Hubbell 4310 Catalog

Hubbell Industrial Controls, Inc.
Fused Magnet Safety Disconnect Switch
Catalog 4310 • August 2003 • New
Description
The 4310 fused magnet safety disconnect switch is
designed to safely allow the operator of a lifting magnet
to disconnect the highly inductive magnet while the
magnet is still energized. Standard safety switches are
not designed to safely disconnect an energized magnet.
The 4310 has (3) power poles.
power poles to disconnect the incoming power and a
third normally closed power pole that shunts the
magnets energy into a discharge resistor when the
disconnect is switched to the off position.
Features
•
Supplied in a NEMA type 3R wall mounting
enclosure.
•
Rated 300 VDC. Max
•
All switches have a padlockable thru-the-door
operator
•
High capacity discharge resistor
Part Number
4310-86262-004
4310-86262-002
4310-86273-001
Specify magnet operating current, cold.
Enclosure type is NEMA 3R
Order by part number
Two normally open
Fused At Magnet Amps (Max)
100 Amps
200 Amps
400 Amps
Enclosure Dimensions
H
67 29.00
134 29.00
267 31.25
How To Order
Telephone (336) 434-2800 • FAX (336) 434-2803
List Price E43
W D
12.63 10.00 $1,900.00
12.63 10.00 $2,250.00
24.00 13.29 $6,130.00
Hubbell Industrial Controls, Inc.
A subsidiary of Hubbell Incorporated
4301 Cheyenne Dr., Archdale, NC. 27262
http://www.hubbell-icd.com
Sales@hubbell-icd.com
4310
