- Page 1 US: 800-556-3484 UK: 0800 585733 Mexico: 001-800-556-3484 U S E R ’ S G U I D E technical@efd-inc.com...
- Page 2 Setup and Operation air cylinder Step 1. Remove reservoir retainer reservoir retainer plunger IMPORTANT: Confirm that a ULTRA ™ white piston is between the reservoir system fluid and the plunger. dispensing tip Step 2. Install dispensing tip on reservoir. Insert filled reservoir into retainer and align flange flange alignment with slot as shown.
- Page 3 Attach a new tip and tighten tip retaining cap securely. Note: Refer to EFD dispenser operating instructions to control deposit size with time and pressure. Do not reuse reservoirs! Wipe plunger clean (if necessary) before installing a new reservoir.
- Page 4 Replace with new bushing. Sales and service of EFD dispensers and dispensing components are available through EFD authorized distributors in over 30 countries. Please contact EFD USA for specific names and addresses. Install piston assembly and reinstall the air cylinder cap and drive plunger.
