Preset Mode
In the PRESET mode, the Rear Control Light is switched ON to indicate that the panel voltage
and current controls are de‐activated.
There are three preset outputs, P1, P2 and P3, selectable via the Recall Switch, located on the
rear of the power supply.
The preset values are factory set per the following table.
Presets
P1
P2
P3
Set Mode
In the SET mode, the Voltage and the Current values for the three presets (P1, P2, and P3) can
be programmed.
1.
Set the Mode Switch located on the rear of the power supply to the "SET" position.
2.
Select a preset using the Recall Switch (set to the P1, P2 or P3 position).
3.
Use the front panel Voltage Control Knob to set the desired voltage value.
4.
Use the front panel Current Control Knob to set the desired current value.
5.
Repeat this procedure for the remaining presets if desired.
6.
Move the Recall Switch from the SET to the PRESET position to store changes.
Note: Presets reside in non‐volatile memory meaning that the voltage and current settings for
each preset are retained even when the power supply is switched OFF.
Caution: Check the output voltage of the preset in use before connecting to the Load. To check a
preset value, move the Mode Switch to the PRESET position and then move the Recall Switch to
the P1, P2 or P3 position. The Voltage and Current settings for the corresponding preset will
display.
Output Voltage
5V
13.8V
25V
5
Output Current
Maximum
Maximum
Maximum
382275/6-EU-EN v4.3 3/14
