DS-7000HI-S Series Net DVR User Manual
Thank you for purchasing our Net DVR. This manual is applicable to DS-7000HI-S series
Net DVR. Please read this User Manual carefully to ensure that you can use the device correctly
and safely.
The contents of this Manual are subject to change without notice.
User Manual of DS-7000HI-S Series Net DVR
V2.1
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DS-7004HI-S and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HIKVISION DS-7004HI-S

Summary of Contents for HIKVISION DS-7004HI-S

  • Page 1 User Manual of DS-7000HI-S Series Net DVR DS-7000HI-S Series Net DVR User Manual V2.1 Thank you for purchasing our Net DVR. This manual is applicable to DS-7000HI-S series Net DVR. Please read this User Manual carefully to ensure that you can use the device correctly and safely.

  • Page 2: Table Of Contents

    User Manual of DS-7000HI-S Series Net DVR Index Chapter1 Product Introduction ....................4 Summary ........................4 Model Description ..................... 4 Features ........................4 Chapter2 Installation ......................... 7 Checking the DVR and Its Accessories ..............7 HDD Installation ....................... 7 Rear Panel Description ....................8 External Alarm In/Out Connection ................
  • Page 3 User Manual of DS-7000HI-S Series Net DVR 5.15 PTZ ......................... 73 5.16 RS232 setup ......................78 5.17 Exceptions ....................... 84 5.18 Transaction Information ..................85 Chapter6 Utilities ........................89 Save Parameters ...................... 89 Restore Parameters ....................89 Upgrade ........................90 Hard Disk Management ..................

  • Page 4: Chapter1 Product Introduction

    User Manual of DS-7000HI-S Series Net DVR Chapter1 Product Introduction 1.1 Summary DS-7000HI-S series network digital video recorder is an excellent digital surveillance product applies the embedded MCU and real time operating system, along with the most advanced technology in the Information Technology Industry such as video and audio encoding/decoding, hard disk record and TCP/IP.
  • Page 5  Support video loop out.  Support up to 4CIF (DS-7004HI-S), 2CIF (DS-7008HI-S & DS-7016HI-S) resolution. Local Functions Recording  Support multiple recording types, including schedule recording, manual recording, alarm recording, motion detection recording, motion&alarm recording, motion|alarm...
  • Page 6 User Manual of DS-7000HI-S Series Net DVR  Support multiple upgrade modes, including FTP, USB and CD. Network  Support Advanced Network Function: NTP, DDNS and E-mail.  Support TCP, UDP, RTP, and Multicast for network preview.  Support PPPoE ...

  • Page 7: Chapter2 Installation

    User Manual of DS-7000HI-S Series Net DVR Chapter2 Installation Warning: Before you installing the DVR, please make sure the power of DVR is switched off. 2.1 Checking the DVR and Its Accessories When you get the product, check that all the items are included in your product package. There is a list in the package.

  • Page 8: Rear Panel Description

    Audio input 4 channel RCA (1.0 Vp-p, 75 Ω Audio Output 1 channel RCA (1.0 Vp-p, 75 DS-7016HI-S uses DB15 connectores. DS-7004HI-S uses Video Loop out on board BNC connectors. VGA Interface VGA display. Connect RS-232 devices. Refer to Appendix B for pin RS-232 definition.
  • Page 9 User Manual of DS-7000HI-S Series Net DVR G (GND): Conenct the GND of sensor. 1~16: Alarm input, supports normal open/normal close. 0: Reserved. Alarm output: 1G~4G: 4 relay output. Alarm output connection Please note the usage of jumper JJ1. If you use DC, either of connections is OK. We suggest you to use those DC under 12V, 1A.

  • Page 10: Chapter3 Operational Instructions

    User Manual of DS-7000HI-S Series Net DVR Chapter3 Operational Instructions 3.1 Front Panel      Index Type Name Description State READY DVR is ready. Lamps STATUS Green means you can use IR remote control. ALARM Red means there is an alarm. RECORD Twinkling red means reading or writing HDD.
  • Page 11 User Manual of DS-7000HI-S Series Net DVR Input switch (number, lower case, upper case and symbol); [FOCUS+]in PTZ control; In preview mode, display or hide the channel status bar. SHIFT Switch between numeric keys and function keys Control Direction Composed of [],[],[] and []. Keys Keys 1.

  • Page 12: Ir Remote Control

    User Manual of DS-7000HI-S Series Net DVR 3.2 IR Remote control Index Name Description POWER Turnoff device. Enable/Disable IR remote control Numeric Keys Same as numeric keys of front panel. EDIT Same as EDIT key of front panel. Same as A key of front panel. Same as REC key of front panel.
  • Page 13 User Manual of DS-7000HI-S Series Net DVR Reserved Reserved IRIS, FOCUS ZOOM for lens Lens control control. Reserved Loading the batteries into the IR remote control Remove the battery cover. Insert the battery. Please take care that the poles (+ and -) are correctly positioned. Replace the battery cover.

  • Page 14: Menu Description

    User Manual of DS-7000HI-S Series Net DVR 3.3 Menu Description 3.3.1 Menu Items Menu Name Function Menu Name Function Unit name Device ID Select camera Require password Camera name & Position Screen saver Brightness, Contrast, & Video standard Saturation Adjust Display Enable scaler Image...

