Advantech AIMB-227 AMD Startup Manual

AIMB-227 AMD Merlin Falcon Quad Core Mini-ITX with
DP/DVI-D/HDMI, 6COM, and Dual LAN
Startup Manual
Packing List
Before you begin installing your card, please make sure that
the following items have been shipped:
1. AIMB-226 AMD R-series RX-421BD/RX-216GD, G-
series GX-224IJ Mini- ITX motherboard
2. SATA HDD cable x 1
3. SATA power cable x 1
4. Serial port cable (1 to 4) x 1
5. Serial port cable (1 to 1) x 2
6. I/O port bracket x 1
7. Startup manual x 1
8. Warranty card x 1
9. CPU Cooler x1 or CPU Heatsink x1
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://support.advantech.com/
This manual is for the AIMB-227 series Rev.A1.
Part No. 2006B22700
Printed in China

Standard SBC Functions

• CPU: AMD R-series SOC RX-421BD Quad core 2.1 GHz
• BIOS: AMI 16-Mbit SPI
• System Memory: Up to 16 GB; 260-pin SODIMM x
• SATA Interface: Two onboard Serial ATA connectors and
• Serial ports: Six serial ports; COM3 is RS-232/422/485,
• Watchdog timer: 1~255 level timer intervals
• USB: Supports up to two USB 3.0 and two USB 2.0 ports,
• GPIO: 8-bit general purpose Input/Output
Graphic Interface
• Controller: AMD Radeon 3rd Generation GCN (Up to 8
• HDMI: Support 4096 x 2160 @ 60Hz Max (60Hz requires
• LVDS: supports dual channel 48-bit up to 1920 x colay
• DP: Supports DP++, resolution up to 4096 x 2160 @
• DVI-D: Supports up to SXGA 1920 x 1200

Ethernet Interface

• Connector: RJ-45 x 2
• LAN1: 10/100/1000 Mbps GbE Realtek 8111G
• LAN2: 10/100/1000 Mbps GbE Realtek 8111G

Mechanical and Environmental

• Dimensions (L x W): 170 mm x 170 mm (6.69" x 6.69")
• Power supply voltage: 3.3V, 5V, 12V
• Power requirements:
• Operating temperature: 0 ~ 60 °C (32 ~ 140 °F)
• Weight: 0.228 kg (weight of board)
1 Edition,
st
January, 2018
Specifications
& RX-216GD Dual core 1.6 GHz & GX-224IJ Dual core
2.4GHz
2,dual channel DDR4 2133 MHz SDRAM
data transfers up to 600 MB/s, and one onboard
COM1, COM2 can be CC talk, COM4, COM5, COM6 can
be TTL and COM4 supports 5V/12V by jumper selection
and four onboard pin headers
CUs)
re-timer)
DP 1.2 port (Optional)
60Hz
Single Voltage 12V DC input ; or AT/ATX Supported by
Jumper
AIMB-227 Startup Manual 1
