v The following table lists the maximum DIMM population using ranked UDIMMs.
v The following table shows the UDIMM memory population rule to optimize the
The following illustration shows the location of the DIMM connectors on the system
board.
30
System x3100 M4 Type 2582: Installation and User's Guide
Table 3. Supported UDIMM population per channel
DIMM
connectors per DIMMs installed
channel in each channel DIMM type
2 1
2 2
Table 4. Maximum memory population using ranked UDIMMs (depending on your model)
Number of UDIMMs DIMM type
4 Single-rank UDIMMs
4 Dual-rank UDIMMs
4 Dual-rank UDIMMs
4 Dual-rank UDIMMs
system performance.
Table 5. UDIMM population rule
DIMM connector 1 DIMM connector 2
Populated Empty
Populated Empty
Populated Populated
DIMM speed
Unbuffered 1066, 1333
DDR3 ECC
Unbuffered 1066, 1333
DDR3 ECC
Size
1 GB
2 GB
4 GB
8 GB (when
available)
DIMM connector 3
Empty
Populated
Populated
Ranks per
DIMM (any
combination)
Single-rank,
dual-rank
Single-rank,
dual-rank
Total memory
4 GB
8 GB
16 GB
32 GB
DIMM connector 4
Empty
Empty
Populated
