HearthStone hase-Bari 8180 Owner's Manual

Euro collection gas fired direct-vent heater
Hide thumbs Also See for hase-Bari 8180:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Owner's Manual
WARNING: Follow the information in these
instructions exactly, if not, a fire or explosion may
result causing property damage, personal injury or
loss of life.
WARNING:
Do not store or use gasoline or any other
flammable vapors and liquids near this or any other gas
appliance.
WHAT TO DO IF YOU SMELL GAS:
Do not try to light any appliance.
Do not touch electrical switches; do not use the phone in
your building.
Immediately call your gas supplier from a phone outside
the structure. Follow your gas supplier's instructions.
If you cannot reach your gas supplier, call the fire
department or 911.
A qualified installer, service agency, or gas supplier must
perform installation and service of this appliance. In the
Commonwealth of Massachusetts, all installation of gas lines
and gas fittings must be performed by a licensed gas fitter or
licensed plumber.
(Model 8180)
Gas Fired Direct-Vent Heater
OWNER'S MANUAL
INSTALLATION AND
OPERATING INSTRUCTIONS
PLEASE READ THIS ENTIRE OWNER'S MANUAL
BEFORE YOU INSTALL AND USE YOUR NEW BARI
GAS HEATER. SAVE THIS DOCUMENT FOR FUTURE
REFERENCE.
AVERTISSEMENT: Assurez-vous de bien suivre les
instructions donné dans cette notice pour réduire au
minimum le risque d'incendie ou pour éviter tout
dommage matéeriel, toute blessure ou la mort.
AVERTISSEMENT: Ne pas entresposer ni utiliser d'essence ni
d'autre vaperurs ou liquides inflammables dans le voisinage
de cet apprareil ou de tout autre appareil.
QUE FAIRE SI VOUS SENTEZ UNE ODEUR
DE GAZ:
Ne pas tenter d'allumer d'appareil.
Ne touchez à aucun interrupteur. Ne pas vous servir des
téléphones se trouvant dans le batiment où vous vous
trouvez.
Appelez immédiatement votre fournisseur de gaz depuis un
voisin. Suivez les instructions du fournisseur.
Si vous ne pouvez rejoindre le fournisseur de gaz, appelez le
service dos incendies.
L'installation et service doit être exécuté par un qualifié installer,
agence de service ou le fournisseur de gaz.
Bari DV Gas Model 8180
Manual # 6400-40458
Revised: 2/13/2008
