Table of Contents

Advertisement

Models:
GRAND-I35-C
GRAND-I35-SP
SUPREME-I30-C
SUPREME-I30-SP
• Important operating
a n d m a i n t e n a n c e
instructions included.
WARNING: If the information in these
instructions is not followed exactly, a fi re
or explosion may result causing property
damage, personal injury, or death.
• DO NOT store or use gasoline or other fl am-
mable vapors and liquids in the vicinity of this
or any other appliance.
• What to do if you smell gas
- DO NOT try to light any appliance.
- DO NOT touch any electrical switch. DO
NOT use any phone in your building.
- Immediately call your gas supplier from a
neighbor's phone. Follow the gas suppli-
er's instructions.
- If you cannot reach your gas supplier, call
the fi re department.
• Installation and service must be performed
by a qualifi ed installer, service agency, or the
gas supplier.
In the Commonwealth of Massachusetts installation must be
performed by a licensed plumber or gas fi tter.
A CO detector shall be installed in the room where the appliance
in installed.
Installation and service of this appliance should be
performed by qualifi ed personnel. Hearth & Home
Technologies suggests NFI certifi ed or factory trained
professionals, or technicians supervised by an NFI
certifi ed professional.
Heat & Glo • Grand-I35-C, Grand-I35-SP, Supreme-I30-C, Supreme-I30-SP • 2206-901 Rev. P • 6/14
NOTICE
DO NOT DISCARD THIS MANUAL
• Read, understand and follow
these instructions for safe
installation and operation.
Owner's Manual
Installation and Operation
• Leave this manual with
party responsible for use
and operation.
WARNING
HOT GLASS WILL
CAUSE BURNS.
DO NOT TOUCH GLASS
UNTIL COOLED.
NEVER ALLOW CHILDREN
TO TOUCH GLASS.
A barrier designed to reduce the risk of burns
from the hot viewing glass is provided with this
appliance and shall be installed.
This appliance may be installed as an OEM
installation in manufactured home (USA
only) or mobile home and must be installed
in accordance with the manufacturer's
instructions and the Manufactured Home
Construction and Safety Standard, Title 24
CFR, Part 3280 in the United States, or the
Standard for Installation in Mobile Homes,
CAN/CSA Z240 MH Series, in Canada.
This appliance is only for use with the type(s)
of gas indicated on the rating plate. This
appliance is not convertible for use with other
gases, unless a certifi ed kit is used.
1

Advertisement

Table of Contents
loading

Summary of Contents for Heat & Glo GRAND-I35-C

  • Page 1 NFI gases, unless a certifi ed kit is used. certifi ed professional. Heat & Glo • Grand-I35-C, Grand-I35-SP, Supreme-I30-C, Supreme-I30-SP • 2206-901 Rev. P • 6/14...
  • Page 2: Congratulations

    00,000 00,000 MIN. MIN. INPUT INPUT BTUH: BTUH: 00,000 00,000 00,000 00,000 Serial Serial XXXXXXXX XXXXXXXX ORIFICE ORIFICE SIZE: SIZE: #XXXXX #XXXXX #XXXXX #XXXXX (Serie): (Serie): Heat & Glo • Grand-I35-C, Grand-I35-SP, Supreme-I30-C, Supreme-I30-SP • 2206-901 Rev. P • 6/14...
  • Page 3: Table Of Contents

    B. Flue Damper........22  = Contains updated information. Heat & Glo • Grand-I35-C, Grand-I35-SP, Supreme-I30-C, Supreme-I30-SP • 2206-901 Rev. P • 6/14...
  • Page 4: Limited Lifetime Warranty

    Firebox and heat exchanger Lifetime All replacement parts 90 Days beyond warranty period See conditions, exclusions, and limitations on next page. 4021-645F 02-18-13 Page 1 of 2 Heat & Glo • Grand-I35-C, Grand-I35-SP, Supreme-I30-C, Supreme-I30-SP • 2206-901 Rev. P • 6/14...
  • Page 5 THE EXTENT PROVIDED BY LAW, HHT MAKES NO EXPRESS WARRANTIES OTHER THAN THE WARRANTY SPECIFIED HEREIN. THE DURATION OF ANY IMPLIED WARRANTY IS LIMITED TO DURATION OF THE EXPRESSED WARRANTY SPECIFIED ABOVE. 4021-645F 02-18-13 Page 2 of 2 Heat & Glo • Grand-I35-C, Grand-I35-SP, Supreme-I30-C, Supreme-I30-SP • 2206-901 Rev. P • 6/14...
  • Page 6: Listing And Code Approvals