  • Page 15: Menu Operation

    User Manual of DS-7000HI-S Series Net DVR Alarm Aux Out Display Delay Layout Save Para. Restore Para. Upgrade firmware HDD management Transaction Information Transact Utilities Stop alarm output Get Through Options Reboot Power off View log System information 3.3.2 Menu Operation How to enter menu mode ...
  • Page 16 User Manual of DS-7000HI-S Series Net DVR Each menu contains different kinds of items. There is a small rectangular frame named “Active Frame” which is pointing to the selected item. This “Active Frame” can be moved by []or[]keys. There are such kinds of menu items: Check Box: Provide 2 options, “”...

  • Page 17: Character Input

    User Manual of DS-7000HI-S Series Net DVR 3.4 Character Input In the menu interface, if you enter edit status (for example, in the “camera name” edit box), at the bottom of screen, the input status is appeared: Here it means you can press numeric keys to input digital number. Press[A]key to change input methods.

  • Page 18: Chapter4 Basic Operation Guide

    User Manual of DS-7000HI-S Series Net DVR Chapter4 Basic Operation Guide 4.1 Power on Note: Please make sure the power supply matches DVR and AC cable connected correctly. Before switch DVR on, please connect one monitor with VOUT or VGA interface. Otherwise, you can not see graphic user interface and can not operate.
  • Page 19 User Manual of DS-7000HI-S Series Net DVR Camera record status is following: Icon Icon Color Status Description White No video signal Yellow Vdieo input Pink Manual recording Green Real time recording Blue Motion detect recording External alarm recording Page 19...
  • Page 20 User Manual of DS-7000HI-S Series Net DVR Camera alarm status is following: Icon Icon Color Status Description White Video signal lost Yellow View tampering alarm Pink Motion&External alarm Green No alarm Blue Motion alarm External alarm Press numeric keys to switch over individual camera preview. If DVR has less than 10 channels, press one numeric key to switch corresponding channel.

  • Page 21: Spot Preview

    User Manual of DS-7000HI-S Series Net DVR 4.2.2 Spot Preview The spot output is an additional composite monitor used for preview operations. Press button “2” on the front panel to control spot out, press “shift” button to switch button function into numeric button, press channel number to switch spot out channels. Notes: 1.If there is no video input;...

  • Page 22: User Name And Password

    User Manual of DS-7000HI-S Series Net DVR 4.3 User name and password Note: When DVR is delivered from factory, there is only one default administrator named “admin”, and password is “12345”. The administrator’s name can not be modified, while the password can be modified. The administrator can create 15 users and define their user rights.
  • Page 23 User Manual of DS-7000HI-S Series Net DVR Setp 2: Enter User menu Move the “Active Frame” to “User” icon by using[]/[]keys. Press[ENTER]key to enter following password menu: Step 3: Input new password Press[EDIT]key to enter edit box. You can use numeric keys to input new password. The password can be null.

  • Page 24: Ptz Control

    User Manual of DS-7000HI-S Series Net DVR 4.4 PTZ Control Note: The user must have the “PTZ control” right. PTZ control interface In preview mode, press [PTZ]key, in the login dialog, select one user name and input the correct password, you can enter PTZ control interface. In menu mode, press [PTZ]key, you can enter PTZ control interface directly.
  • Page 25 User Manual of DS-7000HI-S Series Net DVR Wiper control key: [WIPER/MENU]; Light control key: [LIGHT/F1]; Auxiliary device control key:[AUX/F2] Adjust preset description In PTZ control mode, press[REC/SHOT]key, and press the preset number (three numeric keys), DVR will adjust the corresponding preset number. Repeat pressing[REC/SHOT]key, and press the preset number, DVR will adjust that preset number.

  • Page 26: Manual Record

    User Manual of DS-7000HI-S Series Net DVR 4.5 Manual Record Note: The user must have the corresponding right, DVR has HDD and HDD is formatted already. Manual record In preview mode, press[REC]key, in the pop-up login dialog, select the name and input the correct password, you can enter the “Manual Record”...

  • Page 27: Playback

    User Manual of DS-7000HI-S Series Net DVR 4.6 Playback Note: The user must have “Playback” right. Playback interface In preview mode, press[PLAY]key, in the pop-up login dialog, select username and input correct password, you can enter “Playback” interface. In menu mode, press[PLAY]key, you can enter “Playback” interface directly. Playback Description This series DVR only supports one channel playback,...
  • Page 28 User Manual of DS-7000HI-S Series Net DVR matched file, a corresponding dialog box will be pop-up. Play by Time: Playback the recorded stream directly based on the time section. Select Page: In the file list box, each page will only display 8 files. If the matched files are more than 8, you can select page to list other files.
  • Page 29 User Manual of DS-7000HI-S Series Net DVR 2. Playback by Time: In the playback interface, select channel number, record type and time section, move “Active Frame” to “Play” button, press[ENTER]key, DVR will start to playback based on time section. 3. Search by Card No and Playback file: In the playback interface, select channel number, record type, enable card No.
  • Page 30 User Manual of DS-7000HI-S Series Net DVR You can press [REC] button to get back to normal playback interface. Note: When DVR is busy, if you select high play speed, maybe there is difference for actual play speed. Exit playback In playback interface, press[ESC]key to enter preview mode.

