Electric Pressure Washer
S1700
039-8604-6
OWNER'S MANUAL
If you have any questions or comments, visit our website at www.simoniz.ca or call
our toll free hotline 1-866-4SIMONIZ (1-866-474-6664)
PLEASE KEEP THE ORIGINAL BOX, PACKAGING AND RECEIPT. BEFORE OPERATING
THIS UNIT, PLEASE READ THIS MANUAL THOROUGHLY AND RETAIN IT FOR FUTURE
REFERENCE. IF YOU MUST STORE YOUR PRESSURE WASHER IN A PLACE WHERE
TEMPERATURE IS BELOW 5ºC, YOU MUST APPLY WINTERIZING PROCEDURE TO
PROTECT IT. FAILURE TO WINTERIZE THE UNIT MAY PERMANENTLY DAMAGE PUMP
AND VOID THE WARRANTY.
S
39-8604-6
KU

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S1700 and is the answer not in the manual?

Questions and answers

Related Manuals for Simoniz S1700

Summary of Contents for Simoniz S1700

  • Page 1 S1700 039-8604-6 OWNER’S MANUAL If you have any questions or comments, visit our website at www.simoniz.ca or call our toll free hotline 1-866-4SIMONIZ (1-866-474-6664) PLEASE KEEP THE ORIGINAL BOX, PACKAGING AND RECEIPT. BEFORE OPERATING THIS UNIT, PLEASE READ THIS MANUAL THOROUGHLY AND RETAIN IT FOR FUTURE REFERENCE.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Technical specifications ......................1 Warranty ..........................2 Important precautions – Read first! ..................3 Safety features and electrical power information ..............5 Parts and diagram list ......................6 Assembly instructions ......................7 Operating instructions ......................8 Using the accessories ....................11 Working with detergents .....................12 Shutting down and cleaning up ..................13 Taking a break ......................13...

  • Page 3: Warranty

    Warranty is void if the equipment is used for commercial, rental or industrial purposes. If you have more questions, visit our website (www.simoniz.ca), or call 1-866-4SIMONIZ (1-866-474-6664).

  • Page 4: Important Precautions - Read First

    IMPORTANT PRECAUTIONS – READ FIRST Safety Warnings When using this product, basic precautions should always be followed: • Read all the instructions before using the product. • Water spray must never be directed toward any electric wiring, devices or directly toward the pressure washer machine itself, or fatal electric shock may occur. • To reduce the risk of injury, do not operate the machine near children. • Learn how to stop the machine and release pressure quickly. Be thoroughly familiar with the controls. • Stay alert—watch what you are doing. • For use with cold water supply only. Do not draw other liquids. • The pressure washer should not be used in areas where gas vapours may be present. An electric spark could cause an explosion or fire. • To minimize the amount of water getting into the pressure washer, the unit should be placed as far as possible from the cleaning site during operation.
  • Page 5 IMPORTANT PRECAUTIONS – READ FIRST WARNING - Risk of Injury Do Not Direct Discharge Stream at Persons. • High-pressure jet can be dangerous if misused. • The jet must not be directed at persons, animals, electrical devices, or the unit itself. WARNING - Risk of Explosion •...

  • Page 6: Safety Features And Electrical Power Information

    SAFETY FEATURES & ELECTRICAL POWER INFORMATION The pressure washer is equipped with a stop device that will sense when the trigger on the gun is released. It will open the power circuit to the motor, and cause the pressure washer motor to stop. The motor will start again when the trigger is pulled. WARNING The pressure washer is also equipped with a main power “ON/OFF” switch located on the unit. It should always be moved to the “OFF” position when the pressure...

  • Page 7: Parts And Diagram List

    PARTS AND DIAGRAM LIST Manual Item No. Quantity Part Name Parts Number Turbo wand ZE04-090-0004 Adjustable wand ZE04-090-0003 Gun assembly ZE03-090-0001 Left wing (Gun holder) ZE05-090-0007 High-pressure hose ZE05-090-0001 Gun holster ZE04-000-0001 Hose bracket ZE05-090-0000 Detergent bottle assembly ZE04-090-0010 Right wing (Wand holder) ZE05-090-0006 Quick-connect coupling ZE01-050-0000...

  • Page 8: Assembly Instructions

    ASSEMBLY INSTRUCTIONS Surface Preparation Before starting any cleaning task, it is important to inspect the area for objects that could create a hazard. Remove any objects from the work area that could be tripped over, such as toys or outdoor furniture. Ensure that all doors and windows are closed tightly. Attach the left wing (D) and the right wing (J) to the Attach gun holster.

