LX501/LX601i
Users Manual-Operating Guide
020-000461-01

Advertisement

Table of Contents
loading

Related Manuals for Christie LX501

Summary of Contents for Christie LX501

  • Page 1 LX501/LX601i Users Manual-Operating Guide 020-000461-01...
  • Page 3 • DICOM is the registered trademark of the National Electrical Manufacturers Association for its standards publications relating to digital communications of medical information. All other trademarks are the properties of their respective owners. LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)

  • Page 4: Table Of Contents

    Temporarily freezing the screen . . . 37 Temporarily shutting the screen . . . 37 Using the menu function ..38 Indication in OSD, Containing items of each menu LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)

  • Page 5: Introduction

    • The projector may make a rattling sound when tilted, moved or shaken, since a flap to control the air flow inside of the projector has moved. Be aware that this is not a failure or malfunction. LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)

  • Page 6: Part Names

    ►Do not attach anything onto the lens except the lens cover of this projector because it could damage the lens, such as melting the lens. (continued on next page) LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 7 (16) REMOTE CONTROL IN port (8) COMPONENT ports (17) REMOTE CONTROL OUT port (Y,Cb/Pb, Cr/Pr) (18) CONTROL port (5) (6) (10) (7) (18) (16) (17) (14) (13) (12) (11) (15) (continued on next page) LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 8 • Any button marked with “*” is not supported on this projector ( • Each time you press any button (except ID buttons), the ID button of current 18). selected ID number will light ( LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)

  • Page 9: Setting Up

    The values shown in the table are calculated for a full size screen. Projector top Projector bottom Elevator feet Screen size Projection distance : Screen height (continued on next page) LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 10 • Do not place the projector near water, such as in a bathroom, kitchen, or poolside. • Do not place the projector outdoors or by the window. • Do not place anything containing liquid near the projector. (continued on next page) LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 11 • Keep heat-sensitive things away from the projector. Otherwise, they may be damaged by the heat from the projector. LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)

  • Page 12: Connecting With Your Devices

    COMPUTER IN1 port (DDC 2B compatible). Plug-and-Play may not work properly if any other type of connection is attempted. - Please use the standard drivers in your computer as this projector is a Plug- and-Play monitor. (continued on next page) LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 13 In such a case, use an external display device. You may be able to see the dialog and set an appropriate display resolution. (continued on next page) LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 14 • If an oversized USB storage device blocks the LAN port, use only the further USB TYPE A port from the LAN port or a USB extension cable to connect the USB storage device. (continued on next page) LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 15 It is recommended to fasten the cables to the 15, 16). projector to prevent the cables from coming off ( (continued on next page) LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 16 REMOTE CONTROL IN or OUT ports, use audio cables with 3.5 mm diameter stereo mini plugs. This function is useful when a wireless remote signal may not reliably reach the projector. LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)

  • Page 17: Fastening The Adapter Cover

    Then insert the screw removed from the projector into the hole and tighten the screw. Snap the clip closed to secure the HDMI cables in place. WARNING ►Keep small parts away from children and pets. LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)

  • Page 18: Fastening The Cables

    • The security bar and slot is not comprehensive theft prevention measures. It is intended to be used as supplemental theft prevention measure. 4) can be used for the same purpose as the security bar. • The safety bar ( LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)

  • Page 19: Connecting To A Power Supply

    • Connect the ground terminal for the AC inlet of this unit to the ground terminal of the building using an appropriate power cord (bundled). • This product is also designed for IT power systems with a phase- NOTICE tophase voltage of 220 to 240 V. LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)

  • Page 20: Remote Control

    ID number will light. • To confirm the projector's current ID, press any ID button for 3 seconds. Its number will be shown on each screen regardless of set ID of projector. LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)

  • Page 21: Changing The Frequency Of Remote Control Signal

    (such as from an inverter fluorescent lamp) shines on the remote sensor of the projector. Adjust the position of projector avoiding those lights. LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)

  • Page 22: Using As A Simple Pc Mouse & Keyboard

    - When any menu is displayed on the screen. - While using the cursor buttons to operate the sound or screen functions such as adjusting the sound volume, correcting the keystone, correcting the picture position and magnifying the screen. LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)