    (2000-4500 FT) 31,000 15,500 (0-2000 FT) SUPREME-I30-C, Supreme-I30-SP (LP) CANADA 27,500 14,500 (2000-4500 FT) 35,000 17,000 (0-2000 FT) GRAND-I35-C, Grand-I35-SP, (LP) CANADA 31,000 15,500 (2000-4500 FT) Heat & Glo • Grand-I35-C, Grand-I35-SP, Supreme-I30-C, Supreme-I30-SP • 2206-901 Rev. P • 6/14...
  • Page 7: User Guide

    • Keep remote controls out of reach of children. • Never leave children alone near a hot fi replace, whether operating or cooling down. • Teach children to NEVER touch the fi replace. Heat & Glo • Grand-I35-C, Grand-I35-SP, Supreme-I30-C, Supreme-I30-SP • 2206-901 Rev. P • 6/14...
  • Page 8: Clear Space

    3. The control module has safety feature that automatically shuts down the fi replace after 9 hours of continuous operation without receiving a command from the RC300 remote. Heat & Glo • Grand-I35-C, Grand-I35-SP, Supreme-I30-C, Supreme-I30-SP • 2206-901 Rev. P • 6/14...
  • Page 9: Before Lighting Fireplace

    The appliance has a safety feature that automatically shuts down the fi replace after nine hours of continuous operation without receiving a command from the wall switch or optional remote. Heat & Glo • Grand-I35-C, Grand-I35-SP, Supreme-I30-C, Supreme-I30-SP • 2206-901 Rev. P • 6/14...
  • Page 10: Lighting Instructions (Ipi)

    For additional information on operating your Hearth & Home Technologies fi replace, please refer to www.fi replaces.com. Final inspection by Heat & Glo • Grand-I35-C, Grand-I35-SP, Supreme-I30-C, Supreme-I30-SP • 2206-901 Rev. P • 6/14...
  • Page 11: For Your Safety

    Hearth & Home Technologies fi replace, please refer to www.fi replaces.com. 4. Push in gas control knob slightly and turn clock- wise to OFF”. DO NOT force. 5. Close control access panel. Final inspection by 464-903H Heat & Glo • Grand-I35-C, Grand-I35-SP, Supreme-I30-C, Supreme-I30-SP • 2206-901 Rev. P • 6/14...
  • Page 12: After Appliance Is Lit

    Some optional control systems available with IPI models may allow pilot fl ame to continually? remain lit. In a standing pilot system the pilot will always stay on. Heat & Glo • Grand-I35-C, Grand-I35-SP, Supreme-I30-C, Supreme-I30-SP • 2206-901 Rev. P • 6/14...
  • Page 13: Maintenance And Service

    • Carefully set fi xed glass assembly in place on appliance. Hold glass in place with one hand and secure glass latches with the other hand. • Reinstall door or decorative front. Heat & Glo • Grand-I35-C, Grand-I35-SP, Supreme-I30-C, Supreme-I30-SP • 2206-901 Rev. P • 6/14...
  • Page 14: Maintenance Tasks-Service Technician

    Use caution when cleaning these areas. Screw tips that have penetrated the sheet metal are sharp and should be avoided. • Remove all foreign objects. • Verify unobstructed air circulation. Heat & Glo • Grand-I35-C, Grand-I35-SP, Supreme-I30-C, Supreme-I30-SP • 2206-901 Rev. P • 6/14...
  • Page 15: Burner Ignition And Operation

    • Verify that there is not a short in fl ame sense circuit by checking continuity between pilot hood and fl ame sense rod. Replace pilot as necessary. (IPI only) Heat & Glo • Grand-I35-C, Grand-I35-SP, Supreme-I30-C, Supreme-I30-SP • 2206-901 Rev. P • 6/14...
  • Page 16: Installer Guide

    SURROUND OR FRONT NOT SHOWN SECTION 2.D AND 8.D. HEARTH EXTENSION GAS LINE (SECTION 9) ACCESS THROUGH EXISTING MASONRY OR WOODBURNING FIREPLACE Figure 4.1 Typical System Heat & Glo • Grand-I35-C, Grand-I35-SP, Supreme-I30-C, Supreme-I30-SP • 2206-901 Rev. P • 6/14...
  • Page 17: Design And Installation Considerations

