Hikvision Technical Manual
DS-7000HI-S Series Net DVR
Technical Manual
©2006 – 2010 by HIKVISION. All rights reserved.

Advertisement

loading
Need help?

Need help?

Do you have a question about the DS-7004HI-S and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for HIKVISION DS-7004HI-S

  • Page 1 Hikvision Technical Manual DS-7000HI-S Series Net DVR Technical Manual ©2006 – 2010 by HIKVISION. All rights reserved.
  • Page 2 HIKVISION and then only on the condition that this notice is included in any such reproduction. No information as to the contents or subject...
  • Page 3 Hikvision Technical Manual Contents 1. Overview 2. Model Description 3. Features 4. Specifications ©2006 – 2010 by HIKVISION. All rights reserved.
  • Page 4 (DVS). It can work standalone, also be used to build up a powerful surveillance network. DS-7000HI-S series device can be widely used in bank, telecommunication, transportation, factories, warehouse, irrigation, etc. DS-7016HI-S Front Panel DS-7016HI-S Rear Panel ©2006 – 2010 by HIKVISION. All rights reserved.
  • Page 5: Model Description

    Hikvision Technical Manual 2. Model Description DS-7004HI-S: 4-ch video input and 4-ch audio input. 1-ch composited video output and 1-ch spot video output. 4-ch video loop out. Support one VGA output. 4 SATA HDD supported. DS-7008HI-S: 8-ch video input. 1-ch video output and 1-ch spot video output.
  • Page 6 Support BNC analog monitor and VGA output  Support multiple preview modes  Support Privacy Mask  Support view tampering alert  Support video signal loss alert  Support play forward, backward, pause, frame-by-frame, etc  ©2006 – 2010 by HIKVISION. All rights reserved.
  • Page 7 Support OSD and changeable OSD position.  Support multiple upgrade modes, including FTP, USB and CD.  Automatically recovery from abnormal conditions.  Network SDK and client demo source code available  ©2006 – 2010 by HIKVISION. All rights reserved.
  • Page 8: Specifications

    4 SATA interfaces, can max support 4 SATA HDD and each HDD SATA interface can max support 2000GB, or 2 HDD and 1 SATA CD-RW/DVD-RW 1 USB interface can support USB disk, USB HDD, USB USB interface CD-RW/DVD-RW. ©2006 – 2010 by HIKVISION. All rights reserved.
  • Page 9 ≤40W (without HDD or DVD-R/W) consumption Working -10℃~+55℃ temperature Working 10%~90% humidity Size 440mm(W)*390mm(D)*70mm(H) Weight ≤8Kg (without HDD or DVD-R/W) PAL: 176×144(QCIF), 352×288(CIF), 704×288(2CIF), 528×384(DCIF), 704×576(4CIF); NTSC: 176×120(QCIF), 352×240(CIF), 704×240(2CIF), 528×320(DCIF), 704×480(4CIF). ©2006 – 2010 by HIKVISION. All rights reserved.
