Digital Video/Audio
and Serial I/O Extender
User's Manual
for the M5-2C2
© 2008 Opticis. All Rights Reserved
Revision 1.0
Opticis Locations
Opticis Co., Ltd.
#304 Byucksan Technopia
434-6 Sangdaewon-Dong, Chungwon-Ku
Sungnam City, Kyungki-Do
462-120, South Korea
Tel:
+82 (31) 737-8033
Fax:
+82 (31) 737-8079
For order support, please contact your Distributor or Reseller.
For technical support, check with the Opticis web site
contact
techsupp@opticis.com
Opticis North America Ltd.
330 Richmond street, Suite 100
Chatham, Ontario
Canada N7M 1P7
Tel: (519) 355-0819
Fax: (519) 355-0520
www.opticis.com
or
Advertisement
Table of Contents
Related Manuals for opticis M5-2C2
Summary of Contents for opticis M5-2C2
- Page 1 Canada N7M 1P7 462-120, South Korea Tel: +82 (31) 737-8033 Tel: (519) 355-0819 Fax: +82 (31) 737-8079 Fax: (519) 355-0520 For order support, please contact your Distributor or Reseller. For technical support, check with the Opticis web site www.opticis.com contact techsupp@opticis.com...
- Page 2 Manual Contents Welcome! __________________________________________ Congratulations on your purchase of the M5-2C2, Digital Video/Audio and Serial Manual Contents I/O extender. This manual contains information that will assist you in installing Welcome!, Product Description and operating the product. System Requirements for Setup...
- Page 3 OS and application. AC/DC Power Adapter Technical Advisory The power of M5-2C2 is designed to supply to either Uplink or Downlink module by plugging the power plug. Figure 2 – Connection of DVI and RS232 Cable to Uplink Module...
- Page 4 Step 5 Connect two(2) CAT5 or CAT6 cables to RJ45 receptacles of the Uplink and Downlink modules, as shown in Fig. 7. Opticis recommend solid shielded CAT6 cables. Carefully check the wiring sequence of CAT5 or CAT6 cable as Fig. 8 and ensure each RJ45 connector is fully engaged.
- Page 5 Booster and EQ Mode is used extensions over 10 m (33 feet). By default, M5- 2C2 transmitter and receiver are set to “BOOSTER” and “AUTO” respectively. Under the default setting, M5-2C2 is optimized for the length from 10m (33feet) to 40m (130feet). If you don’t get a picture still or have noise, Booster and EQ Mode Setting are required like the followings.
- Page 6 • Check if the PC and display are powered on and properly booted. Extension limit: • Reset the M5-2C2-TR using Reset button on Uplink and Downlink 50m (160feet) at WUGA (1,900x1,200) 24bit color at 60Hz refresh modules. • Test to make sure the modules are working normally with short CAT5 rate for PC and 1080p for HDTV.
- Page 7 (2) this device must accept any interference received, including interference that service, for a period of one (1) year from the date of purchase from Opticis or may cause undesired operation. This equipment has been tested and found to its authorized resellers.