  • Page 31: Backup Recorded Files

    User Manual of DS-7000HI-S Series Net DVR 4.7 Backup Recorded Files Note: The user must have “Playback” right. Please connect with backup devices before you start to backup. In the playback interface, you can backup the recorded files. In the preview mode, press[PLAY]key, in the login dialog, select username and input the correct password, you can enter the playback interface.
  • Page 32 User Manual of DS-7000HI-S Series Net DVR Step 2: Select the files that you want to backup In the file list box, use[↑]or[↓]keys to move the scroll bar. When the scroll bar stays at the file you wan to backup, press[EDIT]key to select it. The symbol “” is the selection tag. You can use the same method to select other files you want to backup.
  • Page 33 User Manual of DS-7000HI-S Series Net DVR SATA HDD for auto backup needs to be connected to the 1 SATA interface; SATA HDD for auto backup needs to be formatted by selecting “format” in the auto backup menu instead of in the HDD management menu. 1.

  • Page 34: Shut Down Dvr

    User Manual of DS-7000HI-S Series Net DVR 4. Enable the auto backup: Pressing “confirm” or “edit” button to enable(“”) or disable(“×”) the function. 5. Select camera you want to auto backup by using button and enable(“”) it by pressing “confirm” or “edit”. 6.
  • Page 35 User Manual of DS-7000HI-S Series Net DVR using “Power Off” in the “Utilities” menu, or [POWER] key on the front panel or on IR remote control. Shut down DVR normally Use menu Enter “Utilities” menu, move “Active Frame” to “Power Off” button and enter power off dialog, press “Confirm”...
  • Page 36 User Manual of DS-7000HI-S Series Net DVR Please avoid taking away the power cable directly. Note: In some cases, when the power supply is abnormal, DVR will be damaged. We suggest you to use those stable power supplies. Page 36...

  • Page 37: Chapter5 Parameters Setup Guide

    User Manual of DS-7000HI-S Series Net DVR Chapter5 Parameters Setup Guide Only the users that have “Parameters Setup” right need read this chapter. When the following parameters are modified and saved, you must reboot the DVR to make the new parameters take into effective.
  • Page 38 User Manual of DS-7000HI-S Series Net DVR In the user name list box, only “admin” is existed. You can use[→]key, move “Active Frame” to password edit box, and press[EDIT]key to enter edit status. Press numeric keys to input the new password.

  • Page 39: Add And Delete User

    User Manual of DS-7000HI-S Series Net DVR 5.2 Add and Delete User Enter “User Management” interface. Add user The steps are following: Step 1: Enter “User Management” menu Please refer to chapter 5.1 Step 2: Add new user name In the “User Management” menu, move “Active Frame” to “Add” button and press [ENTER], in the pop-up dialog, input the new user name (refer to chapter 3.4), press [ENTER]and return “User Management”...
  • Page 40 User Manual of DS-7000HI-S Series Net DVR In the users list box of “User Management” menu, use[][]keys to select the new user name, then use[]key to the password edit box. Press[EDIT]key to enter edit box, use numeric keys to input the new password. Step 3: Setup the rights for new user The new added user has not any operational rights.
  • Page 41 User Manual of DS-7000HI-S Series Net DVR PTZ control: Locally control PTZ; Record: Manual start/stop recording; Playback: Local playback and backup the recorded files; Parameters Setup: Locally setup the DVR parameters; Log: Locally view the log on DVR; Utilities: Locally upgrade firmware, format HDD, reboot DVR and shut down DVR, etc. “Remote Rights”: PTZ Control: Remote control PTZ;...
  • Page 42 User Manual of DS-7000HI-S Series Net DVR Page 42...

  • Page 43: Unit Name And Device Id

    User Manual of DS-7000HI-S Series Net DVR 5.3 Unit Name and Device ID Unit name In the “Display” menu: There is an item named “Unit Name”. The default unit name is “Embedded Net DVR”. Move “Active Frame” to unit name edit box, press[EDIT]key to enter edit status, you can modify the unit name.

  • Page 44: Video Output Standard And Vga Setup

    User Manual of DS-7000HI-S Series Net DVR 5.4 Video Output Standard and VGA Setup Video output standard There is one VOUT BNC connector at the rear panel of DVR. It is used to connect with analog monitor and can support PAL or NTSC video output. You can modify video output standard to match video input.
  • Page 45 User Manual of DS-7000HI-S Series Net DVR System Time In “Display” menu, you can setup DVR system date and time. Display System Time You can setup display properties for each camera, including display status, position and format. Of course, you can copy the properties of one camera to all cameras. In “Image Setup”...
  • Page 46 User Manual of DS-7000HI-S Series Net DVR “OSD”, press [ENTER]to enter setup image, you can find there are 22*18 (for NTSC, 22*15) small panes, and OSD position is in red. You can use[][][][]keys to move the OSD position. Press【EDIT】key to select OSD format. There are following OSD formats: MM DD YYYY W hh:mm:ss (default) MM DD YYYY hh:mm: ss DD MM YYYY hh:mm:ss...
  • Page 47 User Manual of DS-7000HI-S Series Net DVR Step 3: Press[ENTER]key to exit edit status. Move “Active Frame” to “Confirm” button, press[ENTER]to save the modification and you can see the new camera name. Press “Cancel” button or[ESC]key to abort. Setup Camera Name Position If you do not want to display camera name, just disable the check box beside camer name edit box.

