    TC-610/TC-610P Owner’s Manual Contents Safety Information ............................3 Product Inspection............................4 Radio Overview ............................6 Battery Information ...........................10 Antenna Information ..........................13 Assembly and Disassembly........................13 General Radio Operations .........................20 Programmable Auxiliary Functions ......................22 Functions and Settings ..........................22 CTCSS/CDCSS..........................22 Battery Save ............................23 Power Adjust .............................23 Time-out Timer (TOT) ........................23...
  • Page 2 TC-610/TC-610P Owner’s Manual Preface Thank you for your purchase of the HYT TC-610/610P radio - the choice for professionals. TC-610/610P is a professional radio that with exquisite and ergonomic design, which bring user a fine operation feel. The TC-610/610P is customized for noisy environments such as construction sites because all TC-610/610P radios are approved to dust &...

  • Page 3: Safety Information

    TC-610/TC-610P Owner’s Manual Safety Information The following general safety precautions as would normally apply, which should be observed during all phases of operation, service and repair of this equipment. ◇ Turn off your radio prior to entering any area with a potentially explosive atmosphere.

  • Page 4: Product Inspection

    Before unpacking the TC-610/610P portable radio, please inspect the packaging for signs of damage and report any damage to your dealer. Upon unpacking of the TC-610/610P portable radio, please ensure that all items shipped were received, report any missing or damaged items to your dealer.
  • Page 5 TC-610/TC-610P Owner’s Manual Li-Ion Battery Rapid-rate Charger (for Switching Power (different P/N for Li-ion/Ni-MH Batteries) different countries and areas) Belt Clip Strap Antenna...

  • Page 6: Radio Overview

    TC-610/TC-610P Owner’s Manual Radio Overview TC-610 (1) PTT (Push-to-Talk) (2) SK1 key (Side Key 1) (3) SK2 (Side Key 2) (4) Speaker (programmable) (programmable) (5) Microphone (6) Antenna (7) LED Indicator (8) Channel Selector Knob Radio On-Off (10) Battery Latch...
  • Page 7 TC-610/TC-610P Owner’s Manual TC-610P (1) PTT (Push-to-Talk) (2) SK1 key (Side Key (3) SK2 (Side Key 2) (4) Speaker 1) (programmable) (programmable) (5) Microphone (6) Antenna (7) LED Indicator Channel Selector Knob Radio On-Off (10) Battery Latch (11) Accessory Jack...
  • Page 8 TC-610/TC-610P Owner’s Manual * PTT (Push-to-Talk) Key Press and hold down the PTT key to transmit, release it to receive. *SK1 (Side Key 1) Side Key 1 is the programmable key that can be assigned with long press function and short press function by your dealer.
  • Page 9 TC-610/TC-610P Owner’s Manual is in process. Scan Start Alert Tone (programmable by your dealer): a beep is heard. Scan Exit Alert Tone (programmable by your dealer): a beep is heard. Priority Channel Scan Alert Tone (programmable by your dealer): when scanning, if the current channel is the priority channel, the radio sounds a Beep.

  • Page 10: Battery Information

    TC-610/TC-610P Owner’s Manual Battery Information Initial Use New batteries are shipped uncharged from the factory. Charge a new battery for 5 hours before initial use. The maximum battery capacity and performance is achieved after three full charge/discharge cycles. If you notice the battery power runs low, please recharge the battery.
  • Page 11 Charging Operation When the radio flashes red LED and sounds low-pitched tone at intervals of ten seconds, indicating the battery power is low, please charge the battery by the HYT approved charger. The charger’s LED indicates the charging progress. Status...
  • Page 12 Red LED flashes rapidly (0.2s on/0.2s off)? Remove the battery from the charger, and: Make sure that it is a HYT authorized battery. Other batteries may not charge. Remove power from the battery charger, and clean the gold metal, charging contacts...

