Introduction
Chapter 1

1-1 Product Specifications

Processor
- Supports Intel® Socket 478 CPU with Hyper-Threading Technology
- Supports Intel® Pentium 4/Celeron system bus at 400/533/800MHz
Chipset
- Intel® 875P + ICH5R, supports Hyper-Threading Technology
Main Memory
- Supports four 184 pin DDR DIMMs up to 4GB
- Supports Dual-Channel DDR266/333/400 ECC memory and Performance
Accelerated Technology (PAT)
Expansion Slots
- One 1.5V AGP slot for 8X/4X AGP
- Five 32-Bit PCI slots (v2.2 compatible)
- One CMR (Chaintech Multimedia Raiser) for Chaintech Multimedia Card (CMC)
On-board 7.1 Channel audio
- 24-bit resolution audio format support
- Sampling rates up to 96 KHz
- Multi-channel AC-link supported alternatively
- Supports SPDIF Out
Two UltraDMA-66/100 IDE Ports
- Supports PIO Mode 4 up to 16.6MBps, Multi -Word DMA Mode 2 and Ultra DMA
Mode 5 up to 100MB/s with Bus Mastering
- Bus-Mastering software drivers for all common multi-tasking operating systems
On-board SATA RAID Controller
- Build-in ICH5R supports 2 Serial ATA devices for the highest data transfer rates (1.5
Gbps burst) with RAID 0 solution
On-board VIA VT6306 IEEE1394 Host Controller
- Serial bus data rates of 100,200 and 400 Mbps
- IEEE P1394a compliant and IEEE Std 1394-1995
- Programmable ATA/ATAPI interface supporting PIO modes 0-4, DMA modes 0-2
and Ultra DMA modes 0-4
Chapter 1
1
Chapter 1
Embedded USB 2.0 Host Controller
- Three EHCI USB 2.0 Controllers support total 8 USB 2.0/1.1 Ports
- Support USB 2.0 High-Speed Device @ 480 Mb/s Transfer Rates
- Optional USB adapters for additional USB 2.0/1.1 ports
Dual LAN: Intel CSA Gigabit LAN & Fast Ethernet Controller
- On-board Intel CSA GbE controller supports 10/100/1000 BASE-T Gigabit LAN
- On-board Realtek RTL8101L supports 10/100 Mb Fast Ethernet
On board Super I/O Controller
- ITE 8712 LPC I/O with system monitors hardware
- Two UARTs support serial ports and IR function (up to 115.2Kbps) for HPSIR and
ASKIR
- One SPP/ECP/EPP parallel port
- One floppy disk drive connector supports up to 2.88MB
Boot-Block Flash ROM
- Award system BIOS support PnP, APM, DMI, ACPI, & Multi-device booting
features
Embedded system monitoring
- 8 external voltage inputs
- 2 temperatures sensing for CPU and system
- 3 Fan speed (CPU, system and Case) monitoring