  • Page 48: Video Parameters Setup

    User Manual of DS-7000HI-S Series Net DVR 5.6 Video Parameters Setup For different camera and different background, in order to get the best video image, you need to adjust video parameters such as brightenss, saturation, contrast and hue, etc. You can setup the camera individually, and also you can copy the video parameters of one camera to any other cameras.

  • Page 49: Mask Area Setup

    User Manual of DS-7000HI-S Series Net DVR 5.7 Mask Area Setup In some cases, maybe you want mask the sensitive area. This area will not be preview and recorded. The mask area setup steps are following: Step 1: Enter “Image Setup” menu: Step 2: Select one camera: You can use[][]keys to select one camera.
  • Page 50 User Manual of DS-7000HI-S Series Net DVR Step 4: Setup mask area: In the mask area setup interface, there is one small yellow pane on the upper left side. For PAL camera, the whole screen is divided into 22*18 panes (22*15 for NTSC), you can use[↑][↓][→][←]keys to move the yellow pane to your hope position and press[EDIT]key, the yellow pane will be turned into red, then you can use[↑][↓][→][←]keys to extend the red pane.

  • Page 51: View Tampering Alarm

    User Manual of DS-7000HI-S Series Net DVR 5.8 View Tampering Alarm If you enable this function, when someone blocks the camera spitefully, DVR will make warning alarm. Step 1: Enter “Image Setup” memu: Step 2: Select camera: Please use[][]keys to select one camera. Step 3: Select sensitivity: You can use[↑][↓]keys to select the sensitivity for “View Tampering”...
  • Page 52 User Manual of DS-7000HI-S Series Net DVR Step 6: Alarm schedule setup: When there is view tampering alarm happened, DVR will handle the alarm based on the schedule. You can set 4 periods for each day one week. Also you can copy the schedule of one day to other days.

  • Page 53: Video Loss Alarm

    User Manual of DS-7000HI-S Series Net DVR 5.9 Video Loss Alarm When the video cable or camera has something wrong, the video image is lost. If you enable video loss alarm, in such case, DVR will make alarm. Step 1: Enter “Image Setup” menu: Step 2: Select camera: Use[][]keys to select one camera.
  • Page 54 User Manual of DS-7000HI-S Series Net DVR Step 4: Setup alarm schedule: You can setup working schedule. Only when the video loss is happened in the schedule, DVR will response. Note: The 4 time periods can not be repeated. Please reboot DVR to make parameters into effective.

  • Page 55: Motion Detection Alarm

    User Manual of DS-7000HI-S Series Net DVR 5.10 Motion Detection Alarm If you enable this function, when there is motion detected, DVR will make alarm. Step 1: Enter “Image Setup” menu: Step 2: Select camera: Use[][]key to select one camera. Step 3: Select motion detection sensitivity: On the right side of “Motion Det.
  • Page 56 User Manual of DS-7000HI-S Series Net DVR The whole screen is divided into 22*18 panes (NTSC: 22*15). There is one yellow panel on the upper left side. The motion area setup steps are the same as that of mask area setup (refer to chapter 5.7).
  • Page 57 User Manual of DS-7000HI-S Series Net DVR Step 5: Motion alarm policy: Move “Active Frame” to the corresponding “Policy” button of motion detection alarm, press[ENTER]key to enter “Motiomn Alarm Handle” menu: Step 6: Motion alarm record channel setup: When there is motion alarm happened, you can trigger related camera to start recording.
  • Page 58 User Manual of DS-7000HI-S Series Net DVR response such as “On Screen Warning”, “Audible Warning”, “Upload to Center”, “Trigger Alarm Output” and “Send Email”. You can setup 4 time periods for one day and 7 days for one week. Note: Time periods in one day can not be repeated. Step 8: Motion alarm handle method setup: You can select one or more handle methods such as “On Screen Warning”, “Audible Warning”, “Upload to Center”, “Trigger Alarm Output”...

  • Page 59: Preview Properties

    User Manual of DS-7000HI-S Series Net DVR 5.11 Preview Properties In “Preview” menu, you can setup preview mode, select out, screen switch time, enable or disable audio preview, alarm aux out and layout. Step 1: Enter “Preview” menu: In the main menu, move “Active Frame” to “Preview” icon and press[ENTER], you can enter “preview”...
  • Page 60 User Manual of DS-7000HI-S Series Net DVR Screen”preview mode, this frame is divided into 4 windows. Each window represents one camera. You can move “Active Frame” among the windows. There is one bar under the square to display the preview order of all cameras. First select the biggest screen preview mode, for example, for 16-channel DVR, select “16 Screen”...

