- Page 1 LevelOne User Manual VDS-0120 VDSL2 Ethernet Converter(PSE)
-
Page 2: Table Of Contents
Table of Content 1. Introductions ............3 2. Application Notes ..........3 3. Features ..............4 4. Packing Contents ..........4 5. LED Indicators ............5 6. Dip Switches Settings ........... 5 7. Data Rates & Distances ........7... -
Page 3: Application Notes
With plug and play features and minimum installation time, each VDS-0120 can be configured into either CO for central side or RT for remote side by dip switch setting. The VDS-0120 conforms to the ITU-T G.993.1 and G.993.2 to meet VDSL/VDSL2 and SG15Q4 DMT for network requirements. -
Page 4: Packing Contents
4. Packing Contents Inside the package you should find: (1) One VDS-0120 VDSL2 PSE LAN Extender (2) One AC to DC Power Adaptor (DC12V/2.5A) (3) One User Manual CD Please check if the packing is damaged or any component is missing. If so, please contact your... -
Page 5: Led Indicators
5. LED Indicators On the front panel of VDS-0120, there are four LED indicators as the following VDS-0120 Rear Panel POWER: “Green On” indicates power is on and normal. LAN: “Green On” indicates Ethernet LAN port is in connection. “Flashing” indicates Ethernet LAN data activities. - Page 6 Pin 1: VTU-C/R Switch VTU-C: VDS-0120 will act as at the Central Office (CO) side. VTU-R: VDS-0120 will act as at the Customer Premise Equipment (CPE) or Remote side. Pin 2: Mode for impulse noise protection Interleave mode: Protection for up to 250ms impulse noises with latency less than 6 ms.
-
Page 7: Data Rates & Distances
9dB: Higher SNR margin (9dB) will result in less error with more stable VDSL2 link. 6dB: Original and Normal channel noise protection with 6 dB SNR. 7. Data Rates & Distances Performance in AWG 26 Line at 6dB with full rate Down Stream Up Stream Distance...
