Thank you for purchasing this EMPHASER amplifier!
To maximize the performance of this amplifier and your complete car audio system install,
we recommend that you acquaint yourself thoroughly with all technical features and con-
trolling options of this EMPHASER amplifier. Please read this manual carefully, before
attempting the installation.
If, after reading this manual, you still have questions regarding functions or the installation
of the amplifier, we recommend that you consult your EMPHASER dealer.
4

1. KEY FEATURES

• 1CH / 2CH / 4CH BJT Amp for 4/2 Ohms Stereo Operation
• Mono Bridge Operation into 4 Ohms
• Die Cast Aluminium Heatsink
• Top Control Access of X-Over Controls
• Adjustable 12dB/octave HP + LP X-Over
• Adjustable 12dB/octave Subsonic X-Over
• Phase Inversion Switch
• Top Side Amp Status LED
• High Level Input (4-Pin or 8-Pin)
• Advanced Protection Circuit
• Replaceable ATC Fusing
• Moulded Power + Speaker Terminal
• Remote Bass Control (only for EA1300)
• Master / Slave Input + Output (only for EA1300)