  • Page 61: Recording Setup

    User Manual of DS-7000HI-S Series Net DVR 5.12 Recording Setup In main menu, there is an icon named “Recording”. You can enter recording menu as follows: “Recording” menu description: If HD Full: There are two options: “Overwrite” and “Stop recording”. If you select “Overwrite”...
  • Page 62 User Manual of DS-7000HI-S Series Net DVR Resolution: The higher resolution is, the clearer the image is. The resolution options from low to high are: QCIF, CIF, 2CIF, DCIF, 4CIF. DS-7004HI-S: Each channel supports 4CIF@8FPS, DCIF@8FPS, 2CIF@15FPS, CIF/QCIF@real-time. DS-7008HI-S/DS-7016HI-S: Each...
  • Page 63 User Manual of DS-7000HI-S Series Net DVR PreRecord Time: When you enable motion detection recording or external alarm recording, you can define prerecord time. The options are: No PreRecord, 5 Seconds (default selection), 10 Seconds, 15 Seconds, 20 Seconds, 25 Seconds, 30 Seconds and Max PreRecord. MaxPreRecord is to save all data in PreRecord buffer.
  • Page 64 User Manual of DS-7000HI-S Series Net DVR side of “All Day” item, press[ENTER]or[EDIT]key to enable “All Day” option. “×” means disable and “” means enable. Step 3: Record type For “Rec Type” item, the options are: All Time, Motion Detect, Alarm, Motion|Alarm, and Motion&Alarm.
  • Page 65 User Manual of DS-7000HI-S Series Net DVR Input start time and stop time for each time period, and select record type for each period. The record type options are: All Time, Motion Detect, Alarm, Motion&Alarm and Motion|Alarm. Note: The time periods in one day can not be repeated. Step 4: Copy to other days You can repeat step2 and step3 to setup for other days.

  • Page 66: External Alarm Input And Relay Output

    User Manual of DS-7000HI-S Series Net DVR 5.13 External Alarm Input and Relay Output For 4-channel DVR, there are 4 external alarm input and 2 relay output. For 8-channel DVR, there are 8 external alarm input and 4 relay output. For 16-channel DVR, there are 16 external alarm input and 4 relay output.
  • Page 67 User Manual of DS-7000HI-S Series Net DVR Step 4: Alarm trigger record channel setup You can select channels to record for each alarm input. In the sub menu, you can use[ENTER]or[EDIT]key to enable record channel. “×” means disable and “ means enable. Note: In order to trigger the channel to record, in “Recording”...
  • Page 68 User Manual of DS-7000HI-S Series Net DVR First select one camera, and then select one of following PTZ linkage:  Preset: Set the flag as “” to enable preset, in the preset number edit box and input one preset number that has been setup already. Please refer to chapter 5.15 for preset setup. ...
  • Page 69 User Manual of DS-7000HI-S Series Net DVR Step 3: Enter alarm out schedule You can set the schedule to make alarm output into effective. Move “Active Frame” to “Schedule” button on right side of “Alarm Out Time” item, press[ENTER]key to enter the corresponding schedule menu: Step 4: Setup alarm out schedule Like other schedule setup, you can set 4 time periods for one day and 7 days for one week.

  • Page 70: Network Parameters

    User Manual of DS-7000HI-S Series Net DVR 5.14 Network Parameters If you want to use network to access DVR, you must setup network parameters. Note: If any of the network parameters is modified, you must save and reboot DVR to make it become effective.
  • Page 71 User Manual of DS-7000HI-S Series Net DVR NTP Host: NTP server name. DDNS: Currently supports two protocols provided by DDNS service supplier. www.dyndns.com or www.peanuthull.com. Protocol: Three options including DynDns, PeanutHull or IP Server. Server address: The DDNS server provided by DDNS service supplier Server Port: Provided by the supplier.
  • Page 72 User Manual of DS-7000HI-S Series Net DVR *NAS: Network access storage. DVR will regard network HDD as local HDD. If you enable this function by select “NAS setting”, DVR will send and save the real time image to that network HDD.

  • Page 73: Ptz

    User Manual of DS-7000HI-S Series Net DVR *Email: This function enables image capture and sending emails to designated e-mail address (max 2 e-mail addresses at the same time) when abnormity occured. You can also modify email parameters as follows: Authentication: If your Email server asks for a user name and password when sending Email, you need to tick this check box User: Email account user name Password: Email account password...
  • Page 74 User Manual of DS-7000HI-S Series Net DVR PTZ menu description Select channel: Select one PTZ camera. RS-485 parameters: Including baudrate, data bit, stop bit, parity, flow control, etc. These parameters must be the same as those PTZ Protocols. PTZ address: Each PTZ has one different address. PTZ type: DVR had the following PTZ protocol: YouLi, LinLin-1016, LinLin-820, Pelco-p, DM DynaColor, HD600, JC-4116, Pelco-d WX, Pelco-D, VCOM VC-2000, NetStreamer, SAE/YAAN, Samsung, Kalatel-312, CELOTEX, TLPelco-p, TLHHX-2000, BBV, RM110,...
  • Page 75 User Manual of DS-7000HI-S Series Net DVR Cruise setup: Cruise is remembering the track of PTZ movement. Please make sure the PTZ you are using can support cruise function. Preset setup In “PTZ” menu, move “Active Frame” to “Setup” button on the right side of “Preset” item, press[ENTER], you can enter “Preset”...
  • Page 76 User Manual of DS-7000HI-S Series Net DVR In “Sequence” setup menu, first input the sequence number. The sequence is among 1 --- 16. Each sequence is made up of cruise points, and each cruise point includes preset number, dwell time and dwell speed. Dwell time is the time staying at that preset number. Dwell speed is the speed that PTZ is moved to that preset number.
  • Page 77 User Manual of DS-7000HI-S Series Net DVR Press “RecCru” button, you will enter “PTZ control” interface. You can start controlling PTZ with direction keys, press[ENTER]to save the operation track and return “Cruise” setup menu. Press “StartCru” button to repeat the PTZ track until you press “Stop” button. Press “Return”...

