- Page 1 LX501/LW401/LWU421/ LX601i/LW551i/LWU501i S e t u p G u i d e 020-000504-02 http://www.pureglare.com.au...
-
Page 2: Table Of Contents
LX501/LX601i/LW401/LW551i/LWU421/LWU501i Projector LX501/LW401/LWU421/ LX601i/LW551i/LWU501i Setup Guide User's Manual (concise) Thank you for purchasing this projector. Please read through this manual before using this product, in order to use safely and utilize well the product. WARNING ►Before using this product, be sure to read all manuals for this product. -
Page 3: First Of All
LX501/LX601i/LW401/LW551i/LWU421/LWU501i First of all Entries and graphical symbols explanation The following entries and graphical symbols are used for the manuals and the product as follows, for safety purpose. Please know their meanings beforehand, and heed them. WARNING This entry warns of a risk of serious personal injury or even death. -
Page 4: Regulatory Notices
LX501/LX601i/LW401/LW551i/LWU421/LWU501i Regulatory notices About Electro-Magnetic Interference This is a Class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. This product may cause interference if used in residential areas. Such use must... -
Page 5: About Waste Electrical And Electronic Equipment
LX501/LX601i/LW401/LW551i/LWU421/LWU501i Regulatory notices (continued) About Waste Electrical and Electronic Equipment The mark is in compliance with the Waste Electrical and Electronic Equipment Directive 2002/96/EC (WEEE). The mark indicates the requirement NOT to dispose the equipment including any spent or discarded batteries or accumulators as unsorted municipal waste, but use the return and collection systems available. -
Page 6: Preparing For The Remote Control
LX501/LX601i/LW401/LW551i/LWU421/LWU501i Preparating for remote control Please insert the batteries into the remote control before using it. If the remote control starts to malfunction, try to replace the batteries. If you will not use the remote control for long period, remove the batteries from the remote control and store them in a safe place. -
Page 7: Arrangement
LX501/LX601i/LW401/LW551i/LWU421/LWU501i Arrangement Refer to tables T-1 to T-5 at the back of this manual as well as the following to determine the screen size and projection distance. The values shown in the table are calculated for a full size screen. -
Page 8: Connecting With Your Devices
LX501/LX601i/LW401/LW551i/LWU421/LWU501i Connecting with your devices Before connecting the projector to a device, consult the manual of the device to confirm that the device is suitable for connecting with this projector and prepare the required accessories, such as a cable in accord with the signal of the device. -
Page 9: Fastening The Adapter Cover
LX501/LX601i/LW401/LW551i/LWU421/LWU501i Fastening the adapter cover Use the supplied adapter cover to prevent the USB wireless adapter from coming off easily. When using the adapter cover, connect the USB wireless adapter to the further USB TYPE A port from the LAN port. -
Page 10: Connecting Power Supply
LX501/LX601i/LW401/LW551i/LWU421/LWU501i Connecting power supply Put the connector of the power cord into the AC IN AC IN (AC inlet) of the projector. Power Firmly plug the power cord’s plug into the cord outlet. In a couple of seconds after the power supply connection, the POWER indicator will light up in steady orange. -
Page 11: Turning On The Power
LX501/LX601i/LW401/LW551i/LWU421/LWU501i Turning on the power Make sure that the power cord is firmly and correctly connected to the projector and the outlet. POWER indicator Make sure that the POWER indicator is lighted in steady orange. Then remove ON button the lens cover. -
Page 12: Adjusting The Projector's Elevator
LX501/LX601i/LW401/LW551i/LWU421/LWU501i Adjusting the projector’s elevator When the place to put the projector is slightly uneven to the left or right, use the elevator feet to place the projector horizontally. Using the feet can also tilt the projector in order to project at a suitable angle to the screen,... -
Page 13: Displaying The Picture
LX501/LX601i/LW401/LW551i/LWU421/LWU501i Displaying the picture Activate your signal source. Turn the signal source on, and make it send the signal to the VOL + / - projector. buttons Use the VOL + / - buttons to adjust the volume. Press the INPUT button on the projector. -
Page 14: Turning Off The Power
LX501/LX601i/LW401/LW551i/LWU421/LWU501i Turning off the power POWER indicator Press the STANDBY/ON button on the projector or the STANDBY button on STANDBY button the remote control. The message “Power off?” will appear on the screen for about 5 seconds. Press the STANDBY/ON or STANDBY button again while the message appears. -
Page 15: Replacing The Lamp
Preparation of a new lamp and early replacement are recommended. To prepare a new lamp, make contact with your dealer and tell the lamp type number. Type number <LX501, LW401, LWU421> : 003-120707-01 (DT01285) < LX601i, LW551i, LWU501i> : 003-120708-01 (DT01295) Turn the projector off, and unplug the power cord. - Page 16 LX501/LX601i/LW401/LW551i/LWU421/LWU501i Replacing the lamp (continued) HIGH VOLTAGE HIGH TEMPERATURE HIGH PRESSURE WARNING ►The projector uses a high-pressure mercury glass lamp. The lamp can break with a loud bang, or burn out, if jolted or scratched, handled while hot, or worn over time. Note that each lamp has a different lifetime, and some may burst or burn out soon after you start using them.
-
Page 17: Cleaning And Replacing The Air Filter
LX501/LX601i/LW401/LW551i/LWU421/LWU501i Cleaning and replacing the air filter Please check and clean the air filter periodically. When the indicators or a message prompts you to clean the air filter, comply with it as soon as possible. The filter unit with 2 sheets of filters is inside of the filter cover. An extra air filter is also attached to inner side of the filter cover. - Page 18 LX501/LX601i/LW401/LW551i/LWU421/LWU501i Cleaning and replacing the air filter (continued) Put the filter cover back into the place. Turn the projector on and reset the filter time using the FILTER TIME item in the EASY MENU. (1) Press the MENU button to display a menu.
-
Page 19: Using The Cd Manual
LX501/LX601i/LW401/LW551i/LWU421/LWU501i Using the CD manual The other manuals for this product are written into the included CD-ROM titled “Projector User Manual”. Before using the CD-ROM, please read the following to ensure the proper use. System requirements The system for using the CD-ROM requires the following. -
Page 20: Specifications
Liquid Crystal Panel 1,024,000 pixels (1280 horizontal x 800 vertical) LW U421, LWU501i: 2,304,000 pixels (1920 horizontal x 1200 vertical) LX501, LW401, LWU421: 245 W UHP Lamp LX601i, LW551i, LWU501i: 330 W UHP Speaker 8 W x2 L X501, LW401, LWU421: AC100-120 V: 3.8 A, AC220-240 V: 1.9 A... - Page 21 CONTROL ..........D-sub 9 pin plug x1 LAN ..............RJ45 jack x1 REMOTE CONTROL IN .... 3.5 mm (stereo) mini jack x1 REMOTE CONTROL OUT ..3.5 mm (stereo) mini jack x1 Lamp: <LX501, LW401, LWU421> 003-120707-01 (DT01285) < LX601i, LW551i, LWU501i> 003-120708-01 (DT01295)
-
Page 22: Troubleshooting - Warranty And After-Service
LX501/LX601i/LW401/LW551i/LWU421/LWU501i Troubleshooting - Warranty and after-service If an abnormal operation (such as smoke, strange odor or excessive sound) should occur, stop using the projector immediately. Otherwise if a problem occurs with the projector, first refer to “Troubleshooting” of User Manual - Operating Guide, Network Guide and Instant Stack Guide, and run through the suggested checks.