  • Page 23: Status Monitor

    LAN port is selected. NOT CONNECTED: The projector is not connected to the network or the computer while the LAN or USB TYPE B port is selected. (continued on next page) LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 24 Refer to the LAMP and TEMP indicators simultaneous blinking in the table 115). NOTE • When one of the warnings of FAN, LAMP, COVER, TEMP errors is displayed, the backlight blinks at the same time. LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)

  • Page 25: Displaying The Log

    N 1 9 2 1 6 8 0 0 1 0 7 5 1st page (wireless and wired) Network information : Default gateway 3rd page (example) (wireless and wired) (continued on next page) LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 26 30 seconds without button operation. • If no error or less than 10 errors have occurred, "NO DATA" is displayed in spite of occurred error in the error log. LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)

  • Page 27: Power On/Off

    • This projector has the function that can make the projector automatically turn on/ 65) and AUTO POWER OFF ( off. Please refer to the DIRECT POWER ON ( items of the OPTION menu. LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)

  • Page 28: Operating

    ►If you wish to have a blank screen while the projector's lamp is 37). Taking on, use the AV MUTE function above or the lens shutter function ( any other action may cause the damage on the projector. LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)

  • Page 29: Selecting An Input Signal

    64). detected ( • It may take several seconds to project the images from the USB TYPE B port. LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)

  • Page 30: Selecting An Aspect Ratio

    For an input signal from the LAN, USB TYPE A or USB TYPE B ports, or if there is no signal 4:3 (fixed) NOTE • ASPECT button does not work when no proper signal is inputted. • NORMAL mode keeps the original aspect ratio setting. LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)

  • Page 31: Adjusting The Projector's Elevator

    Only for LX601i, it is possible to install the projector for any direction with specified mounting accessories. Consult with your dealer about such a special installation. LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)

  • Page 32: Adjusting The Lens

    • The adjustable range of LENS SHIFT varies depending on the lens unit mounted on the projector to maintain picture quality. Therefore LENS SHIFT adjustment may not reach the end of the indicator in the dialog, and that is not a failure. LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)

  • Page 33: Lens Memory

    Press the ►button again to clear the lens memory. NOTE • The projector may ignore operation by buttons while moving the lens. • You can perform the LOAD function using LENS MEMORY button. LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)

  • Page 34: Using The Automatic Adjustment Feature

    • This function is unavailable for a signal from the LAN, USB TYPE A / B or HDMI 1 / 2 port. LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)

  • Page 35: Correcting The Distortion

    - The projector is nearly horizontal (about ±4°). - The projector is inclined at about ±35 degrees or over. • When the horizontal lens shift is not set to the center, this function may not work well. LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 36 RESET button, and press the ENTER or INPUT button. Select one of the corners or sides to be adjusted with the ▲/▼/◄/► buttons and press the ENTER or INPUT button. (continued on next page) LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 37 • There may be some noise and the screen may flicker for a moment when loading data. This is not malfunction. • Point at RETURN in the dialog with the ▲/▼ buttons and press the ◄ or ENTER button to return to the KEYSTONE menu. LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)

  • Page 38: Using The Magnify Feature

    • Some horizontal stripes might be visible on the image while magnification is active. • This function is not available in the following cases: - A sync signal in the range not supported is input. - There is no input signal. LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)

  • Page 39: Temporarily Freezing The Screen

    If AC power supply is disconnected while opening or closing the lens shutter, the moving of the lens shutter stops. However, the next time the projector is turned on, the lens shutter opens again automatically. LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)

  • Page 40: Using The Menu Function

    ENTER button to progress. The operation menu or dialog of the selected item will appear. (3) Use the buttons as instructed in the OSD to operate the item. (continued on next page) LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)

  • Page 41: Indication In Osd

    Selecting this word cancels the operation in the present CANCEL or NO menu and returns to the previous menu. Selecting this word executes the prepared function or shifts OK or YES the menu to the next menu. LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)

  • Page 42: Containing Items Of Each Menu

    WIRED INFORMATION, PROJECTOR NAME, MY IMAGE, AMX D. D., PRESENTATION, SERVICE SECURITY PASSWORD CHANGE, MyScreen PASSWORD, PIN LOCK, TRANSITION DETECTOR, MY TEXT PASSWORD, SECURITY ( MY TEXT DISPLAY, MY TEXT WRITING, SECURITY INDICATOR, STACK LOCK LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)

