Uploading and Upgrading

USB
TCP/IP
Operations Guide – DOC. 6655B
Crestron recommends using the latest programming software and that each device
contains the latest firmware to take advantage of the most recently released features.
However, before attempting to upload or upgrade it is necessary to establish
communication. Once communication has been established, files (for example,
programs, projects or firmware) can be transferred to the control system (and/or
device). Finally, program checks can be performed (such as changing the device ID
or creating an IP table) to ensure proper functioning.

Establishing Communication

Use Crestron Toolbox for communicating with the TPMC-4XG; refer to the Crestron
Toolbox help file for details. There two methods of communication.
USB Communication
PC RUNNING
CRESTRON TOOLBOX
•
The TPMC-4XG should be used with a static IP address whenever possible.
•
Use a USB cable to connect the TPMC-4XG to a PC running the Crestron
Toolbox.
•
Open the System Info window; click the "Enter an address . . ." icon
(pencil) to display the "Edit Address" window.
•
Select USB as the connection type, and select "TPMC-4XG" from the
Device Type drop down list (click OK when the "Warning" notice
appears).
NOTE: Required for operation with a Crestron control system.
Ethernet Communication
PC RUNNING
CRESTRON TOOLBOX
•
Establish wireless communication between TPMC-4XG and PC via the
WAP.
•
Enter the IP address, IP mask, and default router of the TPMC-4XG via the
Crestron Toolbox (Functions | Ethernet Addressing); otherwise enable
DHCP.
•
Confirm Ethernet connections between TPMC-4XG and PC.
Isys i/O™ Handheld WiFi Touchpanel
USB
ETHERNET
Isys i/O™ Handheld WiFi Touchpanel: TPMC-4XG • 29
