6. Diagnostic Tool

TSC's Diagnostic Utility is an integrated tool incorporating features that enable you to
explore a printer's settings/status; change a printer's settings; download graphics,
fonts and firmware; create a printer bitmap font; and send additional commands to a
printer. With the aid of this powerful tool, you can review printer status and settings in
an instant, which makes it much easier to troubleshoot problems and other issues.

6.1 Start the Diagnostic Tool

1. Double click on the Diagnostic tool icon
2. There are four features (Printer Configuration, File Manager, Bitmap Font Manager,
Command Tool) included in the Diagnostic utility.
Features tab
Printer functions
Printer Status
26
to start the software.
Interface
Printer setup