  • Page 43: Easy Menu

    The picture modes are combinations of GAMMA and COLOR TEMP settings. Choose a suitable mode according to the projected source. NORMAL CINEMA DYNAMIC BOARD(BLACK) PICTURE MODE DICOM SIM. DAYTIME WHITEBOARD BOARD(GREEN) (continued on next page) (continued on next page) LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 44 Press the ► or ENTER button to use the menu of PICTURE, ADVANCED MENU IMAGE, INPUT, SETUP, AUDIO, SCREEN, OPTION, NETWORK or SECURITY. EXIT Press the ◄ or ENTER button to finish the OSD menu. LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)

  • Page 45: Picture Menu

    • Lines or other noise might appear on the screen when this function is operated, but it is not a malfunction. (continued on next page) LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 46 (1) HDMI FORMAT item in the INPUT menu for selected port is set to VIDEO. (2) HDMI FORMAT item in the INPUT menu for selected port is set to AUTO, and the projector recognizes that it receives video signals. (continued on next page) LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 47 • There may be some noise and the screen may flicker for a moment when loading data. This is not malfunction. • You can perform the LOAD function using MY BUTTON. Please 67). see MY BUTTON item in OPTION menu ( LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)

  • Page 48: Image Menu

    For an input signal from the LAN, USB TYPE A or USB TYPE B ports, or if there is no signal 4:3 (fixed) • The NORMAL mode keeps the original aspect ratio of the signal. (continued on next page) LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 49 It is not possible to adjust when OVER SCAN is set to 10. • This function is unavailable for a signal from the LAN, USB TYPE A / B or HDMI 1 / 2 port. (continued on next page) LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 50 • The items adjusted by this function may vary when the FINE or DISABLE is selected for the AUTO ADJUST item of the SERVICE 68). item in the OPTION menu ( LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)

  • Page 51: Input Menu

    Pb, Cr/Pr) and VIDEO ports will function as a SCART RGB port. A SCART adapter or SCART cable is required for a SCART RGB input to the projector. For details, contact your dealer. (continued on next page) LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 52 ENHANCED: sets the suitable mode for computer signals. (0-255) • If the contrast of the screen image is too strong or too weak, try finding a more suitable mode. (continued on next page) LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 53 • This item can be performed only on a signal with a vertical frequency of 49 to 51Hz, 59 to 61 Hz. • When ON is selected, moving pictures are displayed more smoothly. (continued on next page) LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 54 CANCEL on screen and press the ◄ or ENTER button. The screen will then return to the RESOLUTION menu displaying the previous resolution. • For some pictures, this function may not work well. LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)

  • Page 55: Setup Menu

    WIDE (wide-angle focus) whenever possible. • This function is unavailable when the TRANSITION DETECTOR 89) is ON or the screen is adjusted by PERFECT FIT ( 34, 35). (continued on next page) LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 56 INPUT button of the projector to execute. If TRANSITION DETECTOR is ON and the INSTALLATION status 89) will be is changed, the TRANSITION DETECTOR ON alarm ( displayed when the projector is restarted. (continued on next page) LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 57 Select OFF to disable the MONITOR OUT port for the input port or standby mode chosen in the step (1). • You cannot select COMPUTER IN1 in step (1) and COMPUTER IN2 in step (2) and vice versa. LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)

  • Page 58: Audio Menu

    NTSC for VIDEO or S-VIDEO, or 480i@60 for COMPONENT, COMPUTER IN1 or COMPUTER IN2, and when AUTO is selected for DISPLAY in the C.C. menu under the 63). SCREEN menu ( (continued on next page) LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 59 HDMI port to be set. HDMI AUDIO (2) Use the ◄/►buttons to select the mode of HDMI audio. Check each of the two modes provided and select the suitable one for your HDMI audio device. LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)

  • Page 60: Screen Menu

    • When the ON is selected to the MyScreen PASSWORD item in 87), the START UP is fixed to MyScreen. the SECURITY menu ( (continued on next page) LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 61 MyScreen PASSWORD item in SECURITY menu ( • This function is unavailable for a signal from the LAN, USB TYPE A / B or HDMI 1 / 2 port. (continued on next page) LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 62 The indication of the ECO MODE displayed by changing. • When the OFF is selected, please remember if the picture is 37). frozen. Do not mistake freezing for a malfunction ( (continued on next page) LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 63 Then press the ENTER or INPUT button. (5) If you would like to modify the name assigned to the port, select CUSTOM NAME and press the ENTER or INPUT button. (continued on next page) LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 64 MAP1 or MAP2 is selected. To invert or scroll the map, display the guidance by pressing the RESET button on the remote three seconds or more when MAP1 or MAP2 appears. (continued on next page) LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 65 1: Channel 1, primary channel / language 2: Channel 2 3: Channel 3 4: Channel 4 The channel data may vary, depending on the content. Some channel might be used for secondary language or empty. LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)

