The ServerGuide program requires a supported IBM server with an enabled
startable (bootable) CD drive. In addition to the ServerGuide Setup and Installation
CD, you must have your operating-system CD to install the operating system.
The ServerGuide program performs the following tasks:
v Sets system date and time
v Detects the RAID adapter or controller and runs the SAS/SATA RAID
v Checks the microcode (firmware) levels of a ServeRAID adapter and determines
v Detects installed hardware options and provides updated device drivers for most
v Provides diskette-free installation for supported Windows operating systems
v Includes an online readme file with links to tips for your hardware and
Important: Before you install a legacy operating system (such as VMware) on a
server with an LSI SAS controller, you must first complete the following steps:
1. Update the device driver for the LSI SAS controller to the latest level.
2. In the Setup utility, set Legacy Only as the first option in the boot sequence in
3. Using the LSI Configuration Utility program, select a boot drive.
For detailed information and instructions, go to https://www-947.ibm.com/systems/
support/supportsite.wss/docdisplay?lndocid=MIGR-5083225.

Setup and configuration overview

When you use the ServerGuide Setup and Installation CD, you do not need setup
diskettes. You can use the CD to configure any supported IBM server model. The
setup program provides a list of tasks that are required to set up your server model.
On a server with a ServeRAID adapter or SAS/SATA controller with RAID
capabilities, you can run the SAS/SATA RAID configuration program to create
logical drives.
Note: Features and functions can vary slightly with different versions of the
ServerGuide program.

Typical operating-system installation

The ServerGuide program can reduce the time it takes to install an operating
system. It provides the device drivers that are required for your hardware and for
the operating system that you are installing. This section describes a typical
ServerGuide operating-system installation.
Note: Features and functions can vary slightly with different versions of the
ServerGuide program.
1. After you have completed the setup process, the operating-system installation
2. The ServerGuide program stores information about the server model, service
3. The ServerGuide program presents operating-system partition options that are
configuration program
whether a later level is available from the CD
adapters and devices
operating-system installation
the Boot Manager menu.
program starts. (You will need your operating-system CD to complete the
installation.)
processor, hard disk drive controllers, and network adapters. Then, the program
checks the CD for newer device drivers. This information is stored and then
passed to the operating-system installation program.
based on your operating-system selection and the installed hard disk drives.
