Basic Operation

Turning the power On or Off
PWR
Press and hold [ ] for 1 sec. to turn the power On or Off.
Selecting a Frequency Band
BAND●MODE
1. Press [
2. Rotate the Dial to select the band.
BAND●MODE
3. Press [
You can select between 2m and 70cm bands for transmission,
and 127 MHz, 2m, 220 MHz, 350 MHz, 70cm, 500 MHz, and
900 MHz bands for reception.
Activating VFO Mode
V/MHz●SCAN
Press [ ] to activate the VFO mode.
Alternatively: Press the HM-133 microphone
VFO/LOCK
button [ ] to activate VFO mode.
Operating in VFO Mode
● If necessary, press
[
● To change the frequency using 1 KHz steps, rotate the Dial.
● To change the frequency using 100 KHz, 1 MHz, or 10 MHz steps:
V/MHz●SCAN
1. Press [
KHz, 1 MHz, and 10 MHz tuning steps.
DIAL
2. Rotate [ ] to change the frequency.
● To start a scan, press and hold
● To stop a scan, press
Activating Memory Mode
M/CALL●PRIO
Press [ ] to activate Memory mode.
The indicator icon appears on the LCD display
when Memory mode is activated.
Icom ID–800H Mini–Operating Guide by W5JCK, September 2007
].
] to activate the desired band.
V/MHz●SCAN
] to activate the VFO mode.
] one or more times to toggle between 100
V/MHz●SCAN
[
V/MHz●SCAN
[ ].
Alternatively: See "Using the HM-133
Microphone" section for instructions on
using the microphone to select a band.
] for 1 second.
Alternatively: Press the HM-133 microphone
MR/CALL
button [
Note: The digit associated with
each tuning step (100 KHz, 1
MHz, or 10 MHz) disappears
when that step is selected.
] to activate Memory mode.
Page 3 of 6
