direction flow. SUGGESTED USE: All split-system air conditioners.

  • Page 7: Electrical Data

    Electrical data 60°C 75°C 60°C 75°C OPER VOLTS* COMPRESSOR UNIT WIRE WIRE LENGTH LENGTH MAX FUSE** OR SIZE-SERIES V/PH SIZE† SIZE† (Ft)‡ (Ft)‡ CKT BKR AMPS 018-30 48.0 12.1 024-30 60.0 11.6 15.5 030-30 73.0 14.8 19.3 208-230-1 036-30 82.0 16.0 21.4 042-30...
  • Page 8 Dimensions—38CKS...
  • Page 9 Combination ratings SEER FACTORY- SUPPLIED Carrier Gas INDOOR TOT. CAP. ENHANCE- Standard Furnace or Accessory UNIT MODEL BTUH MENT Rating TDR† TXV‡ EERA SIZE-SERIES CC5A/CD5AA018* 17,200 NONE — 10.00 10.00 9.40 CC5A/CD5AA024 17,600 NONE 10.00 10.50 10.50 9.65 CC5A/CD5AW024 17,600 NONE 10.00...

  • Page 10: Combination Ratings Continued

    Combination ratings continued SEER FACTORY- SUPPLIED Carrier Gas INDOOR TOT. CAP. ENHANCE- Standard Furnace or Accessory UNIT MODEL BTUH MENT Rating TDR† TXV‡ EERA SIZE-SERIES CC5A/CD5AW030 22,600 11.00 — 11.00 10.50 CJ5A/CK5A/CK5BA024 22,400 10.50 — 10.50 10.45 CJ5A/CK5A/CK5BA030 22,600 11.00 —...
  • Page 11 Combination ratings continued SEER FACTORY- SUPPLIED Carrier Gas INDOOR TOT. CAP. ENHANCE- Standard Furnace or Accessory UNIT MODEL BTUH MENT Rating TDR† TXV‡ EERA SIZE-SERIES COILS + 58U(H,X)V080-16 VARIABLE SPEED FURNACE CC5A/CD5AW030 28,000 10.50 — 10.50 10.10 030-30 CD5AW036 29,000 11.00...
  • Page 12 Combination ratings continued SEER FACTORY- SUPPLIED Carrier Gas INDOOR TOT. CAP. ENHANCE- Standard Furnace or Accessory UNIT MODEL BTUH MENT Rating TDR† TXV‡ EERA SIZE-SERIES CD5AW036 33,400 10.50 — 10.50 10.00 CJ5A/CK5A/CK5BA042 33,400 10.80 — 10.80 10.10 CJ5A/CK5A/CK5BW036 33,400 10.50 —...
  • Page 13 Combination ratings continued SEER FACTORY- SUPPLIED Carrier Gas INDOOR TOT. CAP. ENHANCE- Standard Furnace or Accessory UNIT MODEL BTUH MENT Rating TDR† TXV‡ EERA SIZE-SERIES CJ5A/CK5A/CK5BA042 40,000 10.50 — 10.50 9.70 CJ5A/CK5A/CK5BW048 40,000 10.70 — 10.70 9.80 COILS + 58U(H,X)V080-16 VARIABLE SPEED FURNACE...
  • Page 14 † In most cases, only 1 method should be used to achieve TDR function. Using more than 1 method in a system may cause degradation in perfor- mance. Use either the accessory Time-Delay Relay KAATD0101TDR or a furnace equipped with TDR. All Carrier furnaces are equipped with TDR except for the 58GFA.
  • Page 15 Detailed cooling capacities* CONDENSER ENTERING AIR TEMPERATURES °F EVAPORATOR Capacity Capacity Capacity Capacity Capacity Capacity MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Kw** Total Sens‡ Kw** Total Sens‡ Kw** Kw** Kw** Kw** 38CKS018-30 Outdoor Section With CC5A/CD5AA018 Indoor Section 21.0 10.0 1.77...
  • Page 16 Detailed cooling capacities* continued CONDENSER ENTERING AIR TEMPERATURES °F EVAPORATOR Capacity Capacity Capacity Capacity Capacity Capacity MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Kw** Total Sens‡ Kw** Total Sens‡ Kw** Kw** Kw** Kw** 38CKS024-30 Outdoor Section With CC5A/CD5AA024 Indoor Section 27.2 13.2...
  • Page 17 Detailed cooling capacities* continued CONDENSER ENTERING AIR TEMPERATURES °F EVAPORATOR Capacity Capacity Capacity Capacity Capacity Capacity MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Kw** Total Sens‡ Kw** Total Sens‡ Kw** Kw** Kw** Kw** 38CKS030-30 Outdoor Section With CC5A/CD5AA030 Indoor Section 34.0 16.4...