  • Page 13: Antenna Information

    Rainy days or forest locations may narrow your communication range, please prepare in advance to avoid potential inconvenience. Assembly and Disassembly (Note: Pictures listed below all take TC-610 as the sample) Attaching the Battery Hold the battery and make it close to the top of aluminum chassis. (See figure 1 below)
  • Page 14 TC-610/TC-610P Owner’s Manual Figure 1 Lightly press the bottom of the battery until a click is heard. By then, the battery latch locks with the main unit and assembly is finished. (See figure 2 below) Note: if the battery is not well locked, please remove the battery and attach it again.
  • Page 15 TC-610/TC-610P Owner’s Manual Figure 3 When the bottom of battery is lifted, release the battery latch and take out from the battery slot. (see figure 4 below) (Note: when battery is titled, the angle between battery and main unit can not be...
  • Page 16 TC-610/TC-610P Owner’s Manual Figure 5 Removing the Antenna When disassembling antenna, turn the antenna counter-clockwise until it is loosen and screwed out, shown as figure 6. Figure 6 Attaching the Belt Clip Loose the screw of belt clip from the main unit, fasten the belt clip to the main unit (make sure the screw holes of belt clip and of aluminum chassis are aligned), clockwise screw down the belt clip.
  • Page 17 Removing the Belt Clip Turn the screwdriver counter-clockwise to loosen the screw. Please refer to the operations for attaching the belt clip. (See figure 8 below) Figure 8 Attaching the Earpiece/Microphone (TC-610) Open (not remove) the accessory cover, shown as figure 9.
  • Page 18 TC-610/TC-610P Owner’s Manual Figure 9 Plug the audio accessory firmly into the accessory jack, then secure the screw, shown as figure 10. Figure 10 Attaching the Earpiece/Microphone (TC-610P) 1. Insert the tab at the bottom of the earphone/microphone into the slot on the radio.
  • Page 19 TC-610/TC-610P Owner’s Manual Figure 11 2. Plug the audio accessory firmly into the accessory jack, and then secure the screw, shown as figure 12. Figure 12...

  • Page 20: General Radio Operations

    Note: Using the radio with audio accessory may affect the waterproof performance of the radio. General Radio Operations (Note: Pictures listed below all take TC-610 as the sample) Note: See Glossary for definitions of relevant words. Turn the Radio On/Off Turn the radio on-off /volume control knob clockwise to turn on the radio, then radio sounds an alert tone.
  • Page 21 TC-610/TC-610P Owner’s Manual Figure 14 Select a Channel Turn the channel selector knob to select a channel. (See figure 15 below) Figure 15 Transmitting To transmit, press and hold down PTT key and talk to microphone to speak. Ensure the radio is 2.5 to 5 centimeters away from your lips.

  • Page 22: Programmable Auxiliary Functions

    TC-610/TC-610P Owner’s Manual Flat ground with no obstructions Up to 10 kilometers Residential area (close to buildings） Up to 5 kilometers Inside multi-level buildings Up to 20 floors Programmable Auxiliary Functions Your dealer may program the TK, SK1, SK2 (long or short press) keys with one of the following auxiliary functions respectively.

  • Page 23: Battery Save

    Your dealer may program the alert tone that sounds before the TOT timer nearly expires. See Glossary for the definition of Time-out Timer. Battery Strength Indicator The TC-610/610P allows you to simply press one button to illuminate the LED batter gauge, which emits different indications representing battery strength levels until the key is released.

  • Page 24: Monitor / Squelch Off

    TC-610/TC-610P Owner’s Manual Battery Strength LED Indication 70% - 100% Green 50% - 70% Orange 30% - 50% 10% - 30% No indication is shown when programmable key is pressed; LED flashes red while radio is operating. While the radio standby, LED flashes red and a low-pitched tone sounds at intervals of a preset time (defaulted as 10s).

  • Page 25: Scan

    TC-610/TC-610P Owner’s Manual Monitor Carrier condition must be satisfied for the radio to unmute to an incoming call, regardless of CTCSS/CDCSS condition. Press the function key to enter Monitor mode, and press it again to exit. Monitor Momentary Carrier condition must be satisfied for the radio to unmute to an incoming call, regardless of CTCSS/CDCSS condition.
  • Page 26 TC-610/TC-610P Owner’s Manual Priority Channel Scan If you prioritize Channel 2 as Priority 1, the scan operation would change as figure 17 shown below. Figure 17 Scan On/Off You can enter scan mode through the following two methods: 1. Key operation Press the programmed Scan key to enter scan mode, provided that there’re no less than 2...

  • Page 27: Busy Channel Lockout (Bcl)

    TC-610/TC-610P Owner’s Manual channel so that messages will not be missed. Check with your dealer for details. When scanning remains on a non-priority channel, the radio continues to monitor activities on the priority channel, and jumps to the priority channel if activity is detected.