  • Page 78: Rs232 Setup

    User Manual of DS-7000HI-S Series Net DVR 5.16 RS232 setup There is one RS-232 port at DVR rear panel. In main menu, move “Active Frame” to “RS232” icon and perss[ENTER]key, you enter “RS232” setup menu: RS232 menu description RS-232 parameters: Including baud rate, data bit, stop bit, parity, flow control, etc. Work mode: The RS-232 can be used as “Console”, “PPP”...
  • Page 79 User Manual of DS-7000HI-S Series Net DVR Callback mode: Only used when work mode is “PPP”. There are two options: “By Dialer” and “Preset Tel’. This function is not available. Remote IP: Only used when work mode is “PPP”. This IP is defined for remote PC that will connect DVR through PSTN.
  • Page 80 User Manual of DS-7000HI-S Series Net DVR Setup at DVR end Step 1: RS232 setup Setup baud rate, data bit, stop bit, parity and flow control. They must be the same as those of modem connected with PC. Step 2: Video setup In “Recording” menu, select the camera you want to transfer through PSTN.
  • Page 81 User Manual of DS-7000HI-S Series Net DVR ATQ1 ---- Commit instruction and not display AT&W&W1 ---- Save parameters Step 5: Use DCE cable to connect Modem with DVR RS232 port. Setup at PC end Step 1: Setup Modem used on PC side. Use DCE calbe to connect Modem with PC serial port.
  • Page 82 User Manual of DS-7000HI-S Series Net DVR Step 3: Establish the dialup connection Select the Modem connected with PC just like the dialup network connection, input the telephone number connected with DVR’s modem. Input the username, password. They must be the same as that DVR PPP setup.
  • Page 83 User Manual of DS-7000HI-S Series Net DVR Step 6: You can preview the image of 192.1.0.2 by using client-end software. Page 83...

  • Page 84: Exceptions

    User Manual of DS-7000HI-S Series Net DVR 5.17 Exceptions The exceptions can be handled at present include: hard disk full, hard disk error, illegal access, IP address conflict, network failure, and NTSC/PAL differ. Enter “Exceptions” menu: Including the following handle methods: Audible Warning: DVR beep warning.

  • Page 85: Transaction Information

    User Manual of DS-7000HI-S Series Net DVR 5.18 Transaction Information The DVR can actively obtain or passively receive the credit card number from ATM machine linked through network or serial port, and credit card number can be overlay on live video, recorded and playback.
  • Page 86 User Manual of DS-7000HI-S Series Net DVR Transaction type and code When the ATM machine is sending transaction information to bank center, DVR will capture the data package through network, and analyse the data according to the format. Then DVR will overlay the correspond text on live video.
  • Page 87 User Manual of DS-7000HI-S Series Net DVR In this case, you must set the RS-232 of DVR as transparent channel mode as follows: Software must be run in the ATM machine, and send the credit card number, transaction code to DVR through RS-232 port. Please provide detail ATM machine communication protocol for actual projects.
  • Page 88 User Manual of DS-7000HI-S Series Net DVR In the case, you must set the RS-232 of DVR as transparent channel mode as follows: Also, software must be run in ATM machine, and send command to DVR through RS-232 port based on special communication protocol. Page 88...

  • Page 89: Chapter6 Utilities

    User Manual of DS-7000HI-S Series Net DVR Chapter6 Utilities There are many tools in “Utilities” menu, including “SavePara”, “RestorePara”, “Upgrade”, “Hard Disk”, “Stop Alarm Out”, “Reboot”, “Power Off”, “View Log” and “System Info”. Enter “Utilities” menu: 6.1 Save Parameters Save factory default parameters into FLASH memory. You can reboot DVR to make them become effective.

  • Page 90: Upgrade

    User Manual of DS-7000HI-S Series Net DVR 6.3 Upgrade You can use this function to upgrade the firmware. Please confirm the language is matched. Press “Upgrade” icon, in the pop-up dialog, you can select either “FTP” or “USB” upgrade mode. If you select “FTP”...

  • Page 91: Hard Disk Management

    User Manual of DS-7000HI-S Series Net DVR 6.4 Hard Disk Management Check HDD work status Capacity, Free space, Stand by or not, Normal status or not. Format HDD Before formatting stop all recording. After formatting, you must reboot DVR; otherwise DVR will not work normally.

  • Page 92: Reboot

    User Manual of DS-7000HI-S Series Net DVR 6.6 Reboot Reboot DVR. 6.7 Power Off Shut down DVR. 6.8 View Log To view the log recorded in DVR HDD. In “Utilities” menu, press “View Log” to enter “Log” menu: If you want to view the log based on default option, just press[ENTER]key. DVR will list all matched information.
  • Page 93 User Manual of DS-7000HI-S Series Net DVR For exception major type, the minor type includes: Video Signal Loss, Illegal Access, Hard Disk Error, Hard Disk Full, IP Conflict, DCD Lost. For example: The steps of viewing alarm log. Step 1: For “Query” item, select “By Type” to active “Major Type” and “Minor Type” items. Step 2: For “Major Type”...
  • Page 94 User Manual of DS-7000HI-S Series Net DVR Step 3: Input start time and stop time. Step 4: Move “Active Frame” to “Search Log” button and press[ENTER]key to start searching. Step 5: After finish searching, DVR will list the matched log information. Step 6: Press “Return”...

