Baud rate from 300 to 57600
No parity
8 data bits
1 stop bit.
Your output device must be configured in the same way in order to communicate with ColorFlex. Note
that Universal Software's maximum baud rate is 19200.
Note: Several baud rates are available with ColorFlex. Be sure to change the INSTRUMENT
SETUP of ColorFlex to agree with the baud rate selected for your output device.
Handshake
Output from the ColorFlex serial port is controlled by XON/XOFF handshaking. Data output is stopped
when the output device sends an XOFF character to ColorFlex. Data flow begins again when ColorFlex
receives an XON character.

Conditions of Illumination and Viewing

Source
Source UV Content
Integrating Sphere
Port Diameters/View Diameters
45/0 Model
Diffuse/8°

Power Required

External 120/220 V locking AC adapter
Power Cord Wire Color Code:
Color
220V Cord Brown
Blue
Green/Yellow SAFETY
110V Cord Black
White
Green
Instrument-Computer Ground Potential Check:
Perform this check if the power cord wiring is being changed, such as for replacement of the cord or if
changing the plug.
07/02
Dual-beam xenon flash lamp, >500,000 flashes
Nominal match to D65
63.5 mm diameter, high-efficiency white coating
31.8 mm (1.25")/25.4 mm (1.0")
14.3 mm (0.56")/8.0 mm (0.31")
Definition
LINE
NEUTRAL
LINE
NEUTRAL
SAFETY
ColorFlex 13-19