    Safety glasses Level Reciprocating saw Manometer Noncorrosive leak check solution 1/2 - 3/4 inch length, #6 or #8 Self-drilling screws Caulking material (300ºF minimum continuous exposure rating) Heat & Glo • Grand-I35-C, Grand-I35-SP, Supreme-I30-C, Supreme-I30-SP • 2206-901 Rev. P • 6/14...
  • Page 18: Fireplace Size Requirements

    The sidewalls and top structure of the fi rebox may not be altered with the exception of removable baffl es and dampers. Heat & Glo • Grand-I35-C, Grand-I35-SP, Supreme-I30-C, Supreme-I30-SP • 2206-901 Rev. P • 6/14...
  • Page 19 **Unit depth is measured to the back of the surround to give the depth needed for installation. In addition to these dimensions, also reference Clearances and Mantel Projections (Section 5.B). Figure 5.2 Fireplace Opening Heat & Glo • Grand-I35-C, Grand-I35-SP, Supreme-I30-C, Supreme-I30-SP • 2206-901 Rev. P • 6/14...
  • Page 20: Mantel And Wall Projections

    fi rebox. Combustible facings must not extend behind the insert surround. For non-combustible material specifi cations refer to section 1.E. Figure 5.4 Mantel Clearances Heat & Glo • Grand-I35-C, Grand-I35-SP, Supreme-I30-C, Supreme-I30-SP • 2206-901 Rev. P • 6/14...
  • Page 21: Termination Locations

    Over 18/12 to 20/12 ..........7.5 Over 20/12 to 21/12 ..........8.0 * 3 foot minimum in snow regions Figure 6.1 Minimum Height From Roof To Lowest Discharge Opening Heat & Glo • Grand-I35-C, Grand-I35-SP, Supreme-I30-C, Supreme-I30-SP • 2206-901 Rev. P • 6/14...
  • Page 22: Installation Preparation

    • It is recommended that extra length of gas line be installed within the existing wood burner or masonry fi replace to allow removal of the insert for future servicing needs. Heat & Glo • Grand-I35-C, Grand-I35-SP, Supreme-I30-C, Supreme-I30-SP • 2206-901 Rev. P • 6/14...
  • Page 23: Installing Vent Pipe And Appliance

    INLET AIR STARTING COLLAR NOTE: TO ACHIEVE OPTIMUM PERFOR- MANCE OF INSERT, MINIMIZE OR AVOID BENDS IN EXHAUST VENT PIPE. STARTING COLLAR BRACKET EXHAUST STARTING COLLAR Figure 8.1 Heat & Glo • Grand-I35-C, Grand-I35-SP, Supreme-I30-C, Supreme-I30-SP • 2206-901 Rev. P • 6/14...
  • Page 24: Placing, Securing And Leveling The Appliance

    Heat & Glo • Grand-I35-C, Grand-I35-SP, Supreme-I30-C, Supreme-I30-SP • 2206-901 Rev. P • 6/14...
  • Page 25: Remote Control

    See Figure 8.5. AUXILIARY 300 MODULE LOCATION B Figure 8.5 Location of AUX300 for Remote Control Blower Function - IPI Figure 8.3 Heat & Glo • Grand-I35-C, Grand-I35-SP, Supreme-I30-C, Supreme-I30-SP • 2206-901 Rev. P • 6/14...
  • Page 26: Installing Adaptor And Termination Cap

    Connect both the LINK-ZC-ADPB to Class A Pipe VENT PIPE and the termination cap to the LINK-ZC-ADPB with the self tapping screws provided. Figure 8.8 Heat & Glo • Grand-I35-C, Grand-I35-SP, Supreme-I30-C, Supreme-I30-SP • 2206-901 Rev. P • 6/14...
  • Page 27: Gas Information

    fl exible gas connector are connected to the 1/2 inch (13 mm) control valve inlet. • If substituting for these components, please consult local codes for compliance. Heat & Glo • Grand-I35-C, Grand-I35-SP, Supreme-I30-C, Supreme-I30-SP • 2206-901 Rev. P • 6/14...
  • Page 28: Electrical Information

