Enable output

Press
to enable the IT6720 output.
On/Off
Voltage and current settings will be
wink for three seconds, and after that ,
the display value of numerical display
will change from the set value to actual
measured voltage and current value.
Power off lights will be turned off which
means the power is in output state.
Press
again, you will shut power
On/Off
supply's output.

Step value for Cursor Position

Cursor position
Step voltage
A
B
C
D

Check the set voltage and current value

The power supply usually displays the actual voltage and current values. When you want to check
the preset voltage and current values, the unit will display automatically settings, press
the settings will be displayed for three seconds.

Key lock function

This function can prevent error operation by unauthorized person. Press
lit on, press
(Lock) ,
C
C
C
. Repeat above operation, key lock function will be disabled.
On/Off
Step current
10V
1A
1V
0.1A
0.1V
0.01A
0.01V
0.001A
will be lit on, which means all keys on the panel except
Lock
IT6720 60V/5A/100W
ITECH
Auto Range DC Power Supply
A
C
B
Quick Start
CV
CC
V
OVP
OCP
D
Lock
Prog
A
OFF
Shift
Output off indicator
twice,
Shift
, after the
Shift
Shift
and
Shift
USER'S GUIDE
was
7
