Inserting a CompactFlash card

1.
Position the CompactFlash card in the direction as shown in the illustration below.
2.
Insert the card being certain of the orientation - all leading manufacturers of
CompactFlash cards adhere to a specification requiring a positive keying of the card.
Gently push the card in all the way until the card is locked in place. The card will slide in
on the molded rails and a slight amount of resistance will be felt as the connectors make
contact. This is normal.
WARNING: Be careful not to insert the CompactFlash card in the wrong direction - be sure the
connectors are facing inward and the card is not inserted upside down. If it is forced in, the ZiO!
or CompactFlash card may be damaged or data on the card may be lost or corrupted.
IMPORTANT: If excessive force is required or the card just doesn't seem to fit, do not attempt
to force the card in the reader, instead, call Microtech's toll free tech support number for
assistance.
26
128
MB
Digital FlashFilm
?
HELP
CONTENTS
CompactFlash connectors