  • Page 66: Option Menu

    • When the projector is suspended from the ceiling this feature will not function properly so select the OFF. • This function will be unavailable when the Transition Detector is on 89). (continued on next page) LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 67 Using the ▲/▼ buttons sets the time from closing the lens shutter to automatically turning the projector off. SHUTTER TIMER • The shutter will open automatically when turning the projector on again. (continued on next page) LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 68 • For the air filter cleaning, see the section Cleaning and replacing 109). the air filter ( • The filter time can be checked also with the Status Monitor on 23). LX601i ( (continued on next page) LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 69 62) appear or disappear. item ( MUTE: Turns the audio mute on/off. 52). RESOLUTION: Turns on/off the RESOLUTION dialog ( 54). ECO MODE: Turns on/off the ECO MODE dialog ( (continued on next page) LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 70 DISABLE to disable the automatic adjustment, and make adjustment manually. GHOST 1. Select a color element of ghost using the ◄/► buttons. 2. Adjust the selected element using the ▲/▼ buttons to disappear ghost. (continued on next page) LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 71 Using the ▲/▼ buttons turns on/off the lens lock feature. When ON is selected, the buttons (ZOOM, ZOOM + / -, FOCUS + / -, LENS SHIFT, LENS MEMORY) are locked. (continued on next page) LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 72 The projector is controlled by the remote control whose ID button is set the same number as this number. When the ALL is selected, the projector is controlled by a remote control irrespective of the ID setting. (continued on next page) LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 73 OFF: Select this mode to receive RS-232C commands using the CONTROL port. • OFF is selected as the default setting. • When you select the NETWORK BRIDGE, check the item, TRANSMISSTION METHOD ( (continued on next page) LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 74 • HALF-DUPLEX is selected as the default setting. • If you select HALF-DUPLEX, check the setting of 73). the item RESPONSE LIMIT TIME ( (continued on next page) LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 75 Selecting this item displays the STACK menu. For more information, please see Instant Stack Guide. • When STACK MODE is set to MAIN or SUB, the other items in COMMUNICATION menu are invalid. (continued on next page) LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 76 Note that the items LAMP TIME, FILTER TIME, LANGUAGE, FILTER MESSAGE, STANDBY MODE, COMMUNICATION, NETWORK and SECURITY settings are not reset. CANCEL LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)

  • Page 77: Network Menu

    • If ADHOC is set to MODE while one of WPA- PSK or WPA2-PSK is selected in ENCRYPTION, 77) setting switches to OFF the ENCRYPTION ( automatically. (continued on next page) LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 78 Use the ► button to return to the menu after DIFFERENCE setting the TIME DIFFERENCE. • When this item is set, the same item in the WIRED SETUP menu is overwritten with the same 81). setting ( (continued on next page) LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 79 • If IEEE802.11 n is used while MODE is set to INFRASTRUCTURE, TKIP and WEP are disabled. If OFF or AES is not selected, communication will switch automatically to IEEE802.11 b/g. (continued on next page) LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 80 ►, ENTER or INPUT button. To revert to the previous name without saving changes, move the cursor to the CANCEL on screen and press the ◄, ENTER or INPUT button. (continued on next page) LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 81 WIRELESS SETUP menu. • An icon is displayed to the left of the SSID of the device connected to the projector. (continued on next page) LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 82 Use the ▲/▼/◄/► buttons to input the DNS server address. DNS SERVER The DNS server is a system to control domain names and IP addresses on the Network. (continued on next page) LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 83 • Only the first 16 characters of the PROJECTOR NAME are displayed. • IP ADDRESS, SUBNET MASK and DEFAULT GATEWAY indicate “0.0.0.0” when DHCP is ON and the projector has not gotten address from DHCP server. (continued on next page) LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 84 ►, ENTER or INPUT button. To revert to the previous PROJECTOR NAME without saving changes, move the cursor to the CANCEL on screen and press the ◄, ENTER or INPUT button. (continued on next page) LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 85 (AMX Device of AMX connected to the same network. For the details of AMX Discovery) Device Discovery, visit the AMX web site. URL: http://www.amx.com/ (as of Feb. 2012) (continued on next page) LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 86 Press the ► button to choose OK, and then press ENTER or INPUT again. The image for the selected computer is displayed on full screen. (continued on next page) (continued on next page) LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 87 Network will be once cut off when choose restart. If DHCP is selected on, IP address may be changed. After selecting NETWORK RESTART EXECUTE, NETWORK menu may not be controlled approx. 30 seconds. LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)

