Software Update Procedure
To update the access point software:
1.
On the menu, click Update Software under Management. The Update
Software page appears.
2.
Click Browse. The Choose File dialog box appears.
3.
Go to the folder where you saved the software update file, select the file,
and then click Open. The Choose File dialog box disappears.
4.
Click Update. A progress bar appears.
When the software update is complete, the access point reboots itself, and
then redirects you to the Information page.
5.
Check the value for Software Version and verify that it shows a later
version than what was installed before the update.
Viewing the List of Connected Devices
You can view which wireless devices are connected to the access point
anytime by accessing the Connected Devices page on the Web interface.
To access the page, click Connected Devices on the menu. A table appears,
which lists the following information about each associated wireless device:
MAC address: Displays the MAC or physical address of the associated
■
wireless device
■
Channel: Displays the current radio channel on which the wireless device
is receiving broadcast signal
■
Data rate: Displays the transmission speed at which the wireless device
is receiving data from the access point. Data rates shown on this page will
depend on the type of associated wireless device. 802.11a and 802.11g
devices can have data rates up to 54Mbps, while 802.11b devices can only
have up to 11Mbps.
RSSI: Displays the received signal strength of the wireless device on the
■
current wireless channel. The higher the RSSI, the better the signal. The
strongest signal will have an RSSI of 100.
Managing the Access Point
Viewing the List of Connected Devices
5-7
