- Page 1 Microtech PCD-47 SCSI PC Card Reader/Writer PCD-47B — internal for various systems PCD-47-MAC — external for Macintosh PCD-47-PC — external for PC Compatibles PCD-47 User’s Manual ver 1.1...
-
Page 2: Preface
SmartMedia (both 3.3V and 5V, supports up to 128MB of SmartMedia) may be used. * Support of the PCD-47 series for any Unix system on an OEM basis must be arranged under a separate contract. • MS-DOS is the registered trademark of Microsoft. -
Page 3: Table Of Contents
Table of Contents Preface ......................2 FCC radio frequency interference warning ..........5 Precautions ....................6 Safety Precautions and handling ..............7 1. Product outline ..................8 Using with Macintosh .................. 8 Using with Windows ..................8 Using with Unix Systems ................9 2. - Page 4 Table of Contents Continued When the lock indicator is lit ..............24 10. Troubleshooting ................... 26 Windows Troubleshooting ................26 Macintosh Troubleshooting .................27 11. Specifications ..................28 Dimensions ....................29 SCSI Command Set ..................31 Safety Standards ..................32 Index ......................33...
-
Page 5: Fcc Radio Frequency Interference Warning
FCC radio frequency interference warning This equipment generates and uses radio frequencies, and if not installed and used in strict accordance with the manufacturer’s instructions, can cause interference to radio and television reception. This equipment has been certified and found to comply with the limits for a Class B computing device in accordance with the specifications in Subpart J of Part 15 of the FCC rules, which are designed to provide reasonable protection against such interference in a commer-... -
Page 6: Precautions
Precautions I Power source The PCD-47 uses a standard domestic household power cord. The PCD-47-MAC and PCD-47-PC operate at voltages between 100V to 240V. The PCD-47B operates using the computer’s electrical power. I Power cord - Do not bend the power cord excessively or place heavy objects on - Damage to the cord may cause fire or electric shock. -
Page 7: Safety Precautions And Handling
Safety Precautions and handling I Proper places for use and storage - This unit is to be used at temperatures between +5 C and +40 C and at relative humidities between 20% and 80%(with no condensation). - Do not use or store the unit in an excessively hot or cold place. - Do not use or store the unit in a dusty place or in direct sunlight. -
Page 8: Product Outline
Microtech includes Software Architects DOS Mounter SE with the Macintosh version of the PCD-47 (part no: PCD-47-MAC). For owners of other versions of the PCD-47, this software can be purchased as an option through Microtech along with the reader, or may be purchased from a separate vendor. -
Page 9: Using With Unix Systems
‡ Using with Unix Systems This page should explain the basic features of Unix, and pointers to Unix informaiton, and mounting of Dos file systems. Unix systems use a disk format that is different from Windows machines, and memory cards used in digital cameras. Most Unix systems require a special mounting procedure such as the following to access DOS formatted media: mount - dev/scsi/dev000001 /dev/pccard... -
Page 10: Accessories
2. Accessories Packages contain the following items: PCD-47-MAC and PCD-47-PC terminator I N T E R N A T I O N A L, I N C. Users manual power cord (this manual) PCD-47B (Internal) Users manual 5.25” mounting kit... -
Page 11: Identifying The Parts
Type I, II, and III PC cards may be inserted, as well as SmartMedia and CompactFlash. Note that CompactFlash and SmartMedia have their own special slots. 5) Power Button The power switch is only featured PCD-47 external models. Internal models are activated when the hostcomputer is powered... - Page 12 REAR PANEL ............(6) Fan When this switch is "on", the fan is active. (7) SCSI connector SCSI cable is connected here. (8) Power connector For external units, connect the power cord included in the package to this connector.
-
Page 13: Making Connections With A Computer
4. Making connections with a computer This drive unit connects to a computer through a SCSI cable. There are two types of connection depending on whether or not an additional SCSI device is to be used. These two cases are discussed later in this section. -
Page 14: Termination
Termination When this unit is the only device on the SCSI chain, or the last device on the SCSI chain, it must be terminated. External: attach the terminator to the SCSI connector not being used. Internal: Default is terminated. When the termination pin jumper is “off”, the unit is terminated. -
Page 15: Use With Other Scsi Devices
To obtain this information, refer to the related computer and SCSI device manuals. Take care not to use the same SCSI ID number more than once. * The PCD-47 uses 3 SCSI IDs. See “Setting the SCSI ID” for a table explaining the SCSI IDs. -
Page 16: Setting Scsi Id (External)
SCSI ID=6 are available for this drive unit. It will therefore be necessary to pay close attention to the SCSI IDs on your Macintosh, as the PCD-47 requires three SCSI IDs. See “Setting SCSI IDs” for an explanation of SCSI ID usage. -
Page 17: Scsi Id Table
SCSI ID Table ID setting PCMCIA SmartMedia CompactFlash Setting SCSI ID (internal) SCSI ID pins (first 3 rows) SCSI ID pins (first 3 rows) terminator To set the SCSI ID on internal units, set the three jumper pins as shown in the diagram. The default SCSI ID is 4 (5 and 6). -
Page 18: Scsi Id Settings For Windows Computers
SCSI ID Settings for Windows Computers SCSI IDs “0” and “1” may have been previously assigned to the built-in hard disk drive. Therefore, the value “2” is recommended as the first SCSI ID for this drive unit. For details, consult the manuals for your SCSI board. -
Page 19: Installation (Windows)
5. Installation (Windows) Applicable enviroment The PCD-47 can be installed in the following environments: - SCSI board Adaptec SCSI board (recommended) - Software driver Adaptec EZ-SCSI (recommended) - Operating system MS-DOS 5.0 or higher - Windows Ver. 3.x, Win 95/98, Windows NT... -
Page 20: External Reader Installation
External Reader Installation 1. Follow the directions above to set up your SCSI interface card unless you have already done so previously. 2. Close all applications, exit Windows to return to the command prompt (or shutdown Windows 95), and turn off the system. 3. - Page 21 6. Basic operations (Windows) This section describes the operation relating to PC cards. For installa- tion, refer to Section 6 “Using with a Macintosh computer” and Section 7 “Using with a Windows computer”. Inserting the PC card 1. Insert the PC card into the slot in the correct direction as shown in the figure below, then push the card in all the way until the eject button pops out.
