Windows* XP*.
Software installation is flexible and fully automated for Microsoft Windows XP
Home Edition and Windows XP Professional operating systems.
* Other brands and names may be claimed as the property of others.
RAID Overview
RAID (Redundant Array of Independent Disks) refers to multiple independent hard
drives combined to form one large logical array. With RAID in place, the operating
system (e.g. Windows* XP*) no longer deals with individual drives, but instead with
the entire disk array as one logical drives.
The major objectives of RAID are to improve data availability and security. This
version of the Intel Application Accelerator RAID Edition supports RAID Level 0.
RAID Levels 1, 4, 5, and 10 are currently not supported.
Installation CAUTION: When setting up RAID configurations and creating a
volume, it is important to understand that installing the Intel® Application
Accelerator RAID Edition on a system will DELETE ALL EXISTING DATA
from the RAID-controlled hard drive(s) and the data cannot be recovered. It is
important to backup all important data before proceeding with installation.
Uninstall CAUTION: It is important to understand that uninstalling the Intel®
Application Accelerator RAID Edition from a RAID-configured system will
DELETE ALL EXISTING DATA from the RAID-controlled hard drive(s) and
the data cannot be recovered. It is important to backup all important data before
uninstalling.
RAID Levels – How the Drives are organized
Each level of RAID spreads the data across the drives of the array in different way
and is optimized for specific situations.
RAID 0
RAID Level 0 combines two or more hard drives in a way that the data coming from
the user is cut into manageable blocks. These blocks are striped across the different
drives of the RAID 0 array. By doing this, two or more hard drives are combined and
the read/write performance, especially for sequential access, can be improved.
However, no redundancy information is stored in a RAID 0 array, which means that if
one hard drive fails, all data is lost. This lack of redundancy is also stated in the
number 0, which indicates no redundancy. RAID 0 is thus usually not used in servers
where security is a concern.
Appendix
77
Appendix
RAID 0 Advantage: Highest transfer rates
RAID 0 Disadvantage: No redundancy – if one disk fails, all data will be lost
RAID 0 Application: Typically used in workstations for temporary data and high
I/O rate
System Requirements
In order to use the Intel® Application Accelerator RAID Edition, the following
system requirements must be met:
Desktop-based computer system
Intel® Pentium® 4 processor
Intel® 865 chipset with an Intel® 82801ER I/O Controller Hub
Minimum 128 MB physical memory
Two Serial ATA (SATA) hard drives
Microsoft* Windows* XP* Home Edition or Windows XP Professional.
System BIOS with the Intel® RAID Option ROM
Operating Systems not supported:
Any Version of Microsoft Windows 98, Windows Millennium Edition* (Me)
Microsoft Windows 2000 Professional, Windows 2000 Server, Windows 2000
Advanced Server, and Windows 2000 Data center Server
Microsoft Windows XP Server, Windows XP Advanced Server, and Windows
XP Data center Server
Any Version of Microsoft Windows 95
Microsoft Windows NT* 4.0
Any Version (including service pack) of Microsoft Windows NT 3.51
Any Version of Microsoft Windows 3.1
Linux*
UNIX*
BeOS*
MacOS*
OS/2* (any version)
MS-DOS*
* other brands and names may be claimed as the property of others.
General Features
Intel® Application Accelerator RAID Edition has the following features available in
property pages
:
RAID – This property page, available for all matching system configurations,
