StarTech.com ST121HDFXA Instruction Manual page 8

Cable Type
Cable Diameter
(micron)
Video Signal
Max. Cable Length
(meter)
3. Install Receiver Unit
a) Position the Receiver Unit near the video display (i.e. television, projector).
b) Connect the video source to the HDMI® OUT on the Receiver Unit using an
HDMI® cable.
c) (Optional) If using the ST121HDFXA to extend an infrared (IR) device signal.
Connect the IR Receiver Cable to the IR Receiver on the Receiver Unit, and Position
the IR sensor where the remote control will point.
d) Connect the provided Receiver Unit power supply.
4. Your source video image will now appear on the remote video display.
Instruction Manual
Multi-Mode (M-M)
50/125 μM
1080p 1080i
800 1200
5
62.5/125μM
1080p 1080i
350 450
Single-Mode (S-M)
9/125μM
1080p 1080i
- -