  • Page 95: System Information

    User Manual of DS-7000HI-S Series Net DVR 6.9 System Information Press “System Info” icon in “Utilities” menu, you can get DVR system information, including Unit Name, Device Model, Serial Number, Firmware Version, and Encode Version. Page 95...

  • Page 96: Chapter7 Firmware Upgrade

    User Manual of DS-7000HI-S Series Net DVR Chapter7 Firmware Upgrade The DVR firmware is stored in FLASH ROM. You can use DVR upgrade function to write the firmware file (digicap) into FLASH. There are two cases that you need to upgrade DVR firmware. One is update old firmware. The other is when the code in DVR FLASH is crashed.
  • Page 97 User Manual of DS-7000HI-S Series Net DVR Select “Users/rights” under “Security” menu item. The following dialog box will be pop-up. Create new user. Click “new user’. New user dialog pops up. Input user name “target”. Click “OK”. In the password dialog, input password “target” in “New Password” and “Verify Password”...
  • Page 98 User Manual of DS-7000HI-S Series Net DVR 7. Next time, you need not setup again, just double click and open “wftpd32.exe” to upgrade the DVR/DVS firmware. Page 98...

  • Page 99: Upgrade Mode

    User Manual of DS-7000HI-S Series Net DVR 7.2 Upgrade Mode Use client software to upgrade the firmware file. You do not need to use ftp server software. Please refer to the client software user manual for detail information. Enter “Setup” → right click device name →...
  • Page 100 User Manual of DS-7000HI-S Series Net DVR Upgrading as follows: Note: Do not attempt any other tasks until the upload completes. Use “USB” function of “Upgrade” sub menu in “Utilities” menu. The DVR will search for the upgrade firmware file in a connected USB FLASH, and update firmware. After upgrading successfully, DVR will ask you to reboot.
  • Page 101 User Manual of DS-7000HI-S Series Net DVR The DVR will search for the upgrade firmware file in a connected CD-ROM, and update firmware. After upgrading successfully, DVR will ask you to reboot. Note: Make sure that the update firmware file is placed in the CD-ROM root directory. After you reboot DVR, if you can only hear the startup sound, but can not see startup picture, you can input shell commands under HyperTerminal.
  • Page 102 User Manual of DS-7000HI-S Series Net DVR Step 3: Switch off and on the power supply of DVRDVS. In the HyperTerminal, the following sentence is appeared: Please input [u/U] or [ESC] key Release "ctrl" and "u" keys. Step 4: Press “u” key. In the message line of “IP address of NET DVR”, input any one ip, just make sure DVR IP and FTP server IP are in the same sub net.

  • Page 103: Appendix A Mouse Control Function

    4,9,12 or 16 Screen” “Next Preview” “PTZ Control” “Play” “Manual Record” and “Close Status”. 2. PTZ interface Double-click the left key Move to the center of the screen (For SAE\HIKVISION protocol) Drag the left key Select an area to zoom in (For SAE\HIKVISION protocol) Scroll wheel forward...
  • Page 104 User Manual of DS-7000HI-S Series Net DVR Select an area for zooming in single playback interface Moving The primary grid will be following with the cursor 5. Test input interface Click the left key 1. Pop up soft keyboard 2. Input text 3.

  • Page 105: Appendix Bhdd Capacity Calculation

    User Manual of DS-7000HI-S Series Net DVR Appendix B HDD Capacity Calculation Calculate total capacity needed by each DVR according to video recording (video recording type and video file storage time). Step 1: According to Formula (1) to calculate storage capacity that is the capacity of each channel needed for every hour, unit Mbyte.

  • Page 106: Appendix Cdvr Connect Cable Definition

    User Manual of DS-7000HI-S Series Net DVR Appendix C DVR Connect Cable Definition 1 UTP network connect cable made method Material and tool One twist cable (8 pin, the length can be defined as to the actual demand, but must be within 100m), 2 standard RJ45 head, one tool for RJ45.
  • Page 107 User Manual of DS-7000HI-S Series Net DVR The corresponding relationship of cross cable 2 RS-232 connect cable made method DS-7000HI-S has standard DB9 RS-232 interface, like PC COM port. Pin definition “I” means DVR input and O means DVR output. Pin index Name Description...

