SmartNode 4830 DSL Series User Manual

Introduction

The SN4830 model has a built-in G.SHDSL or ADSL modem. The modem appears in the configuration as
"port dsl 0 0" mode.
Profile
napt
WAN
CAUTION
Note

Line Setup

There is no line modulation setting. The modems automatically adapt to the bit rate and modulation used.
The status LED on the back of the device is blinking while the modem attempts to connect and lit when the
link is established. If the modem keeps blinking, check the cabling,

Configuring PPPoE

Figure 13 explains how to configure PPPoE on the SmartNode's built-in G.SHDSL card. To configure the
DSL port for PPPoE, first you need to log in to the SmartNode via the CLI and enter configuration mode.
login: administrator
password: <enter>
SN4xxx>enable
SN4xxx>#configure

Introduction

Figure 13. Configuring the G.SHDSL card for PPPoE
The Modem setup uses IP messages within its own subnet:
192.0.2.0/24. SmartNodes with built-in modems cannot use this
subnet in any other way.
For information about the specifications of the G.SHDSL daughter
card,
"Specifications"
see Appendix B,
port
dsl 0 0
\ \
pvc
vpi 8 vci 35
pppoe
session MyISP
WAN
interface
context
ip
on page 53.
4 • DSL Basic Configuration
Subscriber PPP
MySubscriber
42