  • Page 88: Security Menu

    Pressing the ENTER button on the remote control or ► button on the projector will close the NOTE NEW PASSWORD box. • Please do not forget your password. (continued on next page) LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 89 Inquiring Code will be displayed inside the box. 3-3 Contact your dealer with the 10 digit Inquiring Code. Your password will be sent after your user registration information is confirmed. (continued on next page) LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 90 Inquiring Code is displayed, the projector will turn off. 3-2 Contact your dealer with the 10 digit Inquiring Code. Your PIN code will be sent after your user registration information is confirmed. (continued on next page) LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 91 Inquiring Code will be displayed inside the box. 3-3 Contact your dealer with the 10 digit Inquiring Code. Your password will be sent after your user registration information is confirmed. (continued on next page) LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 92 3-3 Contact your dealer with the 10 digit inquiring code. Your password will be sent after your user registration information is confirmed. (continued on next page) LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 93 CANCEL on screen and press the ◄, ENTER or INPUT button. • The MY TEXT WRITING function is available only when the MY TEXT PASSWORD function is set to OFF. (continued on next page) LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 94 ON, the SECURITY indicator blinks in yellow in the standby mode 88, 89). Selecting this item displays the STACK LOCK dialog. For more STACK LOCK information, please see Instant Stack Guide. LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)

  • Page 95: Presentation Tools

    • PNG (.png) * Interlace PNG is not supported. • GIF (.gif) • Movie (.avi, .mov) * Supported video format: Motion-JPEG Supported audio format: WAV (Linear PCM, Stereo 16bit), IMA-ADPCM (continued on next page) LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 96 NOTE • Files with a resolution larger than the following are not supported. LX501, LX601i: 1024 x 768 (Still), 768 x 576 (Movie) (* Some computers may not support above resolutions.) • Files with a resolution smaller than 36 x 36 are not supported.
  • Page 97 “playlist.txt” file ( Press the ► cursor or ENTER button to rotate the selected still ROTATE image 90 degrees clockwise. This setting information will be 102). saved in the “playlist.txt” file ( LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 98 After that, the projector will not recognize USB REMOVE USB storage devices until you insert it again into the USB TYPE A ports. Turns the sound on/off for files that contain audio data. (continued on next page) LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 99 • Some error icons will be displayed on the Thumbnail screen. This file seems to be broken or not supported format. A file that cannot be displayed on the Thumbnail screen is indicated by a file format icon. LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)

  • Page 100: Full Screen Mode

    [▼] ▼ ► [►] Shows the next file. ► PAGE DOWN [PAGE DOWN] ▲ [▲] ▲ ◄ [◄] Shows the previous file. ◄ PAGE UP [PAGE UP] ENTER INPUT [ENTER] Displays Thumbnail. LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 101 • These operations are not accessible while the projector OSD is displayed. • It is not possible to change the input port by using the INPUT button when the Thumbnail screen, Slideshow, or Full Screen image is displayed. LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)

  • Page 102: Slideshow Mode, Playlist

    • When the Slideshow mode is set to ONE TIME and the last file is a still image, the last slide of the presentation will remain displayed until the ENTER button on the remote control or Web Remote Control, or the INPUT button on the control panel is pressed. LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 103 • The settings for the START, STOP, INTERVAL, and PLAY MODE are saved to the Playlist. • If the storage media is under the write protection or the “playlist.txt” is the read only type file, it is impossible to change the settings of the Slideshow. LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 104 • If the storage device is protected or does not have sufficient space, the “playlist. txt” file cannot be created. 100). • For the Slideshow settings, refer to the section Slideshow mode ( LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)

  • Page 105: Usb Display

    LX501, LX601i: 1024 x 768 (XGA) The transferred image is displayed as shrunk on the projected screen even if the panel resolution of the projector is larger than above.
  • Page 106 • When the audio input from USB TYPE B ( still low even after raising the volume level in the projector to the maximum, check whether your computer outputs audio and raise the volume level accordingly. LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 107 5 Minimize button The Floating menu is closed, and the icon reappears in the Windows notification area. NOTE • Images may not be displayed on screen, if the start/stop capture buttons are clicked repeatedly. LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 108 LX501, LX601i: 1024 x 768 (XGA) If your computer does not support the display resolution specified above, a smaller resolution that is the largest among the resolutions that are supported by the computer will be selected.