    (See Installation instructions for remote control/fronts). Figure 10.1 Ignitor Button • If desired an additional wall switch or thermostat may be added to system. Heat & Glo • Grand-I35-C, Grand-I35-SP, Supreme-I30-C, Supreme-I30-SP • 2206-901 Rev. P • 6/14...
  • Page 29 Figure 10.2 IPI Wiring Diagram PILOT ASSEMBLY THERMOCOUPLE THERMOPILE PIEZO VALVE OPTIONAL WALL SWITCH, ROCKER THERMOSTAT OR REMOTE SWITCH Figure 10.3 Standing Pilot Ignition Wiring Diagram Heat & Glo • Grand-I35-C, Grand-I35-SP, Supreme-I30-C, Supreme-I30-SP • 2206-901 Rev. P • 6/14...
  • Page 30: Optional Accessories Requirements

    PLUG INTO 120V EXISTING OUTLET DC REGULATOR RECEPTACLE VARIABLE SPEED CONTROL BLOWERS FUSE WIRE BLOWER TEMPERATURE RECEPTACLE ASSEMBLY SENSOR SWITCH FUSE WIRE ASSEMBLY Figure 10.4 Fan Wiring Diagram Heat & Glo • Grand-I35-C, Grand-I35-SP, Supreme-I30-C, Supreme-I30-SP • 2206-901 Rev. P • 6/14...
  • Page 31: Fan Wiring With Remote

    DC REGULATOR RECEPTICLE BLOWERS AUX 300 MODULE FUSE WIRE TO CONTROL ASSEMBLY MODULE FUSE WIRE ASSEMBLY BLOWER RECEPTICLE Figure 10.5 Wiring Diagram - Fan with RC200/RC300 Remote Heat & Glo • Grand-I35-C, Grand-I35-SP, Supreme-I30-C, Supreme-I30-SP • 2206-901 Rev. P • 6/14...
  • Page 32: Finishing

    Combustible facings must not extend behind the insert surround. For non-combustible material specifi cations refer to section 1.E. Figure 11.1 Clearances to Mantels or other Combustibles above Appliance Heat & Glo • Grand-I35-C, Grand-I35-SP, Supreme-I30-C, Supreme-I30-SP • 2206-901 Rev. P • 6/14...
  • Page 33: Appliance Setup

    • Place lava rock in front of and to the sides of the burner. Figure 12.2 Placement of Embers PLACE LAVA ROCK IN SHADED AREA ONLY Figure 12.1 Placement of Lava Rock Heat & Glo • Grand-I35-C, Grand-I35-SP, Supreme-I30-C, Supreme-I30-SP • 2206-901 Rev. P • 6/14...
  • Page 34: Install The Log Assembly

    Log #1 (SRV2205-702) Position Log #1 as shown in Figure 3. Mate the left grate tine with the log groove. Rest the nose of the log on the log support as shown. Heat & Glo • Grand-I35-C, Grand-I35-SP, Supreme-I30-C, Supreme-I30-SP • 2206-901 Rev. P • 6/14...
  • Page 35 Log #5 (SRV2205-710): Mate the notch on Log #5 with the second grate tine from the left as shown in Figure 10. Set the other end of the log on the fl at spot of Log #1. See Figure 3. Heat & Glo • Grand-I35-C, Grand-I35-SP, Supreme-I30-C, Supreme-I30-SP • 2206-901 Rev. P • 6/14...
  • Page 36 Place the wider end of the log on the fl at spot of Log #2. See Figure 5 and Figure 7 for locations of fl at spots. 2205-935C Heat & Glo • Grand-I35-C, Grand-I35-SP, Supreme-I30-C, Supreme-I30-SP • 2206-901 Rev. P • 6/14...
  • Page 37 Rotate the right end of Log #2 clockwise, until it comes into contact with the grate tine. Heat & Glo • Grand-I35-C, Grand-I35-SP, Supreme-I30-C, Supreme-I30-SP • 2206-901 Rev. P • 6/14...
  • Page 38 Log #6 SRV(2206-706): Position Log #6 as shown in Figure 8. See Figure 7 for additional references. Rest the left end of Log #6 on the fl at spot of Log #3. Position the nose of Log #6 on the fork of Log #5. 2206-935C Heat & Glo • Grand-I35-C, Grand-I35-SP, Supreme-I30-C, Supreme-I30-SP • 2206-901 Rev. P • 6/14...
  • Page 39: Fixed Glass Assembly

    SUPREME-I30-C 3/8 in. 1/2 in. SUPREME-I30-SP GRAND-I35-C 3/8 in. 1/2 in. GRAND-I35-SP Figure 12.3 Fixed Glass Assembly Heat & Glo • Grand-I35-C, Grand-I35-SP, Supreme-I30-C, Supreme-I30-SP • 2206-901 Rev. P • 6/14...
  • Page 40: Troubleshooting