  • Page 18 Detailed cooling capacities* continued CONDENSER ENTERING AIR TEMPERATURES °F EVAPORATOR Capacity Capacity Capacity Capacity Capacity Capacity MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† Total Sens‡ Kw** Total Sens‡ Kw** Total Sens‡ Kw** Total Sens‡ Kw** Total Sens‡ Kw** Total Sens‡ Kw** 38CKS036-30 Outdoor Section With CC5A/CD5AA036 Indoor Section 41.3 20.5...
  • Page 19 Detailed cooling capacities* continued CONDENSER ENTERING AIR TEMPERATURES °F EVAPORATOR Capacity Capacity Capacity Capacity Capacity Capacity MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Kw** Total Sens‡ Kw** Total Sens‡ Kw** Kw** Kw** Kw** 38CKS036-30 Outdoor Section With CC5A/CD5AA036 Indoor Section continued 41.3 20.5...
  • Page 20 Detailed cooling capacities* continued CONDENSER ENTERING AIR TEMPERATURES °F EVAPORATOR Capacity Capacity Capacity Capacity Capacity Capacity MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Kw** Total Sens‡ Kw** Total Sens‡ Kw** Kw** Kw** Kw** 38CKS042-30 Outdoor Section With CC5A/CD5AA042 Indoor Section 48.6 23.6...
  • Page 21 Detailed cooling capacities* continued CONDENSER ENTERING AIR TEMPERATURES °F EVAPORATOR Capacity Capacity Capacity Capacity Capacity Capacity MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† Total Sens‡ Kw** Total Sens‡ Kw** Total Sens‡ Kw** Total Sens‡ Kw** Total Sens‡ Kw** Total Sens‡ Kw** 38CKS048-30 Outdoor Section With CD5AA048 Indoor Section 54.3 26.2...
  • Page 22 Detailed cooling capacities* continued CONDENSER ENTERING AIR TEMPERATURES °F EVAPORATOR Capacity Capacity Capacity Capacity Capacity Capacity MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† Total Sens‡ Kw** Total Sens‡ Kw** Total Sens‡ Kw** Total Sens‡ Kw** Total Sens‡ Kw** Total Sens‡ Kw** 38CKS060-30 Outdoor Section With CC5A/CD5AW060 Indoor Section 66.3 32.0...
  • Page 23 Condenser only ratings* CONDENSER ENTERING AIR TEMPERATURES °F °F 38CKS018-30 17.6 16.2 14.7 13.4 12.0 10.7 9.52 8.35 1.37 1.49 1.58 1.66 1.73 1.77 1.80 1.82 75.6 86.1 96.4 106.0 116.0 126.0 136.0 146.0 19.6 18.1 16.6 15.1 13.6 12.3 10.9 9.68 1.40...
  • Page 24 Condenser only ratings* continued CONDENSER ENTERING AIR TEMPERATURES °F °F 38CKS036-30 32.1 30.5 28.9 27.2 25.5 23.7 21.8 19.9 2.33 2.57 2.84 3.11 3.40 3.68 3.95 4.21 78.6 89.0 99.3 109.0 120.0 129.0 139.0 149.0 35.2 33.5 31.8 30.0 28.2 26.3 24.3 22.3...
  • Page 25 Condenser only ratings* continued CONDENSER ENTERING AIR TEMPERATURES °F °F 38CKS060-30 52.8 50.6 48.2 45.8 43.3 40.6 37.9 35.2 3.87 4.27 4.73 5.23 5.78 6.37 6.99 7.63 75.7 86.2 96.6 107.0 117.0 127.0 137.0 147.0 57.8 55.4 52.9 50.3 47.6 44.8 41.9 39.0...
  • Page 26 System Design 1. Intended for outdoor installation with free air inlet and outlet. Outdoor fan external static pressure available is less than 0.01-in. wc. 2. Minimum outdoor operating air temperature without low-ambient operation accessory is 55°F (12.8°C). 3. Maximum outdoor operating air temperature is 125°F (51.7°C). 4.
  • Page 27 Guide specifications Air-Cooled, Split-System Air Conditioner 38CKS GENERAL 1-1/2 to 5 Tons Nominal System Description Condenser fan motors will be totally enclosed, 1-phase Outdoor-mounted, air-cooled, split-system air conditioner type with class B insulation and permanently lubricated unit suitable for ground or rooftop installation. Unit consists bearings.
  • Page 28 Indianapolis, IN 46231 4-99 Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations. Book Page 28 Catalog No. 523-762 Printed in U.S.A. PC 101 Form 38CKS-1PD Replaces: NEW 3a 1a 2a...
