Installation - R-Tech C-MIG 315 Operation Instructions Manual

Technical Specifications
Model No.
Input
MIG Operation
Gross Weight
Insulation
Safety Precautions
Read entire section before starting installation
WARNING!
Electric Shock can kill – Only qualified personnel should perform this installation. Turn off input
power at the fuse box before working on this equipment. Do not touch electrically live parts. Always
connect the machine to an earthed mains supply as per national recommended standards.
Select suitable location
Place the welder where clean cooling air can freely circulate in and out of the front & rear louver
vents. Dirt, dust or any foreign material that can be drawn through vents into welder must be kept to
a minimum. Failure to observe these precautions can result in excessive operating temperatures
which can lead to plant failure.
Grinding
Do not direct grinding particles towards the welder. An abundance of conductive material can cause
plant failure.
Stacking
This machine cannot be stacked.
4

Installation

R-Tech C-MIG 315
Rated Input Power
Rated Input Current
Rated Output Current
Duty Cycle @ 315AMPS
Duty Cycle @ 200AMPS
Output current Range
No Load Voltage
Voltage Adjustment Range
Suitable Wire Diameter
415V 3 ~ AC 50/60Hz
6.2 KVA
18 AMPS
315 AMPS
º
40% @ 40 C
º
100% @ 40 C
40-315 AMPS
38V MAX
16V – 33V +/- 3V
0.8mm 1.0mm 1.2mm
82 KG
Class F