  • Page 108: Appendix D Specifications

    User Manual of DS-7000HI-S Series Net DVR Appendix D Specifications Model DS-7004HI-S DS-7008HI-S DS-7016HI-S Video H.264 compression Preview 4CIF (PAL: 704*576, NTSC: 704*480) resolution Playback 4CIF/2CIF/CIF/QCIF 2CIF/CIF/QCIF resolution Video input Video input BNC (1.0Vp-p, 75Ω) interface 1 channel, BNC (1.0Vp-p, 75Ω) Video output 1 channel, BNC (1.0Vp-p, 75Ω)
  • Page 109 User Manual of DS-7000HI-S Series Net DVR 1280*1024/60Hz External alarm in Relay output 100~240VAC, 6.3A, 50~60HZ Power supply Power ≤40W (without HDD or DVD-R/W) consumption Working -10℃~+55℃ temperature Working 10%~90% humidity Size 440mm(W)*390mm(D)*70mm(H) ≤8Kg (without HDD or DVD-R/W) Weight PAL: 176*144(QCIF), 352*288(CIF), 704*288(2CIF), 528*384(DCIF), 704*576(4CIF); NTSC: 176*120(QCIF), 352*240(CIF), 704*240(2CIF), 528*320(DCIF), 704*480(4CIF).

  • Page 110: Appendix E List Of Recommended Dvr Peripherals

    User Manual of DS-7000HI-S Series Net DVR Appendix E List of Recommended DVR Peripherals HDD: 1. IDE HD Maxtor: 1. DiamondMax P lus 9 80G ATA/133 H DD 2. DiamondMax P lus 9 160G ATA/133 H DD 3. DiamondMax P lus 9 200G ATA/133 H DD 4.
  • Page 111 User Manual of DS-7000HI-S Series Net DVR Model:6L080M0 80GB SATA150 HDD Seagate 1. Barracuda 7200.8 250G (+5V +12V 0.46A 0.56A) Model:ST3250823AS 2. Barracuda 7200.9 200G (+5V +12V 0.46A 0.56A) Model:ST3200827AS 3. Barracuda 7200.9 160G (+5V +12V 0.46A 0.56A) Model:ST3160812AS 4. Barracuda 7200.7 120G (+5V +12V 0.63A 0.74A) Model:ST3120827AS 5.
  • Page 112 User Manual of DS-7000HI-S Series Net DVR WD 2000 (5VDC 12VDC 0.92A 0.90A) MDL:WD 2000JS-00MHB1 2. WD Caviar SE16 WD 2500 (5VDC 12VDC 0.92A 0.90A) MDL:WD 2500KS-00MJB1 3. WD Caviar SE WD 1600JS (5VDC 12VDC 0.92A 0.90A) MDL:WD 1600JS-00MHB0 4. WD Caviar SE WD 1200JS (5VDC 12VDC 0.92A 0.90A) MDL:WD 1200JS-00MHB0 5.
  • Page 113 User Manual of DS-7000HI-S Series Net DVR 2. PC HD ＋ ydstar’s transfer box. 3. IBM 20G, 30G. 4. Newsmy traveler 2.5T 40G. U Flash Memory (FAT or FAT32 format) The following products are supported: 1. Thunis USB2.0 512M 2. NETAC super stable and classic mode 64M,32M 3.
  • Page 114 User Manual of DS-7000HI-S Series Net DVR 5.sony ＋ydstar’s USB transfer box 7. SONY CD-R/RW CRX230AD + transfer wire 8.SONY CD-R/RW CRX225E + transfer wire 9.BENQ Outside Recorder EW162I-OK210 10.BenQ （CD） Mode:5232WI 11.BenQ（CD/DVD) Mode:EW164B 12.Samsung（CD/DVD) Mode:SE-S164 13.LG（CD/DVD） Mode:GSA-E10L IDE CD-R 1.Sony CD-R/RW CRX225E 2.NEC DVD R/RW &...

  • Page 115: Appendix F Quick Search Function Table

    User Manual of DS-7000HI-S Series Net DVR Appendix F Quick Search Function Table Type Name Description Index User Create and delete users. System has one default management administrator. The administrator can create 15 users Safety and define their rights. function Password Modify password.
  • Page 116 User Manual of DS-7000HI-S Series Net DVR Remote Remote record real time stream. record Remote Remote playback the recorded files in DVR playback Download Download recorded files in DVR. Remote Remote upgrade firmware. upgrade Transparent Remote control serial device connected with serial 5.16 channel port of DVR.

  • Page 117: Appendix G Troubleshooting

    User Manual of DS-7000HI-S Series Net DVR Appendix G Troubleshooting Failure Possible reasons After plugging in power, turning on the power switch, Power cable is broken. “POWER” light in front Panel does not turn on, and fan Power supply is broken. does not work.
  • Page 118 User Manual of DS-7000HI-S Series Net DVR Old player SDK (playm4.dll) Notes: Place the DVR in well ventilated space so that it operates within the allowed range of temperature and humidity as in specification. If the circuit board is wet, dust on circuit board can cause a short circuit. The circuit board, plug and socket, housing fan and housing should be cleaned by brushing regularly.

  • Page 119: Appendix H Product Service

    User Manual of DS-7000HI-S Series Net DVR Appendix H Product Service Thank you for choosing our products. All of our products users can enjoy a conditional free repair guarantee service for hardware within 12 months starting from purchase date, and a free exchange service within one month (valid for the damage caused by non personal acts).

  • Page 120: Appendix I Customer Information Card

    User Manual of DS-7000HI-S Series Net DVR Appendix I Customer Information Card User’s Name r./Mrs. Company Name Post Address Postcode Phone Number E-mail Model Number of Product Serial Number of Product Purchase Date Distributor Page 120...
  • Page 121 User Manual of DS-7000HI-S Series Net DVR Suggestions: Page 121...
