Page 1: Reference Manual
C AD REF loop REF in Y 2 in Y 1 in 5131 U/C2 in U/C 1 in V 2 in V 1 in SDI out 2 SDI out 1 © LYNX Technik AG Brunnenweg 3 D-64331 Weiterstadt Germany www.lynx-technik.com... - Page 2 Except as expressly written by LYNX Technik AG, the furnishing of this document does not give you any license to patents, trademarks, copyrights or other intellectual property of LYNX Technik AG or any of its affiliates.
-
Page 3: Warranty
LYNX Technik, with shipping charges prepaid. LYNX Technik shall pay for the return of the product to the customer if the shipment is within the country which the LYNX Technik service center is located. -
Page 4: Regulatory Information
Reference Manual C AD 5131 Version1.1 Regulatory information Europe Declaration of Conformity LYNX Technik AG Brunnenweg 3 D-64331 Weiterstadt Germany Declare under our sole responsibility that the product TYPE: C AD 5131 To which this declaration relates is in conformity with the following... -
Page 5: Table Of Contents
Reference Manual C AD 5131 Version1.1 Contents Warranty ......................3 Regulatory information..................4 Europe........................4 Declaration of Conformity ................4 USA ........................4 FCC 47 Part 15.....................4 Contents.......................5 Getting Started ....................7 Packaging......................7 Product Description ..................7 Functional Diagram ..................8 Module Layout ....................8 Connections ......................10 Video Connections..................10 Installation ......................11 Settings and Control ..................12 Multi Function Switch ..................13... - Page 6 Reference Manual C AD 5131 Version1.1 This page is intentionally left blank Page 6...
-
Page 7: Getting Started
Reference Manual C AD 5131 Version1.1 Getting Started Packaging The shipping carton and packaging materials provide protection for the module during transit. Please retain the shipping cartons in case subsequent shipping of the product becomes necessary. Product Description The C AD 5131 is a high performance 12 Bit Video A/D Converter for component analog YUV and S- video signals and is designed primarily for broadcast and professional applications. -
Page 8: Functional Diagram
Reference Manual C AD 5131 Version1.1 Functional Diagram Figure 1 below is the basic functional diagram for the C AD 5131 CardModule. Rack Reference Ref IN Test Signal Genlock REF Loop SDI out 1 Y 1 in Line Synchronizer U/C 1 in SDI out 2 V 1 in Selectable... - Page 9 Reference Manual C AD 5131 Version1.1 PCB Layout Rear Connection Panel Analog Video to SDI Conv. & Line Synch LYNX Technik AG PCB Front View LED 1 LED 2 C AD Matrix Display 5111 5131 Press LED 3 (Alarm) ENTER LED 4 Figure 2 –...
-
Page 10: Connections
Reference Manual C AD 5131 Version1.1 Caution Use static precautions when handling the PCB. Static discharge could result in serious damage to the module. Connections Video Connections The C AD 5131 CardModule is configured with standard 75 Ohm BNC connectors. Connection is self-explanatory. -
Page 11: Installation
Reference Manual C AD 5131 Version1.1 Installation Caution The CardModule is shipped in a protective anti-static bag. Please take suitable precautions to avoid static discharge onto any part of the PCB or components when handling module or serious damage could result. Each Card Module is supplied with a rear connection panel and two mounting screws. -
Page 12: Settings And Control
Reference Manual C AD 5131 Version1.1 Settings and Control The C AD 5131 has an integrated micro-controller, which enables the module to be configured and controlled locally using the multifunction switch and 4 character dot matrix display, or from remote when using one of the optional controllers and control software. -
Page 13: Multi Function Switch
Reference Manual C AD 5131 Version1.1 Multi Function Switch The CardModule is equipped with a multi-function switch located on the front bottom edge of the card (refer to figure 3) Multi-function Switch Side Front Switch Operations Down Enter Figure 4 – Switch Operation Page 13... -
Page 14: Using The Local Display Menus
• Luma-/ chroma filter settings • Auto-/ manual gain control • Test signal select A set of extended adjustments is possible when using a controller option and LYNX control software. Adjustments (in addition to the basic adjustments above) include: Page 14... -
Page 15: Menu Structure
Reference Manual C AD 5131 Version1.1 • Adjustable Luma / chroma peaking filters • Adjustable Coring function • Adjustable Contrast, Saturation, Brightness and • Analog / digital clamp disable • Automatic Gain Control mode reference select • Luma / Chroma shaping filter for YC (S-Video) mode •... - Page 16 Reference Manual C AD 5131 Version1.1 Page 16...
- Page 17 Reference Manual C AD 5131 Version1.1 Page 17...
- Page 18 Reference Manual C AD 5131 Version1.1 Page 18...
- Page 19 Reference Manual C AD 5131 Version1.1 Page 19...
-
Page 20: Factory Preset Condition
Reference Manual C AD 5131 Version1.1 Factory Preset Condition The C AD 5131 is delivered programmed and preset for the following mode of operation: Input Input A Analog Filter Standard Auto Clamp Fast Genlock HI Q Reference External Line delay 0000 Pixel delay 0000... -
Page 21: Alarm/Led Status Indicators
Reference Manual C AD 5131 Version1.1 Alarm/LED Status Indicators The C AD 5131 module has integral LED indicators, which serve as alarm and status indication for the module. Function is described below. Status Indicators 3 status LED`s are provided on the front edge of the module, LED 1, LED 2. -
Page 22: Locate Function
Reference Manual C AD 5131 Version1.1 Locate Function For larger systems which may have multiple cards of the same type in a single rack, or multiple rack systems on a large central control system we have added a useful utility which will help to visually locate a suspect module quickly (When used in conjunction with the optional control system and software) -
Page 23: Specifications (C Ad 5131)
Reference Manual C AD 5131 Version1.1 Specifications (C AD 5131) Inputs (video) Signal Y Cr Cb or Y C (S-Video), one out of two inputs selectable. AC coupled, differential inputs. Sync on Y Input Impedance 75 Ohms Connection Inputs (ext reference) Composite sync (black burst) Signal Input Impedance... -
Page 24: Available Options
Reference Manual C AD 5131 Version1.1 Available Options Below is a list of related products for the C AD 5131 CardModule. Please refer to product brochures or our web site for more detailed information. Model Description Series 5000 Rack Frame (empty) with single R FR 5010 power supply Redundant power supply for the R FR 5010... -
Page 25: Service
Warranty. Please contact your distributor or check our web site for details on this program. More detailed information and product updates may be available on our web site: www.lynx-technik.com You will also find links to contact us directly for assistance. Page 25... -
Page 26: Contact Information
Reference Manual C AD 5131 Version1.1 Contact Information Please contact your local distributor; this is your local and fastest method for obtaining support and sales information. LYNX Technik can be contacted directly using the information below. Address LYNX Technik AG Brunnenweg 3 D-64331 Weiterstadt Germany. - Page 27 Reference Manual C AD 5131 Version1.1 Notes Page 27...
