CHAINTECH
Declaration of Conformity
According to 47 CFR, Parts 2 and 15 of the FCC Rules
9LIF1
The following designated product:
EQUIPMENT: MAINBOARD
MODEL NO.: 9LIF1
Intel® Socket 478
Intel® 845GL + ICH4
u-ATX Motherboard
is a Class B digital device that complies with 47 CFR Parts 2 and 15 of the FCC
Rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that
may cause undesired operation.
User's Manual
This declaration is given to the manufacturer:
CHAINTECH-EXCEL COMPUTER INC.
4427 Enterprise St. Fremont, CA 94538, U.S.A.
http://www.chaintech-excel.com
Chaintech President: Simon Ho
Signature:
V.2_E
Advertisement
Related Manuals for CHAINTECH 9LIF1
Summary of Contents for CHAINTECH 9LIF1
- Page 1 According to 47 CFR, Parts 2 and 15 of the FCC Rules 9LIF1 The following designated product: EQUIPMENT: MAINBOARD MODEL NO.: 9LIF1 Intel® Socket 478 Intel® 845GL + ICH4 u-ATX Motherboard is a Class B digital device that complies with 47 CFR Parts 2 and 15 of the FCC Rules.
-
Page 2: Manufacturer's Disclaimer Statement
Federal Communications Commission Statement This device complies with FCC Rules Part 15. Operation is subject to the following two conditions: * This device may not cause harmful interference. * This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. -
Page 3: Table Of Contents
TABLE OF CONTENTS Chapter 1 Introduction ............1 1-1 Product Specifications ..................1 1-2 Package Contents.....................2 1-3 9LIF1 Motherboard Diagram ................3 1-4 9LIF1 Motherboard Layout ................4 Chapter 2 Hardware Setup............5 2-1 Installing a CPU Processor for Socket 478 .............5 2-2 Setting Your CPU’s Performance: ..............5 2-3 Main Memory Configuration................6... -
Page 4: Chapter 1 Introduction
Chapter 1 Chapter 1 On board Super I/O IT 8702Controller Chapter 1 Introduction Two UARTs support serial port s and IR function (up to 115.2Kbps) for HPSIR and ASKIR 1-1 Product Specifications One SPP/ECP/EPP parallel port Processor One floppy disk drive connector supports up to 2.88MB Supports Intel®... -
Page 5: 9Lif1 Motherboard Diagram
Chapter 1 Chapter 1 1-3 9LIF1 Motherboard Diagram 1-4 9LIF1 Motherboard Layout... -
Page 6: Chapter 2 Hardware Setup
Chapter 2 Chapter 2 (please refer to Chapter3 for more details). Chapter 2 Hardware Setup You do not need to make voltage settings because this board will automatically If your motherboard has already been installed in your computer you may still need set your CPU voltage. -
Page 7: Connector And Jumper Settings
Chapter 2 Chapter 2 2-5 Connector and Jumper Settings poly-fuse will immediately be disconnected from the circuit, just like a normal fuse. Connectors are used to link the system board with other parts of the system, After being disconnected for a certain period of time, the poly-fuse will return to its including the power supply, the keyboard, and the various controllers on the front normal state. -
Page 8: Cn5 [Wol (Wake-On-Lan) Connector]
Chapter 2 Chapter 2 JP23 (Green LED Mode Jumper) OPTIONAL: The system is woken up whenever the keyboard or mouse is touched. The system Definition This cap is to setup Green LED flash mode. resumes in different ways as defined by Power Management Setup screen in BIOS. 1-2 Normal (default) For Green LED connector please refer to Section 2.7 CBOX™... -
Page 9: Cn24 (Front Audio Connector)
Chapter 2 Chapter 3 CN7 (Smart Card Reader Connector): Chapter 3 BIOS Setup Program This connector must be connected to a Smart card reader. Phoenix-Award BIOS ROM has a built-in setup program that allows users to modify the basic system configuration. This information is stored in CMOS RAM so that it can retain the setup information, even when the power is turned off. -
Page 10: Standard Cmos Setup
Chapter 3 Chapter 3 3-2 Advanced BIOS Features 3-1 Standard CMOS Setup By choosing the Advanced BIOS Features option from the CMOS Setup Utility The Standard CMOS Setup allows users to configure system components such as menu (Figure 3-1), the screen below is displayed. This sample screen contains the hard disk drive, floppy disk drive and video display as well as date, time and manufacturer's default values for the motherboard. -
Page 11: Keyboard Interface
Chapter 3 Chapter 3 completes. BIOS will search these drives for an operating system. Controller). Due to compliance to PC2001 design guide, the system is able to run in APIC mode. Enabling APIC mode will expand available IRQs resources for the Swap Floppy Drive: system. -
Page 12: Advanced Chipset Features
Chapter 3 Chapter 3 3-4 Integrated Peripherals 3-3 Advanced Chipset Features This section provides information on setting peripheral devices. By choosing the By choosing the [Advanced Chipset Features] option from the CMOS Setup Integrated Peripherals option from the CMOS Setup Utility menu (Figure 3-1), the Utility menu (Figure 3-1), the screen below is displayed. - Page 13 Chapter 3 Chapter 3 3. IDE Primary/Secondary Master/Slave UDMA: 1. Onboard FDC Controller: Ultra DMA implementation is possible only if your IDE device supports it and Select Enabled if your system has a floppy disk controller (FDC) installed on the your operating environment contains a DMA driver.
-
Page 14: Power Management Setup
Chapter 3 Chapter 3 enable this setting. If you pass the boot up stage without enabling this function, your 1. Blank Screen - BIOS will only blank the monitor's screen. The electricity saved PS/2 keyboard will no longer work. in this mode is negligible and this function is only used as a screen saver to prevent screen damage while the screen is on but not in use. -
Page 15: Pnp/Pci Configurations
Chapter 3 Chapter 3 Wake up Events 3-6 PNP/PCI Configurations 1. Power On by PCI Card: This section provides IRQ and DMA setting information. By choosing the PNP/PCI When enabled, a PCI interface that receives a signal will wake up the system from Configuration option from the CMOS Setup Utility menu (Figure 3-1), the screen soft off and green mode. -
Page 16: Pc Health Status
Chapter 3 Chapter 3 3-7 PC Health Status CPU Clock Ratio: By choosing the PC Health Status option from the CMOS Setup Utility menu This feature allows user to manually configure your CPU clock ratio according to (Figure 3-1), the screen below is displayed. This field shows you the current system your processor’s specifications. -
Page 17: Save And Exit Setup
Setup program without recording any new values or changing old ones. NOTE All rights are reserved for the products and corporate names/logos that appear in this manual to their original owners. CHAINTECH reserves all the rights to change this manual .All information is subject to change without notice.