    Take a reading at the thermopile leads. The reading should be 350 millivolts minimum. Replace the thermopile if the read- ing is below the minimum. Heat & Glo • Grand-I35-C, Grand-I35-SP, Supreme-I30-C, Supreme-I30-SP • 2206-901 Rev. P • 6/14...
  • Page 41 Ensure that the glass is tightened properly on the unit, particularly on top corners. Heat & Glo • Grand-I35-C, Grand-I35-SP, Supreme-I30-C, Supreme-I30-SP • 2206-901 Rev. P • 6/14...
  • Page 42: Intellifireā„¢ Plus Ignition System

    fl ame sensing rod. Verify continuity with a multi-meter with ohms set at lowest range. Replace pilot if any damage is detected. Heat & Glo • Grand-I35-C, Grand-I35-SP, Supreme-I30-C, Supreme-I30-SP • 2206-901 Rev. P • 6/14...
  • Page 43: Reference Materials

    4-11/16 4-9/16 *Note: Location G on Figure 14.1 is measuring the appliance depth, for installation depth reference Location G on Figure 5.1. Figure 14.1 Appliance Dimensions Heat & Glo • Grand-I35-C, Grand-I35-SP, Supreme-I30-C, Supreme-I30-SP • 2206-901 Rev. P • 6/14...
  • Page 44: Vent Kits Components

    FLEX3-30: One 3 inch fl exible liner expands to 30 feet. FLEX-CNCT: Connector kit - 3 inch liner to 3 inch liner, one connector per kit. Heat & Glo • Grand-I35-C, Grand-I35-SP, Supreme-I30-C, Supreme-I30-SP • 2206-901 Rev. P • 6/14...
  • Page 45: Service Parts

    Blower Assembly GFK-210-C Power Cord Assembly 2206-068 Cord Assembly 2201-017 Fuse Wire Assembly Qty 2 req 2206-085 Additional service part numbers appear on following page. 6/14 Heat & Glo • Grand-I35-C, Grand-I35-SP, Supreme-I30-C, Supreme-I30-SP • 2206-901 Rev. P • 6/14...
  • Page 46: Log Set Assembly

    2206-800 Rheostat GFK-210-C Blower 2206-068 Wire Assembly 2201-017 Cord Assembly Qty 2 req 2206-085 Fuse Wire Assembly Additional service part numbers appear on following page. 3/14 Heat & Glo • Grand-I35-C, Grand-I35-SP, Supreme-I30-C, Supreme-I30-SP • 2206-901 Rev. P • 6/14...
  • Page 47 **Fuse for battery pack can be sourced locally, not a warranty item. Specs are 250v, 1A fuse, 3/4” long Additional service part numbers appear on following page. Heat & Glo • Grand-I35-C, Grand-I35-SP, Supreme-I30-C, Supreme-I30-SP • 2206-901 Rev. P • 6/14...
  • Page 48 Brass Connector Pkg of 5 303-315/5 Valve NG 2166-300 19.10 Valve LP 2166-301 19.11 046-018A Temp Sensor Assembly Additional service part numbers appear on following page. Heat & Glo • Grand-I35-C, Grand-I35-SP, Supreme-I30-C, Supreme-I30-SP • 2206-901 Rev. P • 6/14...
  • Page 49 GRAND-I35-C Conversion Kits Conversion Kit NG NGK-I35-C Conversion Kit LP LPK-I35-C Pilot Orifi ce NG 593-528 Pilot Orifi ce LP 593-527 Regulator NG NGK-DXV-50 Regulator LP LPK-DXV-50 Heat & Glo • Grand-I35-C, Grand-I35-SP, Supreme-I30-C, Supreme-I30-SP • 2206-901 Rev. P • 6/14...
  • Page 50: Contact Information

    5890485, 5941237, 6006743, 6019099, 6053165, 6145502, 6374822, 6484712, 6601579, 6769426, 6863064, 7077122, 7098269, 7258116, 7470729, 8147240 or other U.S. and foreign patents pending. 2000-945B Printed in U.S.A. - Copyright 2014 Heat & Glo • Grand-I35-C, Grand-I35-SP, Supreme-I30-C, Supreme-I30-SP • 2206-901 Rev. P • 6/14...

This manual is also suitable for:

Grand-i35-spSupreme-i30-spSupreme-i30-c

Table of Contents