- Page 22 3. Using a Windows computer, three icons will appear under “My Com- puter” as a removable hard drive (a drive letter will also be assigned). Double click on an icon to open the drive. If media is not inserted when double clicking the icon, the message “Device not ready”...
-
Page 23: Removing The Pc Card
7. Installation (Macintosh) Macintosh driver software is required to automatically mount digital film cards with the PCD-47 in a Macintosh environment. Microtech includes the driver software with the external Macintosh version of the PCD-47 only (part no. PCD-47-MAC). For owners of other versions of the PCD-47(ex: part no. -
Page 24: When The Lock Indicator Is Lit
9. Firmware Upgrades From time to time firmware upgrades may be made available as new computer systems, smartmedia cards, and digital applications become available on the market. If firmware upgrades are made available, the necessary program files will be made available, along with the updated instructions, at http://www.microtechint.com/firmware/. - Page 25 When the lock indicator is lit For Macintosh computers, the lock indicator lights when the PC card is mounted. Dragging the PC card icon and dropping it onto the trash icon ejects the PC card, deletes the PC card icon and turns off the lock indicator on this drive unit.
-
Page 26: Troubleshooting
CONFIG.SYS file for the proper setting. The card is not properly Insert the card properly. inserted. The PCD-47 uses three SCSI IDs. Please refer to the table showing ID selection and be sure you do not have SCSI ID conflicts. -
Page 27: Macintosh Troubleshooting
Use a standard SCSI cable The SCSI cable is too long. (6m or shorter). Change the cable The PCD-47 drive and other SCSI devices are not properly connections. connected. Activate terminator. The terminator is not activated. -
Page 28: Specifications
11. Specifications Card type: ATA cards, PCMCIA hard disks CompactFlash SmartMedia Card slots: one Type I/II/III, one SmartMedia one CompactFlash Host interface: SCSI-II SCSI connector: External: 50 pin Centronics Internal: 50 pin header Transfer rate: 4MB/sec (asynchronus transfer) Power requirements: External: AC 100V to 240V, 50/60 Hz Internal: 5v/12v DC (Standard PC Connector) -
Page 29: Dimensions
Dimensions PCD-47B Top view 165.4 mm Front view 101.6 mm Side view 147.8 mm... - Page 30 Dimensions PCD-47 External 55 mm I N T E R N A T I O N A L, I N C. 211 mm 169 mm...
-
Page 31: Scsi Command Set
SCSI Command Set Command name Command Code Test Unit Ready Rezero Unit Request Sense Format Unit Read Write Seek Inquiry Mode Select Start/Stop Unit Send Diagnostic Prevent/Allow Media Removal Read Capacity Read Write Seek Write and Verify Verify Read Defect Data... -
Page 32: Safety Standards
Safety Standards For more information on safety standards, please refer to the Pre- cautions section on page 6, and the Safety Precaution and Handling section on page 7. -
Page 33: Index
Index AC 28 high voltages 6 noises 6 Accessories 10 HP 2 not ready 23 Ambient 28 Humidity 28 NT 19 benzene 7 Initialize 23 operations (Windows) insecticide 7 Inserting 20 outlet 6 Installation 19 outline 8 cabinet 7 Installation (Macintosh) Cause 26 CompactFlash 28 Internal 20... - Page 34 Index severe electric shock 6 shock 6 SmartMedia 2, 20, 23, 28 smoking 6 softarch.com 8 Specifications 28 SSFDC 2 support 27 Symptom 26 temperature 7 Termination 14 terminato 26 Test Unit Ready 31 transportation 7 Macintosh 27 Troubleshooting 26 Windows 26 Unix 9 unix shell 9...
- Page 35 Microtech International, Inc. 242 Branford Road, North Branford, CT. 06471-1303 USA Tel: 800-626-4276 (toll-free US only) Tel: + 203-483-9402 Fax: + 203-483-9792 www.microtechint.com...
