CHAINTECH 9CJS User Manual page 21

Hyper-Threading Technology
Available options are [Enabled] and [Disabled]. Select [Enable] to support
Hyper-Threading Technology and vice versa.
Quick Power On Self Test:
Enable this function to reduce the amount of time required to run the POST (Power
On Self Test). BIOS will save time by skipping some items during POST. It is
recommended that you disable this setting. Discovering a problem during boot up is
better than loosing data during your work.
Hard Disk Boot Priority:
Select priority of the hard disk boot device.
First/Second/Third/Boot Other Device:
This option sets the sequence of drives BIOS attempts to boot from after POST
completes. BIOS will search these drives for an operating system.
Swap Floppy Drive:
Enabling this function will swap the floppy drive assignment so that drive A will
function as drive B, and drive B will function as drive A. Note that the boot
sequence assignment mentioned directly above does not include booting from floppy
drive B. This function is useful if floppy drives B and A are of different types of
drives and you want to boot from floppy drive B.
Boot up Floppy Seek:
This is a set up check for floppy power-on after starting the computer system.
Boot Up NumLock Status:
This function defines the keyboard's number pad as number keys or arrow keys. If it
is set at On the number keys will be activated, if it is set at Off the arrow keys will
be activated.
Gate A20 Option:
This allows you to set the Gate A20 status. When set to [Fast], Gate A20 is cont
rolled by chipset. When set to [Normal], Gate A20 is cont rolled by a specific pin
from the keyboard controller. Available options are [Fast] and [Normal].
Keyboard Interface：
1. Typematic Rate Setting
When enabled, you can set the following two-typematic control items. When
disabled, the keyboard controller determines keystrokes arbitrarily in your system.
Chapter 3
35
Chapter 3
2. Typematic Rate (Chars/Sec)
The typematic rate sets the rate at which characters on the screen repeat when a key
is pressed and held down.
3. Typematic Delay (Msec)
The typematic delay sets how long after you press a key that a character begins
repeating.
Security Option:
The Supervisor and/or User Password functions shown in Figure 3-1 must be set to
take advantage of this function. See Section 3.11 for password setting information.
When the Security Option is set to System, a password must be entered to boot up
the system or enter the BIOS setup program. When the Security Option is set to
Setup, a password is required to enter the BIOS setup program.
APIC Mode
In order to comply with PC2001 standard, the system is designed to run in APIC
(Advanced Programmable Interrupt Controller) mode. Enabling APIC mode
will increase the available IRQs resources for the system. Available options are
[Enabled] and [Disabled].
MPS Version Control For OS
This item allows you to select which MPS (Multi-Processor Specification) version
is used for the operating system. You need to select the MPS version that is
supported by your operating system. To find out which version to use, consult the
vendor of your operating system. Available options are [1.4] and [1.1].
OS Select (For DRAM >64MB):
If your system's DRAM is larger than 64MB and you are running OS/2, select OS/2
as the item value. Otherwise, set the item value to Non-OS/2 for all other operating
systems.
Small Logo (EPA) Show
This setup allows photo that is EPA. Logo.
Show POST CODE
Enabling this function can show POST error code on the screen before proceeding to
system's operating system.
