Husqvarna 1335PW Operator's Manual

Husqvarna gas pressure washer operator's manual.
Hide thumbs

Advertisement

Operator's manual
5525PW, 6026PW, 9030PW, 1335PW
Please read the operator's manual carefully and make sure you
understand the instructions before using the machine.
English

Advertisement

   Summary of Contents for Husqvarna 1335PW

  • Page 1

    Operator’s manual 5525PW, 6026PW, 9030PW, 1335PW Please read the operator’s manual carefully and make sure you understand the instructions before using the machine. English...

  • Page 2: Table Of Contents

    9030PW Cart ......25 1335PW Cart ......25 PUMP PART LIST .

  • Page 3: Key To Symbols

    Safety Guidelines This manual contains information that is very important to know and understand. This information is provided for SAFETY and to PREVENT EQUIPMENT PROBLEMS. To help recognize this information, observe the following symbols. Warning indicates a potentially WARNING hazardous situation which, if not avoided, COULD result in death or serious injury.

  • Page 4: Introduction

    Husqvarna River to create the water-powered plant. During the more than 300 years of being, the Husqvarna factory has produced a lot of different products, from wood stoves to modern kitchen appliances, sewing machines, bicycles, motorcycles, etc. In 1956, the first motor driven lawn mowers appeared, followed by chain saws in 1959, and it is within this area Husqvarna is working today.

  • Page 5: What Is What

    Tip Holder with Spray Tips Detergent Tank (5525PW, 6026PW) Injection Tube (not shown) Gun with trigger Lance Inlet Connection for High Pressure Hose (not shown on 9030PW/1335PW) Inlet Connection for Garden Hose (not shown on 9030PW/1335PW) 4 — English WHAT IS WHAT? 9030PW/1335PW*...

  • Page 6: Frequently Asked Questions

    4. DO NOT store your pressure washer in an area where the temperature will drop below 32˚F / 0˚C) unless pressure washer is properly winterized (see Page 15). Where can I buy accessories for my pressure washer? • Call your local Husqvarna Dealer. English — 5...

  • Page 7: Safety Guidelines

    ALWAYS turn water supply “ON” before turning pressure washer “ON.” Running pump dry causes serious damage. • DO NOT operate the pressure washer with the inlet water screen removed. Keep screen clear of debris and sediment. • NEVER operate pressure washer with broken or missing parts.

  • Page 8

    NEVER allow the unit to run with the trigger released (off) for more than two minutes. Resulting heat buildup will damage the pump. • NEVER store the pressure washer outdoors or where it could freeze. Freezing temperatures can seriously damage the pump. •...

  • Page 9: Pre-operation

    One cart handle assembly. • One spray gun. • One lance. • Two spray tips for Model 5525PW Five spray tips for Models 1335PW, 6026PW and 9030PW • One high pressure hose. • One pack of nuts, bolts, and manuals. •...

  • Page 10

    4. Connect the high pressure hose to the pump outlet (See Figure 5). High Pressure Hose Garden Hose Figure 5 - Connect high pressure hose to pump 5. Attach the lance with nozzle to the gun (See Figure Figure 6 - Attach lance to gun 6.

  • Page 11: Trigger Safety Latch

    For models 9030PW and 1335PW: Insert spray tips into rubber grommets on placard (See Figure 9). Figure 9 - Insert spray tips into the placard 10 — English PRE-OPERATION TRIGGER SAFETY LATCH In the engaged position, the trigger safety latch prevents the gun from being triggered accidentally.

  • Page 12: Operation

    "RUN" or "RABBIT" position. Turn the On/Off switch to the "ON" position On model 1335PW - Honda GX engine: Open the fuel shutoff valve by pushing the lever to the right. Close the choke (if the engine is cold) by moving the choke lever fully to the left.

  • Page 13: Initial High Pressure Rinse

    (see pages 13 and 14 for cleaning techniques). PRESSURE ADJUSTMENT Models 9030PW and 1335PW have a pressure adjustment knob located on the pump (see Figure 11). Turn the knob clockwise to increase the pressure. Turn the knob counter clockwise to decrease the pressure.

  • Page 14: Angle To The Cleaning Surface

    ANGLE TO THE CLEANING SURFACE When spraying water against a surface, you can generate maximum impact by striking the surface head on. However, this type of impact can cause dirt particles to embed in the surface and can prevent the desired cleaning action. Spray water against a surface at a 45 degree angle to achieve the most beneficial impact force and to efficiently remove debris.

  • Page 15: General Cleaning Tips

    NOTE: Some units also may have a pressure adjustment knob on the pump that can adjust the pressure (models 9030PW and 1335PW). 6. Final Rinse The final rinse should start at the bottom and work upward. Make sure that you thoroughly rinse the surface and that you remove all detergent.

