Hubbell 2243 Specification Sheet

Hubbell Industrial Controls, Inc.
Speed Responsive Switch
Price List 2243/2260 • June 2008
CATALOG
NUMBER
2243-301
2243-302
2243-303
2243-304
2243-311
2243-312
2243-313
2243-314
All switches are supplied in NEMA Type 4 Surface Mounting Cast Aluminum enclosures.
Power requirements: 115 Volts 50/60 Hertz, + 10% - 15%, 15 Watts. Ambient Temperature
Range +32°F to 158°F (0°C to 70°C). Repeatability: ± 2% within rated voltage and tempera-
ture range. Max. Contact Interrupting Rating: 115V, AC 2 Amp. @ 35% P.F.
(1) Relay de-energizes when descending set point is reached.
(2) Relay de-energizes when ascending set point is reached.
(3) Contacts are factory set at minimum decreasing and minimum increasing speeds as
shown, unless otherwise specified on customer's purchase order.
CATALOG
PART NUMBER
NUMBER
2260-021 HC48230002
2260-022 HC48230004
All switches are supplied in NEMA Type 13 enclosures. Power requirements: 117 Volts 50/60
Hertz, + 10% - 15%, 4 Watts. Ambient Temperature Range 0°F to 158°F (-18°C to +70°C).
Repeatability: ± 2% within rated voltage and temperature range. Max. Contact Interrupting
Rating: 120V, AC 2.5 Amp. @ 40% P.F.
(4) Contacts are factory set at 3 RPM increasing speed, unless otherwise specified on
customer's purchase order.
PART NUMBER
HC30349000
HC30350000
HC30351000
HC30353000
HC30490000
Prices are subject to change without notice.

2243 TYPE D ELECTRONIC SPEED SWITCHES

(3)
PART
NUMBER
(3)

UNDERSPEED DETECTION (1) - NON DIRECTIONAL CONTACTS

DECR. SPEED
HC00743301 0.57
HC00743302 3.8
HC00743303 14.3
HC00743304 47.5

OVERSPEED DETECTION (2) - NON DIRECTIONAL CONTACTS

ASC. TRIP
HC00743311 0.6
HC00743312 4.0
HC00743313 15.0
HC00743314 50.0

2260 TYPE E ELECTRONIC SPEED SWITCHES

(4) CONTACT ADJUSTMENT RANGE
MINIMUM TRIP SPEED
(4) INC.
DECR. SPEED
SPEED
NON DIRECTIONAL CONTACTS
3.0 2.25
3.0 2.25

SPEED RESPONSIVE SWITCH ACCESSORIES

FLEXIBLE COUPLINGS

CUSTOMER END
COUPLING BORE KEYWAY
.500 / .5015" .125 x .062"
.5115 / .512 .125 x .056
.625 / .6265 .188 x .094
.750 / .7515 .156 x .078
.625 / .6265 .094 x .0529
CONTACT ADJUSTMENT RANGE
MINIMUM RPM MAXIMUM RPM
INCR. SPEED
DECR. SPEED
ADJ. RANGE
0.6 - 0.71 4.8
4.0 - 4.7 16.0
15.0 - 17.8 48.0
50.0 - 59.4 240.0
DESC. TRIP
ASC. TRIP
ADJ. RANGE
0.48 - 0.57 6.0
3.2 - 3.8 20.0
12.0 - 14.3 60.0
40.0 - 47.5 300.0
MAXIMUM TRIP SPEED
INCR. SPEED DECR. SPEED
300 225
DIRECTIONAL CONTACTS
300 225

SEPARATE MOUNTING GEAR BOXES

LIST PRICE
PART NUMBER
FK
HC65222002
$210
$210 HC65222001
$210
$210
$210
2243/2260
LIST PRICE
FH
INCR. SPEED
ADJ. RANGE
5.1 - 6.0 $5,130
16.9 - 20.0 $5,130
50.6 - 60.0 $5,130
253.0 - 300.0 $5,130
DESC. TRIP
ADJ. RANGE
4.8 - 5.7 $5,130
16.0 - 19.0 $5,130
48.0 - 57.0 $5,130
240.0 - 285.0 $5,130
LIST PRICE
MOUNTING
FH
SURFACE/FLANGE $3,180
SURFACE/FLANGE $3,550
LIST PRICE
GEAR RATIO
FK
2.94 To 1 $1,425
8.64 To 1 $2,970
Hubbell Industrial Controls, Inc.
a subsidiary of Hubbell Incorporated
4301 Cheyenne Drive, Archdale, NC 27263
Telephone (336) 434-2800 · Fax (336) 434-2803
http://www.hubbell-icd.com
