Advantech AIMB-223 Startup Manual

AIMB-223 Mobile AMD G-series Dual Core Mini-ITX with
VGA/LVDS/HDMI,6 COMs and Dual LAN
Startup Manual
Packing List
Before you begin installing your single board, please make
sure that the following materials have been shipped:
1. 1 x AIMB-223 Mini ITX Motherboard
2. 1 x CD-ROM or DVD-ROM contains the following:
- User's Manual
- Drivers
3. 1 x Serial port cable
4. 2 x SATA HDD Data cable
5. 2 x SATA Power cable
6. 1 x I/O shield
7. 1 x CPU cooler
8. 1 x Startup manual
9. 1 x Warranty card
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/epc
For technical support and service, please visit our
support website at:
http://service.advantech.com.tw/eservice/
This manual is for the AIMB-223 series Rev. A2
Part No. 2006022311
Specifications
Processor System
• CPU: AMD G-series Dual core 1.65 GHz
• Max. Speed: 1.65 GHz (dual core)
• L2 Cache: 512 KB
• Chipset: A55E
• BIOS: 16 M-bit SPI

Expansion Slot

• Mini-PCIe: 1
• PCIe: PCIe x1 (PCIe gen2)
• PCI: 32 bit/33 MHz PCI
Memory
• Technology: Dual channels DDR3 1066/1333 MHz
• Max. Capacity: 4 GB
• Socket: 1 x 204-pin SODIMM
Graphic Interface
• Controller: ATI Radeon HD 6310, support DirectX 11,
UVD3
• VGA: Supports up to 2560 x 1536 @32bpp
• LVDS:Supports 24-bit dual channel and 1920 x 1200
• HDMI:1920 x 1200 @ 60 MHz
• Dual Display: Supports dual display of any two display
device (CRT, LVDS, HDMI)

Ethernet Interface

• Interface: 10/100/1000 Mbps
• Controller: GbE LAN1: RTL8111G-CG;
• Connector: RJ-45 x 2

SATA Interface

• Max Data Transfer Rate: 600 MB/s
• Channel: 4
SSD Interface
• Cfast compactFlash: Cfast type I/II
Rear I/O
• VGA: 1
• HDMI: 1
• Ethernet: 2
• USB: 4 (USB 2.0 compliant)
• Audio: 3 (Mic-in, Line-out, Line-in)
• Serial: 2 (RS-232)
• PS/2: 1
2nd Edition
July 2015
GbE LAN2: RTL8111G-CG
AIMB-223 Startup Manual 1