  • Page 9: Operating Instructions

    OPERATING INSTRUCTIONS Make sure the ON/OFF switch is in the “OFF” position. Fasten the quick-connect coupling (K1) onto the garden hose, and then attach the quick- connect coupling (K1) to the inlet adaptor (K2).
  • Page 10 OPERATING INSTRUCTIONS A or B Insert the wand (A or B) into the spray gun, and twist 1/4 turn until rectangular tab appears. Fasten the high-pressure hose (E) tightly Attach garden hose to water supply, and onto the gun assembly (C), and tighten to turn water on. avoid leakage.
  • Page 11 OPERATING INSTRUCTIONS Plug the unit into an outlet. Before turning the unit “ON”, depress the trigger to bleed any trapped air out of the pump and hose. Release trigger, and start the pressure washer by turning ON/OFF switch to ON.

  • Page 12: Using The Accessories

    OPERATING INSTRUCTIONS USING THE ACCESSORIES Adjusting the spray The adjustable spray nozzle can be adjusted from fan to jet. The spray is adjusted from jet to fan spray by turning the nozzle as shown. CAUTION Jet spray adjustment is very aggressive. Do not adjust while spraying. We recommend a 20º spray angle for most cleaning applications to avoid damage to the surface being sprayed. CAUTION To prolong the life of the unit, it is recommended to rest the unit for 5 minutes after every 30 minutes of use.

  • Page 13: Working With Detergents

    OPERATING INSTRUCTIONS WORKING WITH DETERGENTS Working with detergent ensures a quick soaking of the dirt, and allows the high-pressure water to penetrate and remove the dirt more effectively. Always spray detergent on a dry surface, do not pre-soak area. Wetting the surface first dilutes the detergent and reduces its cleaning ability.

  • Page 14: Shutting Down And Cleaning Up

    OPERATING INSTRUCTIONS Allow detergent to remain on the surface for a short time before rinsing. Do not allow detergent to dry on surface. Rinse with clean water under high pressure. On a vertical surface, rinse from the bottom up, then rinse from the top down to avoid streaking. Hold nozzle 6-8” (15-20 cm) from the work surface, at a 45°...
  • Page 15 OPERATING INSTRUCTIONS CAUTION Failure to clean properly will cause the injection system to become clogged and inoperable. CAUTION Never use: • Bleach, chlorine products and other corrosive chemicals • Liquids containing solvents (i.e., paint thinners, gasoline, oils) • Tri-sodium phosphate products • Ammonia products • Acid-based products These chemicals will harm the unit and will damage the surface being cleaned.

  • Page 16: Winterizing And Long-Term Storage

    2. Depress button on top of antifreeze container. 3. Continue until exits the pump outlet. 4. Remove the hose from pump inlet. Use Simoniz® Pressure Washer Antifreeze (39-8602-0). Quick Winterizing Procedure If you cannot do the Optimum Winterizing procedure, you can still protect your pres-...

  • Page 17: Cleaning And User Maintenance

    CLEANING AND USER MAINTENANCE Connections Connections on pressure washer hoses; gun and spray wand should be cleaned regularly and lubricated with non-water soluble grease. Adjustable Nozzle Only Clogging of the nozzle causes the pump pressure to be too high and cleaning is immediately required.

  • Page 18: Troubleshooting

    TROUBLESHOOTING Disconnect the machine from the power source before making any repairs. Symptom Cause Solution Motor will not start. On/Off switch is in the Turn switch to the “ON” “OFF” (O) position. ( | ) position. Power cord is not plugged in. Plug in power cord.

  • Page 19: Troubleshooting

    TROUBLESHOOTING Symptom Cause Solution Discharge nozzle is obstructed. Blow out or remove debris with a fine needle. Calcified gun, hose or Run distilled vinegar power nozzle. through detergent tank. No Detergent Detergent container is empty. Add more detergent. Detergent bottle or suction Check connections.
  • Page 20 Pressure washer not used Call the Toll-Free Hotline. for long periods. IF YOU ENCOUNTER ANY ADDITIONAL DIFFICULTIES NOT LISTED, VISIT OUR WEBSITE AT WWW.SIMONIZ.CA OR CALL CUSTOMER SERVICE AT 1-866-4SIMONIZ (1-866-474-6664) FOR HELP . Imported by Trileaf Distribution Trifeuil Toronto, Canada M4S 2B8...