  • Page 16: Storage

    WASHER • NEVER operate the unit without water. • Your pressure washer is not meant to pump hot water. NEVER connect your pressure washer to a hot water supply as it will significantly reduce the life of the pump. •...

  • Page 17: Maintenance

    5525PW - Honda GCV160 - 18.6 fl. oz. (0.550 L) 6030PW - Subaru EX17 - 20 fl. oz. (0.591 L) 9030PW - Subaru EX27 - 37 fl. oz. (1.09 L) 1335PW - Honda GX390 - 37 fl. oz. (1.09 L) 16 — English MAINTENANCE...

  • Page 18: Check Pump Oil And Pump Oil Changing

    For models 6026PW, 9030PW, and 1335PW: These units all have a sight glass to check the oil level and have a drain plug to remove the old oil when changing. To add oil remove vent cap from top of pump [See Figure 19 (A)].

  • Page 19: Maintenance Schedule

    MAINTENANCE SCHEDULE Maintenance Schedule Each use After first 5 hours of operation After first 50 hours of operation Every 25 hours of operation Every 50 hours of operation Each 100 hours of operation or every 3 months Every 500 hours of operation (5 months) NOTE: This is a general maintenance schedule.

  • Page 20

    6030PW - Subaru EX17 - 20 fl. oz. (0.591 L) 9030PW - Subaru EX27 - 37 fl. oz. (1.09 L) 1335PW - Honda GX390 - 37 fl. oz. (1.09 L) Engine Fuel Capacity 5525PW - Honda GCV160 - 0.29 gal (1.09 L) 6030PW - Subaru EX17 - 0.95 gal (3.6 L)

  • Page 21: Troubleshooting Chart

    TROUBLESHOOTING CHART Troubleshooting Chart - Gasoline Powered Pressure Washers Only Symptom Possible Cause(s) Engine will not start No gasoline in fuel tank or or is hard to start carburetor Low oil Start/Stop switch in stop position Water in gasoline or old fuel Dirty air cleaner filter Spark plug dirty, wrong gap or wrong type...

  • Page 22

    Reduce temperature below 100°F / 38°C Use black quick connect detergent tip If clean, unkink or replace hose Use only hose length provided with initial purchase of pressure washer. Detergent suction will not function if more than once section of hose is attached to unit Remove 1”...

  • Page 23

    NOTES 22 — English...

  • Page 24: Cart Parts List

    5525PW 531 30 74-96 531 30 75-35 531 30 74-69 531 30 74-72 531 30 74-84 531 30 74-94 531 30 75-37 531 30 81-14 531 30 75-39 (x1) 531 30 74-61 (x1) 531 30 75-32 531 30 81-11 531 30 74-97 531 30 74-62 531 30 74-77 (Soap) 531 30 74-78 (0°)*...

  • Page 25: 6026pw Cart

    531 30 74-82 531 30 74-87 531 30 74-88 531 30 74-86 531 30 74-68 531 30 74-94 531 30 75-37 531 30 75-39 (x1) 531 30 74-61 (x1) 24 — English 6026PW 531 30 74-93 531 30 74-82 531 30 74-89 531 30 75-44 531 30 74-72 531 30 74-84...

  • Page 26: 9030pw Cart

    531 30 74-68 531 30 74-72 531 30 74-84 531 30 74-70 531 30 75-45 (x4 9030PW) 531 30 75-96 (x4 1335PW) 531 30 75-47 531 30 74-91 531 30 75-39 (x1) 531 30 74-71 Detergent Tube (not shown) 531 30 74-77 (Soap) 531 30 74-73 (0°)

  • Page 27: Pump Part List

    531 30 75-29 Pump Assembly Complete P/O 531 30 75-06 (x1) 531 30 75-01(x6) 531 30 75-02 (x6) 531 30 75-66 531 30 75-03 (x3) 531 30 75-02 (x6) P/O 531 30 75-01 (x3) 531 30 75-11 (x3) 531 30 74-98 P/O 531 30 75-06 (x1) 26 —...

  • Page 28: 6026pw Pump

    531 30 75-12 Pump Assembly Complete 531 30 75-77 (x3) 531 30 75-87 531 30 75-14 (x1) 531 30 75-51 (x3) 531 30 75-15 (3/8" TRV) 531 30 75-91 (1/4" TRV) 531 30 75-66 531 30 75-16 (x8) 531 30 75-90 531 30 74-90 531 30 75-89 531 30 75-67...

  • Page 29: 9030pw Pump

    Pump for 9030PW and 1335PW 531 30 75-17 Pump Assembly Complete P/O 531 30 75-61 (x1) P/O 531 30 75-61 (x1) P/O 531 30 75-92 (x1) P/O 531 30 75-92 (x1) P/O 531 30 75-63 (x1) P/O 531 30 75-63 (x4)

  • Page 30

    For customer assistance contact us at our website: www.usa.husqvarna.com IN466800AV 3/06...