  • Page 28: Atis

    TC-610/TC-610P Owner’s Manual Note: No matter whether the VOX feature is enabled, if you select the PTT/VOX switch on the earpiece to PTT, you are able to transmit by press of the external PTT, and you are not allowed to push the switch from PTT to VOX, this action shall cause the radio to continuously transmit.

  • Page 29: 2-Tone Decode

    TC-610/TC-610P Owner’s Manual HDC1200 PTT ID data. DOS time can be programmed by your dealer. Note: DOS enable check and DOS time can be programmed by your dealer. 2-Tone Decode （Available to TC-610P only） The function is to receive 2-tone signal that transmitted by radio with 2-tone encode and to respond the function according to the preset configuration.

  • Page 30: Troubleshooting

    TC-610/TC-610P Owner’s Manual Troubleshooting Symptom Solution a. The battery is run out. Please recharge the battery or replace it with a fresh one. Cannot power on the radio. b. The battery is not properly installed. Please remove and reinstall the battery.

  • Page 31: Care And Cleaning

    TC-610/TC-610P Owner’s Manual Care and Cleaning Do not handle the radio by its antenna or external microphone directly. Do not place the radio in a dusty or dirty environment. Clean the radio with a lint-free cloth to remove dirt or grease, to avoid poor contact due to excessive dust.

  • Page 32: Optional Accessory

    TC-610/TC-610P Owner’s Manual Optional Accessory Optional Accessories Antenna Ni-MH Battery (1300mAh) Li-Ion Battery (2000mAh) MCU Multi-unit Rapid-rate BH1303 BL2001 Charger (for Li-ion/Ni-MH Batteries) MCA02 Six-unit Switching Power Vehicle Adapter CHV09 Universal Nylon Chest Pack Leather Carrying Case PS7001 (Black) LCBN13...
  • Page 33 TC-610/TC-610P Owner’s Manual Light-weight, Light-weight, Single-muff Earpiece with on-MIC PTT & 2-wire Surveillance Earpiece Behind-the-head Earpiece Headset ECN07 Transparent Acoustic Tube with Transparent Acoustic ECN06 EAN04 Tube (black) EAN07 3-Wire Surveillance Earpiece 2-Wire Earpiece with Heavy Weight, Behind-the-Head, with Transparent...
  • Page 34 TC-610/TC-610P Owner’s Manual Programming Cable (USB port) PC25 TC-610 Optional Audio Accessories Earbud with in-line PTT & Earbud with on-MIC PTT & Earbud with in-line PTT & VOX D-earset with in-Line MIC & VOX ESM13 VOX ESM12 ESM11 VOX EHM15...
  • Page 35 TC-610/TC-610P Owner’s Manual Neck 2-wire Earpiece with Ear Canal Bone Induction Light Weight, Throat-Vibrating Noise-Canceling Headset Wireless Earphone and Neck Earpiece EBM01 Earpiece ELM01 ECM13 Loop(Beige) EWM03 Behind-the-Head, Remote Speaker Noise-Canceling Remote Noise-Cancelling Remote Noise-Canceling Headset Microphone SM08M3 Speaker Microphone...

  • Page 36: Channel Frequency Table

    TC-610/TC-610P Owner’s Manual Channel Frequency Table Model: Serial No.: Tx CTCSS Channel Frequency Frequency CTCSS/CDCSS /CDCSS (MHz) (MHz) CTCSS Table 38 Frequency (Hz) Frequency (Hz) 67.0 131.8 71.9 136.5 74.4 141.3 77.0 146.2 79.7 151.4 82.5 156.7 85.4 162.2...

  • Page 37: Cdcss Table (83)

    TC-610/TC-610P Owner’s Manual 88.5 167.9 91.5 173.8 94.8 179.9 97.4 186.2 100.0 192.8 103.5 203.5 107.2 210.7 110.9 218.1 114.8 225.7 118.8 233.6 123.0 241.8 127.3 250.3 CDCSS Table (83) CDCSS CDCSS...
  • Page 38 TC-610/TC-610P Owner’s Manual...

  • Page 39: Glossary

    TC-610/TC-610P Owner’s Manual Glossary Name Description Short Press Key press shorter than 1.5 seconds. Long Press Key press longer than 1.5 seconds. In normal mode, no key operation is made on the Standby Status radio and the radio is in receiving status.
  • Page 40 The radio will automatically begin transmitting when you speak. HYT endeavors to achieve the accuracy and completeness of this manual, but no warranty of accuracy or reliability is given. All the above specifications and design are subject to change without notice due to continuous development.
