4. Adjustable burnback control
5. Spot Welding & stitch welding facilities
6. Digital Amp & Volts meters
7. Euro type torch fittings for easy torch fitment/replacement
Recommended Processes
The R-Tech C-MIG315 is recommended for the MIG welding processes within its output capacity of
315 Amps DC
Equipment Limitations
The R-Tech C-MIG 315 is protected from overloads beyond the output ratings and duty cycle as per
machine specifications with thermostat protection of the output coils and rectifiers.
Welding Capability – Duty Cycle
The R-Tech C-MIG 315 is rated at 315 Amps at 40% duty cycle on a ten minute basis. If the duty
cycle is exceeded a thermal protector will shut machine off until the machine cools.
Controls and Settings
Front Panel