  • Page 109: Maintenance

    Preparation of a new lamp and early replacement are recommended. To prepare a new lamp, make contact with your dealer and tell the lamp type number. Type number <LX501> : 003-120707-01 (DT01285) < LX601i> : 003-120708-01...

  • Page 110: Lamp Warning

    When the pictures appear dark, or when the color tone is poor, please replace the lamp as soon as possible. Do not use old (used) lamps; this is a cause of breakage. LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)

  • Page 111: Cleaning And Replacing The Air Filter

    Filter unit soiled, replace them with the new ones. knobs Combine the two parts to reassemble the filter unit. Put the filter unit back into the projector. Interlocking parts (continued on next page) LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 112 filter, for a suitable indication about the air filter. • The projector may display the message such as the “CHECK THE AIR FLOW” or turn off the projector, to prevent the internal heat level rising. LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)

  • Page 113: Other Care

    ►Do not use cleaners or chemicals other than those specified in this manual. ►Do not polish or wipe with hard objects. NOTICE ►Do not directly touch the lens surface with hands. LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)

  • Page 114: Troubleshooting

    Projector is waiting for an image file. Check the hardware connection, settings on the projector and network-related settings. The computer-Projector network connection might be disconnected. Please re-connect them. (continued on next page) LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 115 - Pressing the one of buttons to call a signal input might be ignored, when all the input ports belonging to the category the button's name shows are set to the "SKIP" by the item SOURCE SKIP of the OPTION menu. LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)

  • Page 116: Regarding The Indicator Lamps

    After Lighting performing any needed maintenance, turn the power on again. If the same indication is displayed after the remedy, please contact your dealer or service company. (continued on next page) LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 117 Blinking In At least 1 Power ON schedule is saved to the Green Turned Turned projector. approx. 3 Please refer to 3.1.7 Schedule Settings in the seconds. Network Guide. (continued on next page) LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)

  • Page 118: Resetting All Settings

    74) can reset all settings (except settings of SERVICE item in OPTION menu ( such as LANGUAGE, LAMP TIME, FILTER TIME, FILTER MESSAGE, STANDBY MODE, COMMUNICATION, SECURITY and NETWORK) to the factory default. LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)

  • Page 119: Phenomena That May Be Easy To Be Mistaken For Machine Defects

    The USB TYPE B port is not recognized as a input port because of electrical noise. Once set to MOUSE for USB TYPE B in OPTION menu, and reset to USB DISPLAY again for re-recognition. (continued on next page) LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 120 The lens shutter is closed. Check whether the SHUTTER indicator is blinking. If it is blinking, press SHUTTER button on the control panel. (continued on next page) LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 121 Adjust the focus using the FOCUS + / - buttons, and/or H PHASE using the menu function. The lens is dirty or misty. Clean the lens referring to the section Caring for the lens. (continued on next page) LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 122 Network does The same network address is set for both wireless and not work wired LAN. 76, 80 Change the network address setting for wireless or wired LAN. (continued on next page) LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 123 NOTE • Although bright spots or dark spots may appear on the screen, this is a unique characteristic of liquid crystal displays, and it does not constitute or imply a machine defect. LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)

  • Page 124: Specifications

    • Be sure to read “End User License Agreement for the Projector Software” which is separated document. LX501/LX601i User Manual-Operating Guide 020-000461-01 Rev. 1 (03-2012)
  • Page 126 Corporate offi ces USA – Cypress ph: 714-236-8610 Canada – Kitchener ph: 519-744-8005 Worldwide offi ces United Kingdom Eastern Europe Singapore Japan ph: +44 118 977 8000 ph: +36 (0) 1 47 48 100 ph: +65 6877-8737 ph: 81-3-3599-7481 France Middle East Beijing South Korea...
